D10.4 Training Concepts and Training Plans

Project number

IST-027635

Project acronym

Open_TC

Project title

Open Trusted Computing

Deliverable type

Report

Deliverable reference number

IST-027635/D10.4/1.0 Final

Deliverable title

Training Concepts and Training Plans

WP contributing to the deliverable

WP10

Due date

Oct 2006 - M12

Actual submission date

30

th

 November 2006

Responsible Organisation

RHUL

Authors

RHUL (Stéphane Lo Presti, Eimear Gallery,
Chris Mitchell), PORT (Bora Güngören, Baran
Erdo

ğ

an), TUB (Görkem Çetin), IAIK (Peter

Lipp), TEC (Klaus-Michael Koch, Sabine
Dullnig)

Abstract

This document introduces the training
concepts relevant to courses on (Open)
Trusted Computing, and presents the various
training plans devised by the project
partners.

Keywords

Training concept, training plan, trusted
computing

Dissemination level

Public

Revision

1.0 Final

Instrument

IP

Start date of the
project

1

st

 November 2005

Thematic Priority

IST

Duration

42 months

background image

Training Concepts and Training Plans

1.0 Final

Table of Contents

1  Introduction ...............................................................................................................3
2  Major Goals.................................................................................................................4

2.1   Professional training.............................................................................................4

2.1.1   Identification of the Target Audience.........................................................4
2.1.2   List of Major Course Goals..........................................................................5

2.2   Academic training.................................................................................................6

3  Training concepts.......................................................................................................8

3.1   Concepts related to Academic training.................................................................8
3.2   Concepts related to Professional training.............................................................8

4  Training plans...........................................................................................................17

4.1  PORT....................................................................................................................17
4.2   RHUL...................................................................................................................20

4.2.1   Course unit proposal..................................................................................20
4.2.2   Course specification...................................................................................23
4.2.3  Lecture plans...............................................................................................24

4.3  TEC......................................................................................................................34
4.4  TUB......................................................................................................................37
4.5   IAIK.....................................................................................................................38

5  List of Abbreviations ................................................................................................40

Open_TC Deliverable 10.4

2/40

background image

Training Concepts and Training Plans

1.0 Final

1 Introduction

The  OpenTC  project  has  been  set  up  with  ambitious  technical  objectives.  When
achieved, these objectives will improve the state of the art and enable a whole new
set of products and services to be built. If OpenTC is to be accessible to a general
audience, education on Trusted Computing in general and the OpenTC approach in
particular is important in order to ensure that this new technology is well understood.
Both  academic  and  professional  training  will  be  completed  in  order  to  spread  the
results of OpenTC to a wide audience, including open source developers, postgraduate
students, researchers, engineers and industrial executives. Training activities will take
a variety of forms, including workshops, university courses and/or on-line tutorials. The
training activities will also provide external feedback to OpenTC.

Europe is often credited to be a major and constant source of highly qualified open
source developers. This position derives from the relationship of European universities
to  open  source.  Most,  if  not  all,  European  universities  encourage  the  use  of,  and
contributions  to,  open  source  software  in  higher  education  courses.  Therefore
European universities can play an important role in communicating the results of the
OpenTC project to European open source developers.

All OpenTC training activities aim at delivering high quality and technically unbiased
information  about  Trusted  Computing  in  general,  and  demonstrating  the  use  of
Trusted  Computing  using  OpenTC  deliverables  (specifications,  designs  and  open
source code, where applicable). This document presents the major goals of OpenTC
training.

This document serves as a requirements specification for the training material to be
developed  within  the project.  This specification  first  presents  a list  of  seven  Major
Course  Goals  (MCGs)  and  a  larger  list  of  289  detailed  Learning  Objectives  (LOs)
assigned to MCGs.

Secondly, the main concepts that are to be covered in OpenTC training courses are
presented. General concepts common to all courses are described, and concepts more
specific  to  academic  or  professional  training  are  then  given.  These  concepts  are
presented as a general list of learning objectives that can be used as a checklist for
quality  control  of  the  training  material  in  preparing  instruction,  examination,  or
certification material related to OpenTC training.

Thirdly, the various training courses planned by OpenTC partners in the context of this
work package are described. Each partner has a different focus and a different target
audience, and providing these training plans demonstrates the diversity of ways that
the OpenTC partners have found to apply the learning objectives to their training.

Note  that  all deliverables  in  subworkpackage  10c,  including  this  one,  are  released
under an Open Source or Creative Commons License, as stated by each contributor
individually.

Open_TC Deliverable 10.4

3/40

background image

Training Concepts and Training Plans

1.0 Final

2 Major Goals

The goals of an OpenTC training activity have been devised in two main ways. First,
training for open source developers in a professional context has been analysed and
designed, and this work and the corresponding results are presented in section  2.1.
Secondly,  integration  of  OpenTC  training  into  university  courses  is  taking  place  in
various partner institutions, and the specific goals of these courses are presented in
section 2.2.

2.1  Professional training

Examination  of  open  source  developer  courses  was  conducted  by  PORT,  including
UNIX/Linux  development  and  security  related  courses  in  universities,  professional
courses  and  workshops  offered  by training  companies  or  professional  associations.
The   training   material   studied   includes   websites   that   were   either   open   source   or
without any license notification, as well as books on security and secure development.

This study has shown that, contrary to common belief, most open source developers
lack  common  knowledge  in  secure  application  design  and  development.  Therefore
training  material  aiming  at  the  majority  of  open  source  developers  should  either
explain or make  reference to basic  principles, methods and technologies of secure
development,  where  necessary.  On  the  other  hand,  developers  with  even  minimal
experience in secure development do not have problems in explaining and correctly
applying most basic functions such as performing certificate operations, using hashes
to check file integrity or using Linux process mechanisms for authentication.

Note that this situation creates a widening gap in application development, as most
low level code and libraries developed in the open source domain are designed and
implemented  securely,  but security-related bugs increase  statistically  because  high
level developers often do not use even the most basic designs in security.

The   lack   of   good   training   material   further   widens   this   gap.   Most   open   source
developers demand precise training material than can be quickly understood. They
typically prefer to learn through real life examples, so as to to understand the need for
the  technology,  and  then  find  a  generic  source  code  sample  that  addresses  the
problem. As more advanced subjects in security are hard to express in this manner,
there is often no information publicly available on these topics that developers can use
in practice. More advanced topics are covered mainly in books or on some websites.

The majority of these resources are not easily accessible to open source developers,
and they further assume that the intended audience has knowledge and experience
about  elementary  and  some  advanced  topics  on  security.  With  this  assumption  in
mind, the material is prepared so that intended audience does not spend time learning
the basics and jumps straight into the subject. However, this ignores the needs of the
typical open source developer and leaves him with the task of learning the basics on
his own. As a consequence, this widens the knowledge gap between those who can
use the material and those who can not.

2.1.1  Identification of the Target Audience

In order to appeal to most open source developers and keep duplication of work to a
minimum, we have identified the following type of audience for the training materials

Open_TC Deliverable 10.4

4/40

background image

Training Concepts and Training Plans

1.0 Final

to be developed later in the project:

Inexperienced open source developers that want to learn about basic security
and how to achieve it using Trusted Computing. The focus here is primarily on
hardening  existing  systems  by  use  of  the  TPM/TSS.    What  these  developers
often need is sample source code in C/C++, and also instructions on how to
build   and   link   this   code   with   common   library   dependencies.   Note   that   it   is
possible to have a number of environments with different sets of library paths in
Linux, and thus even compilation, packaging and installation of such code can
be problematic.

Experienced security developers that want to learn about the enhancements
Trusted  Computing  brings.  These  developers  want  to  see  more  advanced
methods  in  securing  applications,  and  they  will  often  apply  them  to  their
existing  applications.  They  might  even  have  prior  experience  with  using
TPM/TSS, but they will be interested in using OpenTC deliverables such as the
Basic Management Interface or the Privacy CA.

Therefore  the  OpenTC  course  goals,  presented  in  the  next  section,  have  been
designed to accommodate the needs of these two types of audience. Training material
for  major  goals  that  correspond  to  basic  knowledge  of  Trusted  Computing  will  be
developed in a style adapted to the first type of audience.

2.1.2  List of Major Course Goals

The following list of seven Major Course Goals (MCGs) have been specified to give a
high level overview of the objectives that an OpenTC training course should achieve.

MCG 1. Explain what Trusted Computing is using TCG definitions.

The audience should first learn how to define security and under which conditions it
can be defeated, while being able to classify these aspects with respect to hardware,
OS  and  application  software.  Building  upon  this  classification,  they  will  learn  what
cryptography can offer in order to enhance security, and use OpenSSL and certificates
to implement it. This background will then be used to define what Trusted Computing
is,   and   to   define   major   components   of   a   TC-enabled     environment,   such   as   an
endorsement  key,  TPM  sealing,  Direct  Anonymous  Attestation  (DAA)  or  enforced
policies.

MCG  2.  Understand  and  use  in  practice  existing  TPM  and  TSS
implementations for designing and developing applications.

The audience will learn the properties of a trusted platform in detail, and how to use
all the basic TPM features. Furthermore they will be able to elaborate on the features
of versions 1.1 and 1.2 of TPMs, installing and using TPM drivers and related software
on Linux. This will include features such as RTM based measurements and using these
measures,  key  migration  issues,  correctly  placing  the  TPM  in  a  complete  trusted
platform  implementation  including  hardware,  software  and  the  networked
environment,  setting up  the  the  trusted platform  itself, and  reference  source code
functions such as those in the TPM Tools package.

MCG 3. Describe the goals and objectives of the Open Trusted Computing
project by using the public specification (D02.1), plus updates and related
source code deliverables.

Open_TC Deliverable 10.4

5/40

background image

Training Concepts and Training Plans

1.0 Final

The audience will understand what the OpenTC project is aiming to achieve at the low
level of the infrastructure, and how the project results can be used to enhance the
security of individuals and corporations. The audience will first learn the basic goals of
the project and the common fears of Trusted Computing that have been witnessed by
the general public. Once the virtualisation approach of OpenTC is understood in detail
(i.e. the VM hosted security services model, enhancements to the x86 architecture,
SOAP  interfacing  to the TCS, runtime  protection and  isolation  of OS instances) the
audience will evaluate the three application scenarios chosen for demonstration of the
Open TC results. Note that this Major Goal covers and makes detailed use of the public
deliverables of WP02-05.

MCG 4. Describe and demonstrate use of the Basic Management  Interface
(BMI)  by  using  the  public  specification  (D04.1),  plus  updates  and  related
source code deliverables.

The  audience  will  analyse  and  understand  the  boot  sequence  of  virtualised  OS
instances,  and  be  able  to  discuss  how  additional  security-related  features  can  be
incorporated into a virtualisation abstraction. Furthermore they will be able to use the
BMI.

MCG  5.  Evaluate  an  everyday  application  (e.g.  Office  Suite,  Email)  for
security issues and design an improved version using OpenTC deliverables.

The   security   of   a   common   application   will   be   evaluated.   Then   the   procedure   to
evaluate   an   application   will  be   shown   on  an  example   of   typical   software   (e.g.   the
kwrite text editor). The audience will be then guided in the preparation  of a short
specification for an improved version that uses OpenTC deliverables.

MCG  6.  Evaluate  a  security  related  application  (e.g.  DRM,  Firewall)  for
security issues and design an improved version using OpenTC deliverables.

The  security  of  a  security  application  will  be  evaluated.  Then  the  procedure  to
evaluate an application will be shown for a typical piece of secure software (e.g. the
iptables  firewall).  The  audience  will  be  then  guided  in  the  preparation  of  a  short
specification for an improved version that uses OpenTC deliverables.

MCG 7. Demonstrate the use of GPL'ed source base produced by OpenTC.

The audience will make use of OpenSSH and OpenSSL implementations modified for
TPM/TSS, and also proof of concept applications developed in WP06.

2.2  Academic training

Academic  training  deals with a rather different  audience than that for professional
training.    Moreover,  the  nature  of  teaching  in  an  academic  environment  is  very
different  to  the  short-term  focused  training  typically  available  in  a  commercial
environment.  Therefore it needs to fulfill rather different goals.  Graduate  students
often have no significant prior knowledge of security when taking courses on security
or  secure  development    However,  as  their  work  often  includes  a  large  amount  of
research, they easily adapt and rapidly learn the necessary basics. Therefore when
given the appropriate resources, we can expect graduate students to develop secure

Open_TC Deliverable 10.4

6/40

background image

Training Concepts and Training Plans

1.0 Final

code.

Graduate students have more diverse and sometimes very advanced objectives, such
as evaluating Trusted Computing based designs and implementations. Therefore they
will  not  only  have  to  cover  the  subjects  covered  for  developers  in  the  previously
described professional training, but also possibly design and implement a small proof
of concept with very advanced design as part of thesis work.

The goals of such an OpenTC training course include:

Provide a basic introduction to trusted computing;

Discuss how trusted computing ideas might assist with the future development of
secure systems;

Describe the basic hardware and software technologies underlying trusted
computing;

Give an appreciation of how virtualisation and isolation, with appropriate hardware
support, can provide a trusted environment in which to run sensitive applications;

Discuss possible applications of trusted computing technology.

Open_TC Deliverable 10.4

7/40

background image

Training Concepts and Training Plans

1.0 Final

3 Training concepts

Every OpenTC training course should address basic information security concepts,  the
underlying Trusted Computing technology, and the OpenTC approach.

In  educational  theory,  learning  occurs  only  when  a  behavioural  change  (mostly
psychomotor or cognitive) is observed. We can thus define any educational application
in terms of the expected changes in behaviour. It is common practice to provide lists
of such expected changes. These lists are not simple lists of topics to be covered in a
course, but they describe what the student should be able to do after the course. The
most commonly used terms for these are training concepts and learning objectives.

Training concepts or learning objectives describe student performance and hence can
also  be  used  for  assessment.  As  formal  assessment  is  an  important  tool,  course
designs should be tailored so that their results can be assessed.

In practice, these concepts are often related to exact skills, knowledge and attitude
(SKA) that the student is expected to gain. Professional training programs focus more
on skills than knowledge and attitude, whereas academic training programs want to
achieve  higher  levels  of  cognitive  learning  such  as  synthesis  and  evaluation  of
concepts.    Therefore,  concepts  developed  for  professional  courses  have  a  large
number  of  narrowly  defined,  to-the-point  entries  and  academic  objectives  are
expressed in broader terms.

The training concepts which may be adapted to academia are first described, followed
by concepts more tailored towards professional training.

3.1  Concepts related to Academic training

Depending   on   the   subject   of   the   academic   degree   where   the   OpenTC   training   is
taught,  an  introduction  to  the  basic  principles  of  computer  security  and  possibly
cryptography may be necessary.

An OpenTC training will probably introduce the history of trusted computing, notably
the one of the TCG, and possibly concludes the training with a description of some of
the non-technological elements (software license, socio-psychological trust, public
acceptance of the technology, etc.).

With regards to the technological elements of the training, on successful completion of
an academic course students should be able to:

understand the fundamental principles behind trusted computing;

work with the TCG specifications;

have an appreciation of the range of possible trusted hardware and software;

understand what trusted computing can do to improve system and user security
(and what it cannot do);

understand the OpenTC approach and be able to compare it to other approaches;

analyse and assess possible applications of trusted computing.

3.2  Concepts related to Professional training

MCG 1. Explain what Trusted Computing is using TCG definitions.

Open_TC Deliverable 10.4

8/40

background image

Training Concepts and Training Plans

1.0 Final

LO 1. Define the security of a system.
LO 2. Define a security violation or a flaw.
LO 3. Explain some hardware security flaws.
LO 4. Explain some software security flaws.
LO 5. Explain general attack methods with respect to software and hardware security
flaws.
LO  6.  Define  the  terms  "trust"  and  "trustworthy"  with  respect  to  general  security
concepts.
LO 7. Present the definition of Trusted Computing given by the TCG.
LO 8. Explain how Trusted Computing contributes to security at large.
LO 9. Explain the four key concepts of Trusted Computing.
LO 10. Present the endorsement key and describe its usage and logic.
LO 11. Explain the necessity of the secure I/O channels by using examples such as key
loggers.
LO 12. Explain how memory curtaining and memory isolation in virtualisation could be
achieved by cryptographic means.
LO 13. Explain how Trusted Computing would contribute to memory curtaining.
LO 14. Define the terms "sealed" and "secured" for memory related issues.
LO 15. List software and hardware based methods for encryption in data sealing.
LO 16. Present "remote attestation" using a client-server application scenario
LO 17. Define “privacy”, “anonymity” and discuss their legal and ethical necessity.
LO 18. Describe how anonymity can be implemented.
LO 19. Debate over anonymity and attestation.
LO 20. Present DAA.
LO 21. Define Digital Rights Management (DRM) and show a number of potential uses.
LO 22. Debate over the moral issues around DRM.
LO 23. Explain how DRM could be achieved without major ethical problems.
LO 24 .Define identity theft and list a number of examples.
LO 25. Explain how identity theft could be prevented.
LO  26.  Define  "viruses"  and  "worms"  and  explain  how  they  work  by  using  recent
examples.
LO 27. Explain how Trusted Computing could prevent the spreading of viruses and
worms.
LO 28. Define biometrics and list a number of biometric attributes.
LO 29. Debate of the use of biometrics in security.
LO 30. Explain the necessity for protecting biometric data and how Trusted Computing
can help.
LO  31.  Define  the  terms  "platform"  and  "trusted  platform"  using  the  TCG
specifications.
LO 32. Explain the need for layered designs in implementing trusted platforms.
LO 33. Define the term "root of trust".
LO 34. Explain why more than one root of trust can be necessary for practical reasons.
LO 35. Define a Trusted Platform Module with respect to a generic trusted platform.
LO 36. Define a Trusted Platform Module with respect to TCG specifications.
LO 37. List the features of a TPM v1.1.
LO 38. List the additional features of a TPM v1.2.
LO 39. Explain the cryptographic capabilities and limits of a 1.2 TPM.
LO 40. Explain how the TPM is used for cryptographic key management.
LO 41. Define the term "enforced policy" and list a number of potential uses.
LO 42. Describe a number of ways on how enforced policies could be implemented.

Open_TC Deliverable 10.4

9/40

background image

Training Concepts and Training Plans

1.0 Final

LO 43. Define and compare "hard" and "soft" enforced policies.
LO 44. Define "access control" and the existing ACL implementation of Linux.
LO 45. List access control issues with respect to Trusted Platforms.
LO 46. Describe how a complete electronic voting mechanism could be implemented
using  concepts  and  techniques  utilizing  Trusted  Computing  such  as  anonymity,
attestation, access control, and enforced policies.

MCG  2.  Understand  and  use  in  practice  existing  TPM  and  TSS
implementations for designing and developing applications.

LO 1. Define the key concepts of a trusted platform.
LO 2. Describe a number of root of trust mechanisms.
LO 3. Describe how the RTM takes measurements.
LO 4. Explain how the RTS enables trusted storage.
LO 5. Explain how the RTR handles reporting.
LO 6. Compare the CRTM with the RTM.
LO 7. Define the all NV functional structures in the TPM.
LO 8. Explain which values are kept in the PCRs.
LO 9. Compare the TRNG with OS random number generator.
LO 10. Present the key generation capabilities of a TPM v1.2.
LO 11. Present a cryptographic co-processor engine with respect to engines in a TPM.
LO  12.  Compare  a  cryptographic  accelerator  with  a  TPM  from  the  application
developer's point of view.
LO 13. Explain how HMAC is used in a Trusted Platform.
LO 14. Explain the importance of the power state of a TPM chip.
LO 15. Compare key migratability and non-migratability.
LO 16. Evaluate an application scenario where keys should be migratable.
LO 17. List the basic set of keys inside a TPM.
LO 18. Describe the key hierarchy in a TPM.
LO 19. Present the SRK with respect to data and key protection.
LO 20. Define endorsement, platform and conformance credentials.
LO 21. Explain AIKs and their credentials.
LO 22. Explain DAA.
LO 23. Compare AIK and DAA with regards to privacy.
LO 24. Define the TSS.
LO 25. List the TSS Layers and their complementary behavior with respect to the TCG
design.
LO 26. Present the high level TSS Layer Hierarchy.
LO 27. Define the interaction between the TDD and the TCS.
LO 28. Elaborate on why we should use TSPI for application development.
LO 29. Define the entities involved in the TP from the end-user point of view.
LO 30. Define authorization and privilege techniques.
LO   31.   Compare   physical   presence   and   cryptographic   authorization   in   terms   of
demonstrating privilege.
LO 32. Define and compare the OIAP and OSAP protocols.
LO 33. Explain how to change authorization data.
LO 34. Define and compare AACP and ADCP protocols.
LO 35. Explain the initialization of the TPM using pseudo-code.
LO 36. Explain how to enable the TPM using pseudo-code.
LO 37. Explain how to take ownership of the TPM using pseudo-code.
LO 38. Explain how to clear the TPM using pseudo-code.

Open_TC Deliverable 10.4

10/40

background image

Training Concepts and Training Plans

1.0 Final

LO 39. Compare data sealing, data binding and data wrapping.
LO  40.  Define  transport  security  and  session  establishment  with  a  TPM.  Define  a
Monotonic Counter.
LO 41. Define a Context Manager.
LO 42. Draw the schema of a simple Trusted Platform.
LO 43. Present trusted platform architectures such as NGSCB, Nizza and OpenTC.
LO 44. Describe how to setup a Trusted Platform.
LO 45. Describe functionalities and commands of TPM Tools.
LO 46. Demonstrate activating and taking ownership of the TPM with TPM tools.
LO 47. Describe the interaction of the layer interfaces between TSS API.
LO 48. Describe TDDLI in detail, including its programming logic.
LO 49. Describe TCSI in detail, including its programming logic.
LO 50. Describe TSPI in detail, including its programming logic.
LO 51. Present how to program using Trousers TSS API.
LO 52. Describe the programming logic of the TSS.
LO 53. Describe common TSPI functions.
LO 54. Explain how the context manager works.
LO 55. Define the policies.
LO 56. Present the different types of object.
LO 57. Describe TSPI common return codes.
LO 58. Describe important TSS structures like TSS_PCR_EVENT, TSS_UUID.
LO 59. Demonstrate how to initialise and create objects from a context using the TSPI.
LO 60. Explain attributes and flags of the related objects.
LO 61. Demonstrate getting and setting the attributes of the objects.
LO 62. Explain functional classes of the objects.
LO 63. Demonstrate how to get the TPM object of the system via a context.
LO 64. Demonstrate getting and setting TPM properties.
LO 65. Demonstrate how to get the endorsement key of the TPM with an application.
LO 66. Explain key generation and usage of the SRK.
LO 67. Describe a UUID.
LO 68. Describe how to load or get keys from Trusted Storage.
LO 69. Describe data sealing and binding in an application.
LO 70. Explain the usage of Tspi_ChangeAuth and Tspi_ChangeAuthAsym.
LO 71. Present the Tspi_Policy class.
LO 72. Present the Tspi_TPM class.
LO 73. Present the Tspi_Key class.
LO 74. Present the Tspi_Hash class.
LO 75. Present the Tspi_Data class.
LO 76. Present the Tspi_PcrComposite class.
LO 77. Describe Tspicb callback function definitions.
LO 78. Examine TPM Tools source code.
LO 79. Describe TCS architectural properties like memory manager, data marshalling
and interface dynamics.
LO 80. Describe the architecture of TDDL.
LO 81.  Draw a high level TSS hierarchy diagram  with respect to local and remote
procedure calls.

MCG 3. Describe the goals and objectives of the Open Trusted Computing
project by using the public specification (D02.1), plus updates and related
source code deliverables.

Open_TC Deliverable 10.4

11/40

background image

Training Concepts and Training Plans

1.0 Final

LO 1. Describe the goals of the OpenTC project.
LO  2.  Elaborate  on  whether  an  OS  supplier  could  take  control  on  installation  of
software with or without cooperation from the owner of the computer.
LO 3. Discuss technical aspects of Linus Torvald's and Richard Stallman's positions on
Trusted Computing.
LO 4. Discuss the virtualisation approach of the Open TC project.
LO 5 .Describe briefly XEN and L4 virtualisation architectures.
LO 6. Define a virtual machine monitor (VMM) / hypervisor.
LO 7. Discuss how hypervisors can verify a trusted platform boot.
LO  8.  Discuss  how  hypervisors  can  be  used  to  enforce  security  policies  on  OS
instances.
LO 9. Describe a platform security kernel.
LO 10. Elaborate on the definition of a trusted computing base (TCB) for the case of
OS virtualisation.
LO 11. Elaborate on differences in the TCB between XEN and L4.
LO 12. Elaborate on implementing a TCB with Linux or Windows on XEN or L4.
LO 13. Present a diagram of the proposed VM-hosted security services model.
LO 14. Discuss the use of virtual TPMs and a separate TPM server.
LO 15. Describe the components and features of the hardware/virtualisation layer.
LO 16. Describe the components and features of the trusted software layer.
LO 17. Describe briefly the Basic Management Interface (BMI).
LO 18. Discuss the use of scripting tools and Java for the security kernel OS instance.
LO 19. Discuss key management issues for the VM-hosted security services model.
LO 20. Present current and discuss future TPMs and TC enhanced CPUs.
LO 21. Discuss the changes in the x86 architecture, with reference to the AMD Pacifica
specification.
LO   22.   List   the   elements   of   secure   initialization  architecture  provided  by  the  SVM
guest execution environment.
LO 23. Discuss why secure initialization requires immutable hardware components.
LO  24.  Discuss  how  a  secure  loader  is  measured  and  how  this  measurement  is
extended to the TPM.
LO 25. Provide a basic list of secure software components for establishing a TCB on a
secure loader.
LO 26. Discuss the need for a Configuration Verification (CV) module and describe the
expected functionality.
LO 27. Describe how a TSS stack could be implemented.
LO 28. Debate over the need for a SOAP  interface for the TCS.
LO 29. Describe the implementation of the SOAP interface.
LO 30. Describe the TCS persistent storage and how it can be used.
LO 31. Discuss the logical and physical cache strategies in a TSS implementation.
LO 32. Discuss error handling strategies in a TSS implementation.
LO 33. Define a PKCS#11 interface.
LO 34. Discuss how a PKCS#11 API can be implemented on a TPM/TSS.
LO 35. Discuss and compare key and certificate models in common applications.
LO 36. Discuss the benefits of designing a key management adaptation (KMA) module.
LO 37. Describe how OpenSSH could be adapted to use TPM/TSS.
LO 38. Describe how the OpenSSL core engine could be adapted to use TPM/TSS.
LO  39.  Discuss  and  compare  the  Java  security  model  to  that  of  the  OpenTC
architecture.
LO 40. Discuss whether Java would benefit from Trusted Computing and OpenTC.
LO 41. Describe the chain of trust for a Java Applet running on top of a TC-enabled

Open_TC Deliverable 10.4

12/40

background image

Training Concepts and Training Plans

1.0 Final

Java VM.
LO 42. Describe the basic goals of hypervisor-based security architectures.
LO 43. Debate approaches for runtime protection and isolation of OS instances.
LO 44. Define the Trusted Computing Base (TCB) for the OS instances running on top
of hypervisors.
LO 45. Define the TVL and how it establishes the chain of trust.
LO 46. Describe the life cycle of an OS instance loaded by XEN/L4.
LO 47. Describe the security policies at the hypervisor level.
LO 48. Describe the layers of the OpenTC framework with respect to the management
services.
LO 49. Define the three types of management services developed within the OpenTC
project.
LO 50. Discuss the use of the management services by applications.
LO 51. Define the components of the OpenTC security services.
LO 52. Describe the functionalities of the Compartment Security Manager.
LO 53. Describe the functionalities of the Compartment Trust Manager.
LO 54. Describe the functionalities of the Storage Manager.
LO 55. Discuss how the Storage Manager is used by applications at higher levels.
LO 56. Define the OpenTC security management services.
LO 57. Describe the management of a TPM.
LO 58. Describe the security platform initialization.
LO 59. Describe how a user-initiated TPM migration takes place.
LO 60. Describe the key management services and infrastructure.
LO 61. Discuss and compare the use of a Privacy CA and DAA.
LO  62.  Debate  over  the  high  level  use    case  approach  used  in gathering  OpenTC
requirements.
LO  63.  Discuss  the  security  measures  for  Internet  branch  and  similar  applications
provided by major banks.
LO 64. Discuss the private electronic transaction (PET) scenario of the OpenTC project.
LO 65. Compare the use of a trusted OS for private electronic transactions with the
use of a hardened browser on a legacy OS.
LO 66. Discuss the feasibility of banks supplying a Linux OS image based on the PET
scenario.
LO 67. Simulate and test the functional requirements of the PET scenario by assigning
roles among peers where each threat is tested.
LO 68. Discuss the use of security proxies for clients.
LO 69. Discuss the use of security proxies for servers.
LO  70.  Discuss  the  establishment  of  the  communication  on  the  SSL/TLS  channel
between each proxy.
LO 71. Describe a Data Center and the services offered by such infrastructure.
LO  72.  Describe  P2P  and  Grid  technologies  and  their  relationship  to  data  center
operations.
LO 73. Describe how mapping virtual resources to physical resources can contribute to
the management complexity of data centers.
LO  74.  List  down  privacy  issues  and  common  security  threats  in  data  center
applications.
LO 75. Discuss common threats and attacks on data centers.
LO   76.   Discuss   published   security   flaws   on   server   applications   that   data   centers
typically use.
LO 77. Describe how mapping virtual resources to physical resources can contribute to
the security complexity of data centers.

Open_TC Deliverable 10.4

13/40

background image

Training Concepts and Training Plans

1.0 Final

LO 78. Elaborate on the concept of load balancing for higher performances and how
this could be achieved with virtualised resources.
LO 79. Discuss configuration management issues on a virtualised data center.
LO 80. Discuss network policy applications on a virtualised data center.
LO 81. Discuss how data center operators would benefit from networked servers for
verification and attestation of virtual/physical resources.
LO  82.  Describe  and  compare  the  boot,  hibernation  and  reboot  processes  of  a
virtualised server instance to the one of a physical server instance.
LO 83. Discuss the differing levels of trust of the administrator roles on virtual and
physical resources.
LO 84. Draw a diagram of the virtualised data center scenario and show the trusted
path to the user.
LO  85.  Discuss  home  officing,  outsourcing,  offshoring  and  similar  activities  which
result in employees being physically separated from employers and offices.
LO 86. Describe how complex workflow  applications  are designed to accommodate
cases such as territory management for sales representatives.
LO 87. Elaborate on the case of professionals such as medical doctors, lawyers and
consulting engineers who have to separate data of one client from the other because
of legal and ethical reasons.
LO 88. Discuss and verify that feasibility of the Corporate Computing at Home (CCH)
scenario for the mentioned job descriptions.
LO 89. Discuss how to configure and manage each trusted OS instance separately and
independently.
LO 90. Describe the trust relationship between two different trusted OS instances with
respect to confidentiality and integrity of data.
LO 91. Describe the trusted path between each OS instance and the corporate servers.
LO 92. Describe the process of booting up a new trusted OS instance.
LO 93. Describe the process of switching to another trusted OS instance.
LO 94. Compare the usability and security of the CCH scenario with existing VPNs and
workflow based applications.
LO 95. Simulate the threat scenarios to be considered for the CCH case by facilitating
a role play among peers.
LO  96.  Look  for  a  way  that  an  employer  would  have  for  creating  a  malicious  OS
instance that would access the other OS instances.

MCG 4. Describe and demonstrate use of the Basic Management  Interface
(BMI)  by  using  the  public  specification  (D04.1),  plus  updates  and  related
source code deliverables.

LO  1.  Describe  the  Basic  Management  Interface  as  a  front-end  hiding  the  specific
virtualisation technique used by the hypervisor.
LO  2.Describe  the  Basic  Management  Interface  as  a  front-end  for  creating  and
managing trusted OS instances.
LO 3. Describe the Basic Management Interface as a mechanism ensuring the integrity
of the overall system.
LO  4.  Demonstrate  the  use  of  the  libvirt  open  source  library  for  creating  a  XEN
domain.
LO 5. Discuss the capabilities of libvirt and how they could be extended for security
purposes such as maintaining the integrity of OS intances.
LO 6. Present the list of hardware resources on a computer to a hosted OS intance.
LO 7. Present the XML schema for the Common Information Model (CIM) standard.

Open_TC Deliverable 10.4

14/40

background image

Training Concepts and Training Plans

1.0 Final

LO 8. Describe the set of resources on a computer using a CIM document.
LO 9. Express a set of Access Control List (ACL) based policies on resources expressed
by a CIM document.
LO 10. Evaluate the proposed component and data model for BMI.
LO  11.  Describe  how  the  Basic  Management  Interface  relies  on  the  Trusted
Virtualisation Layer (TVL).
LO 12. Define the term "protection domain" and explain the difference with the term
"hosted OS instance".
LO 13. Describe the controller interface provided to a protection domain.
LO 14. Define the controlling relationship between protection domains with respect to
controllers.
LO 15. Discuss the types of connection between protection domains.
LO 16.  Elaborate  on how a trusted  keyboard  and mouse  implementation  would be
possible with the BMI.
LO 17. Elaborate on how a DRM Core would control access on sound or video devices
by utilizing the BMI.
LO 18. Discuss the integrity measurement of a set of protection domains.
LO 19. Describe the life cycle and configuration management for XEN.
LO 20. Describe the life cycle and configuration management for L4.
LO 21. Discuss XEN and L4 Interoperability.
LO 22. List the steps of a traditional OS boot sequence.
LO 23. List the steps of a static root of trust measurement during boot with XEN and
L4.
LO 24. Describe the differences in dynamic root of trust measurement during boot.
LO 25. Describe the steps of the creation of a new protection domain.
LO 26. Discuss the need for abstracting the location of a protection domain image.
LO 27. Discuss how to realise a trusted thin client.
LO 28. Describe the protection domain management features of the BMI specification.
LO 29. Describe the protection domain controller features of the BMI specification.
LO   30.   Describe   the   protection   domain   image   location   features   of   the   BMI
specification.
LO 31. Describe the integrity management features in the BMI specification.
LO 32. Describe data structures of the BMI specification.
LO 33. Describe the runtime parameters of the BMI specification.
LO 34. Demonstrate the use of BMI for creating separate protection domains.

MCG  5.  Evaluate  an  everyday  application  (e.g.  Office  Suite,  Email)  for
security issues and design an improved version using OpenTC deliverables.

LO 1. Define information security with respect to ISO 17799 / 27001 standards.
LO 2. Define risk assessment and risk management in a business domain.
LO 3. List the steps in a formal threat assessment.
LO 4. Conduct threat assessment for a simple paper-based document-centric office.
LO 5. Conduct threat assessment for a paperless document-centric office.
LO 6. Identify threats that can be eliminated using basic cryptographic techniques.
LO 7. Identify critical entities and need for entity authentication in an application.
LO 8. Identify access control requirements for entities in an application.
LO 9. Prepare and verify an access control mechanism by applying the Chinese Wall
and/or the Bell LaPadula methods.
LO 10. Prepare a basic security policy document for data communication and storage
in an office application.

Open_TC Deliverable 10.4

15/40

background image

Training Concepts and Training Plans

1.0 Final

LO 11. Prepare a document for improving cryptographically the encryption, the use of
digital signatures, the non-repudiation services, key management and key security.
LO  12.  Evaluate  security  policy  documents  and  cryptographic  improvement
documents when using a TPM/TSS.

MCG  6.  Evaluate  a  security  related  application  (e.g.  DRM,  Firewall)  for
security issues and design an improved version using OpenTC deliverables.

LO 1. Conduct a formal  risk assessment  for the exact application  domain  that the
security application provides secure access to.
LO 2. Conduct a formal risk assessment for the security application itself.
LO 3. Identify the need for cryptographic modules in the security application.
LO 4. Specify the requirements on the TPM hardware component for the cryptographic
modules.
LO 5. Describe the roles, services and authentication mechanisms that cryptographic
modules will support.
LO 6. List the services where the cryptographic module will assume a role or will not
need any assumed role.
LO 7. Describe self test procedures for cryptographic modules.
LO 8. Describe the finite state model for cryptographic modules.
LO 9. Discuss physical and environmental requirements for FIPS 140.2 compliance.
LO 10. Describe the cryptographic key management requirements including random
number  generation,  key  generation,  key  establishment,  key  entry  and  output,  key
storage,  key  deletion,  self  test  and  initialisation  tests  for  the  improvement  of  the
security application.
LO 11. Evaluate the key management infrastructure provided by the OpenTC project
for the described requirements.
LO 12. Prepare a cryptographic module specification.
LO 13. Prepare a cryptographic module security policy document.
LO 14. Evaluate the design of the security application for modularity.
LO 15. Evaluate the source code of the security application for argument passing and
return mechanisms.
LO 16. Evaluate the source code of the security application for entry/exit points.
LO 17. Evaluate the source code of the security application for existing or planned
access to cryptographic modules.
LO 18. Prepare a cryptographic improvement plan for the design and source code of
the security application.

MCG 7. Demonstrate the use of GPL'ed source base produced by OpenTC.

LO  1.Demonstrate  use  of  OpenSSH  and  OpenSSL  implementations  enabled  for
TPM/TSS.
LO 2.Demonstrate the use of the WP06 code base.

Open_TC Deliverable 10.4

16/40

background image

Training Concepts and Training Plans

1.0 Final

4 Training plans

Several  partners  are  currently  planning  to  deliver  courses  in  the  area  of  Trusted
Computing.  In  this  section,  the  training  plans  devised  by  each  partner  for  their
respective courses are presented.

4.1 PORT

PORT will be working on two aspects of the training efforts:

utilise existing connections in academia to support an Msc level course entitled
“Open Trusted Computing”. There is yet no official acceptance of such a course;
but we expect at least 3 Turkish universities to start offering this course in Fall
2007. Researchers from PORT will also be delivering some of the lectures at
these universities.

prepare  a  45-hour  professional  course  that  will  be  used  to  assist  Turkish
developers.  This  course  can  be  either  conducted  in  cooperation  with  the
continuous  education  center  of  a  university  or  PORT  alone.  This  course  will
reflect much of the university course but will have a more hands on approach.

Course Proposal

1. Nature of the proposal

[x] to validate a new course
unit

   to  amend  an  existing  course

unit

  to withdraw a course unit

2. Course code:

 EE5xx / CENG5xx

*3. Course unit value:

 42 hours in class, 60

hours individual study, total 102 hours

4. Course title

: Open Trusted Computing

*5.

 Academic

level:

Professional Training / Masters Level

*6.Student
numbers:

1st year of operation

2nd year of operation

3rd year of
operation

20

40

40

*7. Course team:

TBD (Dept. of Electrical and Electronics Engineering / Computer Engineering)

Bora Güngören, Baran Erdo

ğ

an (Portakal Teknoloji)

8. Programme(s) for which the course is chiefly intended:



MSc in Electrical and Electronics Engineering

MSc in Computer Engineering

*9. Pre-requisites:

 None

*10. Co-requisites:

 None

11. Rationale for the proposal

Open_TC Deliverable 10.4

17/40

background image

Training Concepts and Training Plans

1.0 Final

Information security is gaining importance as more people and institutions trust their critical
data  and  applications  to  computers.  Traditional  security  approaches  can  not  satisfy  the
requirements of a modern information system architecture.

Trusted Computing offers a new approach to security. Each computer is equipped with a low-
cost security chip (the trusted platform module – TPM) which has important features necessary
to implement secure architectures. The TPM can be used for cryptographic primitives such as
key generation and storage, random number generation, hashing and asymmetric encryption.
However, once a developer masters advanced features of the TPM, detailed and more effective
security measures can be implemented on operating system or at application level.

The European Union framework project, Open Trusted Computing (

www.opentc.net

) combines

Trusted  Computing  with  another  recent  development  in  operating  system  architectures.
Virtualisation proposes a (microkernel) layer called a virtual machine monitor (VMM) between
the operating system and the hardware, isolating the OS access to hardware components. The
VMM can load more than one OS instance and enforce policies on their access to the hardware
resources. This brings complete isolation between the operating systems.

When  trusted computing  is  combined  with  virtualisation, it  is  possible to  validate  the  whole
operating system and necessary components during boot-up. A validated OS instance can run a
number of services to secure the environment of user applications. This level of security can
eliminate major problems such as viruses, Trojans, worms and even spam mail. Furthermore a
more secure Internet can be used for electronic transactions such as e-banking, e-health and
even conducting an electronic election.

The same approach is also foreseen in future versions of the Microsoft Vista operating system.
However current systems are implemented on Linux only.

Dissemination and wide acceptance of this new approach and the tools developed for producing
applications that make use of Trusted Computing among graduate students will be very useful
for their professional career. Also as the field is a recently growing field, academic cooperation
opportunities for the University exist.

12. Likely impact of the proposal

The  course  will  require  teaching  space  and  a  computer  laboratory  for  assignments.  The
computers in the laboratory should have Linux installations with a virtual 1.2 TPM or in the best
case they should have a real hardware 1.2 TPM.

It is also suggested that the students be given a discussion space such as a mailing list or a wiki
to share their experience on the subject matter.

*13. Collaborative arrangements

The course will be conducted jointly with the faculty and researchers from Portakal Teknoloji Ltd.

Ş

ti.  Portakal  Teknoloji  will  be  assisting  the  faculty  by  supplying  course  material  and  also

delivering some of the lectures.

Course Description

Code:

EE5xx

/CENG5xx

Course

Value:

3.0

Credits

Status:

ie:Core, or Optional

Optional

Title:

Open Trusted Computing

Availability:

(state which

teaching terms)

Fall term

Open_TC Deliverable 10.4

18/40

background image

Training Concepts and Training Plans

1.0 Final

Prerequisites:

None

Recommended:

Co-ordinator:

TBD

Course Staff:

TBD
Bora Güngören, Baran Erdo

ğ

an (Portakal Teknoloji)

Aims:

This course will:

discuss security problems and approaches to solve them;

describe Trusted Computing, virtualisation and the OpenTC

architecture;

provide examples of the development of secure code using OpenSSL

and the TPM/TSS;

describe the design and evaluation process of Trusted Software.

Learning
Outcomes:

On successful completion of this course students will be able to:

describe and evaluate common security problems in computing;

discuss the applicability of cryptographic techniques to security
problems;

describe the advances achieved by Trusted Computing;

describe the OpenTC Architecture;

use XEN/L4 to start virtualised instances of Linux;

use both OpenSSL and the TPM/TSS to write secure code on the Linux

platform;

access and make use of international standards related to security to

design and evaluate Trusted Software.

Course Content:

The course will cover the following main topics:

evaluation of security problems in information technologies and
examination of solutions using cryptographic techniques;

using OpenSSL for secure programming;

definition of Trusted Computing;

approaches to Trusted Computing;

secure OS Fundamentals;

SELinux, Vista, Trusted BSD;

virtualisation and applications;

XEN and L4;

OpenTC Architecture;

TPM/TSS Development;

design and evaluation of Trusted Software.

The lecture plan is as follows:

Lecture 1: Information technologies and security problems;

Lecture 2: Cryptographic basics;

Lecture 3: OpenSSL;

Lecture 4: OpenSSL;

Lecture 5: Trusted Computing;

Lecture 6: Approaches to Trusted Computing;

Lecture 7: Secure OSs;

Lecture 8: Virtualisation and Applications;

Lecture 9: XEN and L4;

Lecure 10: OpenTC Architecture;

Lecture 11: TPM/TSS Development;

Lecture 12: TPM/TSS Development;

Lecture 13: TPM/TSS Development;

Lecture 13: TPM/TSS Development;

Lecture 14: Design and evaluation of Trusted Software.

There   will   be   at   least   two   written   assignments.   It   is   expected   that   the

assignments eliminate any open issues and enable the student to utilise

the theoretical background gained in the lectures.

Open_TC Deliverable 10.4

19/40

background image

Training Concepts and Training Plans

1.0 Final

Teaching &
Learning
Methods:

The course will be delivered through 14 3-hour lectures. For each lecture, a
reading assignment list will be distributed to students. The references of
these assignments will be mainly from the key bibliography but will also
include papers and web sites.
There will be one midterm exam and one comprehensive final exam that
covers the lectures and reading assignments.
The students will also be given at least two written assignments. One of
them will focus on more theoretical aspects of security and one will require
the student to develop C code that makes use of the TPM/TSS.

Key
Bibliography:

1.

C. J. Mitchell (ed.),

Trusted Computing

.  IEE Press, 2005.

2. S. Pearson (ed.), Trusted Computing Platforms: TCPA Technology in

Context, Prentice Hall PTR, 2002

3. S. Barman (ed.), Writing Information Security Policies, New Riders

Publishing, 2001

4. W. Stallings, Network and Internetwork Security, IEEE Press, 1995

Formative
Assessment and
Feedback:

An evaluation sheet will be distributed at the end of the course to assess
the   student's   opinion   of   the   course,   the   course   material,   exams   and
assignments, and the instructor.

Summative
Assessment:

1 Written midterm exam (%25)
1 Written final exam (%40)
2 or more assignments (%35)

4.2  RHUL

At Royal Holloway, we are currently preparing to deliver an 11-week course on Trusted
Computing. The course will be delivered as part of the MSc in Information Security,
and will consist of eleven 3- hour sessions.

The main lectures will be delivered by Eimear Gallery and Stephane Lo Presti. One
lecture will also be delivered by Graeme Proudler (HP/TCG) on Trusted Computing and
the TCG, and one by Steven Hand (CUCL) on XEN and the art of virtualisation.

In  section  4.3.1  the  course  unit proposal  is  presented.  In  section  4.3.2  the  course
specification description is given.  Finally, in section 4.3.3, the individual lecture plans
are outlined.

4.2.1  Course unit proposal

The form below describes the new Higher Education Masters level course, which has
been proposed as an addition to the Royal Holloway MSc in Information Security, and
which will be offered every year starting in the 2006/07 academic year.  This course
proposal has been approved by the Department Board and resources are being made
available in the department(s) to support it.

1. Nature of the proposal

[x] to validate a new course
unit

   to  amend  an  existing  course

unit

  to withdraw a course unit

Open_TC Deliverable 10.4

20/40

background image

Training Concepts and Training Plans

1.0 Final

with effect from: September 2006

Changes to the title, learning outcomes and aims, delivery, assessment, organisation (including
the balance of contact time, assessment and independent study) and requirements for pre-/co-
requisites in an existing course must be validated in advance by the College.

2. Course code:

 IY5608

Please seek advice from the Examinations and
Timetabling Office (ext. 4392) before assigning
a code to a new course unit.

*3. Course unit value:

 110 hours (0.5)

For  UG  courses,  indicate  the  unit  value  (not
less  then  0.5).    For  PG  courses,  indicate  the
number of notional learning hours.

4. Course title

 (max 70 chars): Trusted Computing

*5.

 Academic

level:

  HE Certificate level

  HE Intermediate level

  HE Honours level

[x]  HE Masters level

  Sub-HE level

The academic level of the course unit is determined in reference to the QAA Framework for
Higher  Education  Qualifications  in  England,  Wales  and  Northern  Ireland,  available  at
www.qaa.ac.uk

*6.Student
numbers:

1st year of operation

2nd year of operation

3rd year of
operation

30

30

30

Provide a realistic estimate of new enrolments during the first three years of operation. Note
that minimum thresholds apply as follows: HE Certificate level (15); HE Intermediate level (8);
HE Honours level (4); HE Masters level (4).

*7. Course team:

Professor Chris Mitchell

Indicate  course  leader  with  asterisk. S/he  will  be  responsible  for  delivery  of  the  course  and
completion of the annual Course Report Form, and will be expected to attend the validation
meeting if required by the Chair.

8. Programme(s) for which the course is chiefly intended:



MSc in Information Security

*9. Pre-requisites:

 Core courses on MSc

*10. Co-requisites:

 None

11. Rationale for the proposal

a) What are the rationale and aims of the proposal in the context of existing and proposed
programmes?  Refer  to  evidence  such  as  student  feedback,  Visiting  Examiners’  reports  and
external benchmarks as appropriate.

The RHUL MSc in Information Security has been highly successful, and continues to attract large
numbers of students.  However, although the course was groundbreaking, in recent years a
number of competitive offerings have emerged.  It is imperative for the future success of the
Royal Holloway Information Security MSc that we continue to distinguish it from the rest of the
market in terms of the quality and diversity of provision, made possible by the unique quality
and  range  of  our  staff.    This  will  require  the  development  of  optional  courses  in  new  and
emerging security technologies, of which this is intended to be a prime example.

Not only is trusted computing a potentially fundamentally important technology for the future of
secure  computing,  and  hence  worthy  of  an  MSc  course  for  that  reason  alone,  but  our
participation in the OpenTC 6th Framework Integrated Project gives us a unique opportunity to
combine research expertise with masters level teaching.  Part of the Royal Holloway budget for

Open_TC Deliverable 10.4

21/40

background image

Training Concepts and Training Plans

1.0 Final

this project requires us to commit over a man-year to training activities relevant to the project.
Developing and giving this course is one of the main planned activities within this part of the
project.  As a result the development of this course will have a minimal resource impact.

*b) For course amendments, summarise briefly the proposed change in reference to the course
unit specification.

Not applicable (this is a new course).

12. Likely impact of the proposal

a) What are the implications for the curriculum in terms of student choice, pathways in existing
programmes and the range of subjects on offer? For new course proposals, is it intended that
the proposed course should replace any existing course units?

This course will run in addition to existing optional courses (although optional courses may be
discontinued over time if demand disappears or if the subject matter is deemed to be no longer
of great importance).

*b) What additional learning resources (library, computing and web-based materials), specialist
equipment  and/or  teaching  space  will  be  required,  and  how  are  these  to  be  provided  from
existing departmental allocations?

Teaching space will be required for a total of eleven 3-hour lectures in the spring term.  We
currently anticipate teaching the course on Friday mornings.

*c) What are the other types of expenditure arising from the proposal (e.g. field trips), and how
will these be funded?

No major impact.  We anticipate that this course may require access to teaching laboratory
space, although such space is already provided as part of the MSc.  There may also be some
minor travelling expenses for visiting speakers.

*13. Collaborative arrangements

a) Provide names and contact information for any organisations outside Royal Holloway which
would be involved in the organisation, delivery or assessment of the course unit.

The course would not be dependent on any outside bodies; that is, the course will be designed
to so it can be delivered entirely using college staff.  However, to increase the range of expertise
available, we plan to call on our collaborative partners in industry and academia to give a small
number of presentations on the course (up to around 25% of the total).  Currently, we have no
definite  plans  about  the  identities  of  these  organisations  and,  as  stated  above,  we  will  not
depend on their contribution.

b)  Describe  the  nature  and  extent  (as  a  percentage  of  the  programme)  of  each  partner’s
intended involvement.

We would anticipate up to three outside organisations (companies and/or universities) giving
one eleventh of the course material each (i.e. one week’s lectures).

c) Provide a brief rationale for the proposed collaboration, which should take into account each
partner’s size, sphere of influence, range of activities, standing among professionals in the field
and existing links with Royal Holloway and other bodies.

The development of this course will be funded by a European Union 6th Framework Integrated
Project, called OpenTC.   This project has over 20 partners in a variety of European countries.
The outside lectures would call upon the wide range of expertise on trusted computing available
in these partner organisations.  Indeed, we could claim to have almost all the main European
players in trusted computing within this project.

Collaborative courses are subject to additional scrutiny during validation and are regulated by
institutional contracts. No department or individual may enter into a formal understanding or

Open_TC Deliverable 10.4

22/40

background image

Training Concepts and Training Plans

1.0 Final

agreement with an external partner in regard to an accredited course unit without the prior
approval of the Academic Board.

4.2.2  Course specification

The form reproduced below contains the course specification.  This includes a
statement of the aims of the course, as well as the learning outcomes and the
syllabus.

Code:

IY5

60

8

Course

Value:

0.5

Status:

ie:Core, or Optional

Optional

Title:

Trusted Computing

Availability:

(state which

teaching terms)

Spring term

Prerequisites:

Core Msc courses

Recommended:

Co-ordinator:

Chris Mitchell

Course Staff:

Eimear Gallery, Stephane Lo Presti and Chris Mitchell

Aims:

This course will:

provide a basic introduction to trusted computing;

discuss how trusted computing ideas might assist with the future

development of secure systems;

describe the basic hardware and software technologies underlying

trusted computing;

give an appreciation of how virtualisation and isolation, with

appropriate hardware support, can provide a trusted environment in

which to run sensitive applications;

discuss possible applications of trusted computing technology.

Learning
Outcomes:

On successful completion of this course students will be able to:

understand the fundamental principles behind trusted computing;

work with the TCG specifications;

have an appreciation of the range of possible trusted hardware and

software;

understand what trusted computing can do to improve system and

user security (and what it cannot do);

analyse and assess possible applications of trusted computing.

Course Content:

The course will cover the following main topics.

What is trusted computing?  An introduction to the fundamental ideas

underlying trusted computing technology.

The Trusted Computing Group (TCG) specifications: history, objectives,

the v1.2 specifications, and profiles for various platform types.  This

will include a discussion of both the hardware base for the TCG

specifications, namely the TPM, and also the supporting software (TSS

etc.).

Trusted computing hardware architectures, e.g. including the Intel,

ARM and AMD processor extensions, AEGIS, XOM, etc.

Software architectures to exploit trusted computing hardware, to

include coverage of isolation kernels, virtualisation, secure boot, etc.

Examples of TCG software architectures, including NGSCB, Xen and L4.

Selected applications of trusted computing, such as:

o

application security support through trusted computing;

o

content protection;

o

mobile device security functions;

o

other selected applications.

Teaching &
Learning
Methods:

The course will be delivered through 11 three-hour sessions.  The main
lectures will be delivered by ISG staff, although a small number of lectures
on specialist topics may be delivered by industry or external academic
experts.  All lectures will provide opportunities for questions and further
discussion.  Students are expected to attend the lectures and to ask

Open_TC Deliverable 10.4

23/40

background image

Training Concepts and Training Plans

1.0 Final

questions and to discuss the subject matter with the lecturer.  Students are
also expected to engage in appropriate private study.

Key
Bibliography:

C. J. Mitchell (ed.),

Trusted Computing

.  IEE Press, 2005.

Formative
Assessment and
Feedback:

This module will include non-assessed coursework which students are
expected to complete and submit.  Answers will be marked and returned
with feedback.

Summative
Assessment:

Exam

 100(%)  This course is assessed solely by written examination

consisting of a two-hour-exam. There will be five questions of equal value
on the examination paper.  Three questions may be attempted.

Coursework

0(%)  Coursework does not contribute to the final assessment

for this course.

Deadlines:

 The written examination will be held in the Summer term

4.2.3 Lecture plans

This section contains lecture plans for each of the eleven 3-hour lectures which will
make up the course.  The lectures will be delivered during the spring term of 2007 (i.e.
between January and April 2007).

Lecture

1

Author

Graeme Proudler

E-mail Address

gjp@hplb.hpl.hp.com

Institution

Hewlett-Packard

Course

MSc in Information Security / Trusted Computing (IY5608)

Duration

3 hours

Subject

An Introduction to Trusted Computing

Prerequisites

Core MSc courses

Aims

The lecture will:

provide a brief background to trusted computing;

discuss the concept of trust in the context of trusted computing;

describe at a high level the benefits of trusted computing;

provide a general overview of the fundamental trusted computing
concepts – integrity measurement, authenticated boot, attestation and
protected storage;

describe the roots of trust – RTM, RTS, RTR;

describe the CRTM and the TPM; and

provide a basic introduction to the TCG.

Learning
Outcomes

On successful completion of this lecture, students will be able to:

understand the evolution of Trusted Computing;

have an appreciation of the concept of trust in the context of trusted
computing;

describe at a high level the benefits of trusted computing;

understand the fundamental trusted computing concepts;

describe the purpose/functionality of the roots of trust – RTM, RTS, RTR;

understand how the roots of trust are implemented – i.e. have an
appreciation of CRTM and TPM functionality; and

have an awareness of TCG activities.

Open_TC Deliverable 10.4

24/40

background image

Training Concepts and Training Plans

1.0 Final

Lecture Content

This lecture will cover the following main topics:

the background to Trusted Computing;

trust as implemented in Trusted Computing;

the incremental benefits of Trusted Computing;

an introduction to the fundamental technological principles of Trusted
Computing;

the RTM, RTS, RTR;

the CRTM and TPM; and

the Trusted Computing Group (TCG): organisation, specifications.

Teaching
materials

Lecture/guided discussion through OpenDocument/PowerPoint presentation.
Students are expected to attend the lecture, to ask questions and to discuss
the subject matter with the lecturer.
Students are also expected to engage in appropriate private study.

Bibliography

The TCG specification set (www.trustedcomputinggroup.org).
B. Balacheff, L. Chen, S. Pearson, D. Plaquin, G. Proudler, Trusted Computing
Platforms: TCPA Technology in Context.  Prentice Hall PTR, 2002.
C. J. Mitchell (ed.), Trusted Computing.  IEE Press, 2005.

Lecture

2

Author

Eimear Gallery

E-mail Address

e.m.gallery@rhul.ac.uk

Institution

Royal Holloway, University of London

Course

MSc in Information Security / Trusted Computing (IY5608)

Duration

3 hours

Subject

The CRTM and TPM v1.2: part 1 (Work completed by TPM, TSS, Infrastructure
and PC client working groups)

Prerequisites

Core MSc courses and lecture 1

Aims

The lecture will:

describe at a high level the objectives of the TCG working groups –  TPM,
TSS Infrastructure, PC client, TNC, Server, Storage, Mobile;

define the TP architecture components – the CRTM, the TPM, and the
TSS;

define the CRTM;

describe the TPM v1.2 architecture;

specify the critical entities involved in TP use and endorsement;

describe the endorsement key pair and its purpose;

explore the set of required platform credentials;

specify how a platform is initialised, enabled, activated, taken ownership
of, and cleared.

define an attestation identity key and its purpose;

describe the process by which a platform acquires an attestation identity
key;

explore the authenticated boot process;

examine the authenticated boot process for a conventional PC BIOS;

investigate platform attestation;

analyse the privacy issues surrounding traditional platform attestation;
and

briefly examine DAA.

Open_TC Deliverable 10.4

25/40

background image

Training Concepts and Training Plans

1.0 Final

Learning
Outcomes

On successful completion of this lecture, students will be able to:

describe the objectives/purpose of each TCG WG;

list the components of a TP;

describe the CRTM and the TPM v1.2 architecture;

list, and describe the function of, the critical entities involved in TP use
and endorsement;

define the purpose and use of an endorsement key pair;

have an appreciation for the credential set required by a TP;

describe how a TPM is initialised, enabled, activated, taken ownership of,
cleared;

define the purpose and use of an attestation identity key pair;

define the process by which an attestation identity key pair can be
acquired by a platform;

understand the authenticated boot process and have an appreciation as
to how this process is implemented on a conventional PC BIOS;

describe platform attestation;

have an appreciation for the privacy issues associated with the
traditional platform attestation mechanism; and

have an awareness of DAA.

Lecture Content

This lecture will cover the following main topics:

the TCG working group objectives;

a TP – its functional components and entities involved in its use and
endorsement;

the CRTM;

the TPM v1.2 – its architecture, certification, initialisation, enablement,
activation, ownership, clearance;

authenticated boot – its implementation on a conventional PC BIOS; and

platform attestation.

Teaching methods
and materials

Lecture/guided discussion through OpenDocument/PowerPoint presentation.
Students are expected to attend the lecture, to ask questions and to discuss
the subject matter with the lecturer.
Students are also expected to engage in appropriate private study.

Bibliography

The TCG specification set (www.trustedcomputinggroup.org).
B. Balacheff, L. Chen, S. Pearson, D. Plaquin, G. Proudler, Trusted Computing
Platforms: TCPA Technology in Context.  Prentice Hall PTR, 2002.
C. J. Mitchell (ed.), Trusted Computing.  IEE Press, 2005.

Lecture

3

Author

Eimear Gallery

E-mail Address

e.m.gallery@rhul.ac.uk

Institution

Royal Holloway, University of London

Course

MSc in Information Security / Trusted Computing (IY5608)

Duration

3 hours

Subject

The CRTM and TPM v1.2 part 2 (Work completed by TPM, TSS, Infrastructure
and PC client working groups)

Prerequisites

Core MSc courses and lectures 1 and 2

Open_TC Deliverable 10.4

26/40

background image

Training Concepts and Training Plans

1.0 Final

Aims

The lecture will:

describe the protected storage capabilities of a TPM – key generation,
key certification, key loading, binding and sealing;

describe the process of key migration;

define TPM authorisation mechanisms;

examine transport protection;

describe the TPM delegation model;

investigate the TPM time-stamping capabilities;

explore TPM audit;

investigate TPM maintenance; and

describe at a high level the TSS.

Learning
Outcomes

On successful completion of this lecture students will be able to:

understand the protected storage capabilities of the TPM v1.2;

have an appreciation of the key migration process;

understand TPM authorisation, covering physical presence and the
authorisation protocols;

describe transport protection;

understand the TPM delegation model;

outline TPM time-stamping capabilities;

have an appreciation for TPM audit and maintenance functionality; and

have an awareness of the TSS.

Lecture Content

This lecture will cover the following main topics:

TPM v1.2 protected storage;

TPM v1.2 key migration;

TPM v1.2 authorisation;

TPM v1.2 transport protection;

TPM v1.2 delegation;

TPM v1.2 time-stamping;

TPM v1.2 audit and maintenance; and

The TSS v1.2.

Teaching methods
and materials

Lecture/guided discussion through OpenDocument/PowerPoint presentation.
Students are expected to attend the lecture, to ask questions and to discuss
the subject matter with the lecturer.
Students are also expected to engage in appropriate private study.

Bibliography

The TCG specification set (www.trustedcomputinggroup.org),
B. Balacheff, L. Chen, S. Pearson, D. Plaquin, G. Proudler Trusted Computing
Platforms: TCPA Technology in Context. Prentice Hall PTR, 2002.
C. J. Mitchell (ed.), Trusted Computing. IEE Press, 2005.

Lecture

4

Author

Eimear Gallery

E-mail Address

e.m.gallery@rhul.ac.uk

Institution

Royal Holloway, University of London

Course

MSc in Information Security / Trusted Computing (IY5608)

Duration

3 hours

Subject

TP deployment infrastructure, TNC, SKAE (Work completed by the Infrastruc-
ture and TNC  working groups)

Prerequisites

Core MSc courses and lectures 1 – 3

Open_TC Deliverable 10.4

27/40

background image

Training Concepts and Training Plans

1.0 Final

Aims

The lecture will:

describe the TP lifecycle – manufacturing, platform delivery, deployment,
identity registration, operation, recycling and retirement;

investigate the infrastructure for TP deployment;

define the entities, assertions and signed structures involved at each TP
lifecycle stage;

explore the stages in the TP lifecycle at which particular credentials may
be generated.

define the objectives of the TNC working group;

describe the TNC architecture – entities involved, functional components,
TNC interfaces and basic message flow across interfaces;

examine the process of assessment, isolation and remediation;

describe the TNC architecture with the TPM – any additional entities and
functional components involved;

investigate the platform trust services;

examine the relationship between the TNC architecture and the TCG
integrity management model;

describe the requirement for an SKAE extension;

define the SKAE extension;

describe the process by which a certificate with an SKAE  extension can
be obtained by a TPM client; and

investigate how a TPM client can establish an authenticated session with
a server who must validate the SKAE.

Learning
Outcomes

On successful completion of this lecture students will be able to:

understand the TP lifecycle;

have an appreciation of the infrastructure required for TP deployment;

describe the entities, assertions and signed structures required at each
lifecycle stage;

outline the lifecycle stages at which particular credentials may be issued;

define the objectives of the TNC WG;

describe the TNC architecture;

understand the process of assessment, isolation and remediation;

have an appreciation for the TNC architecture with respect to platforms
which incorporate a TPM;

list the platform trust services;

describe the relationship between the TNC architecture and the TCG
integrity management model.

understand the requirement for and potential uses of an SKAE extension;

define the SKAE extension;

understand the process by which a certificate with an SKAE  extension
can be obtained by a TPM client; and

describe how a TPM client can establish an authenticated session with a
server.

Lecture Content

This lecture will cover the following main topics:

the TP lifecycle;

the TP infrastructure;

the objectives of the TNC WG;

the TNC architecture; and

the SKAE extension.

Teaching methods
and materials

Lecture/guided discussion through OpenDocument/PowerPoint presentation.
Students are expected to attend the lecture, to ask questions and to discuss
the subject matter with the lecturer.
Students are also expected to engage in appropriate private study.

Bibliography

The TCG specification set (www.trustedcomputinggroup.org),

Open_TC Deliverable 10.4

28/40

background image

Training Concepts and Training Plans

1.0 Final

Lecture

5

Author

Eimear Gallery

E-mail Address

e.m.gallery@rhul.ac.uk

Institution

Royal Holloway, University of London

Course

MSc in Information Security / Trusted Computing (IY5608)

Duration

3 hours

Subject

The Mobile TPM

Prerequisites

Core MSc courses and lectures 1 – 4

Aims

The lecture will:

define the objectives of the MPWG;

describe the MPWG use cases;

define the reference architecture for mobile trusted computing;

investigate the mobile RTM and RTV;

define a RIM and explore the secure provisioning of RIMs to a mobile
device;

describe the secure boot process;

explore MTP initialisation – SRK generation, EK generation, attestation
identity key pair generation, bootstrap counters;

describe the update and revocation of RIMs/RIM certificates;

explain post factory RIM installation/management;

describe backup, recovery, maintenance and migration of RIMs;

examine the requirements for maintaining integrity after boot; and

specify the subset of TPM v1.2 commands required by a MTPM.

Learning
Outcomes

On successful completion of this lecture students will be able to:

outline the objectives of the MPWG;

have an awareness for the MPWG use cases;

have an appreciation of the architecture for trusted mobile computing;

describe the functionality of the mobile RTM and RTV;

define a RIM and describe the process by which they are provisioned to a
mobile device;

outline the secure boot process;

have an appreciation for MTM initialisation;

understand RIM/RIM certificate update and revocation;

describe issues relating to post factory RIM management;

outline how RIMs can be backed-up, recovered, maintained and
migrated;

list the requirements for maintaining integrity after boot; and

have an appreciation for the differences between a TPM v1.2 and a
MTPM.

Lecture Content

This lecture will cover the following main topics:

the MTPM use cases;

the reference architecture for mobile trusted computing;

the secure boot process;

managing the secure boot process;

MTPM initialisation;

maintaining platform integrity after boot; and

the differences between a TPM v1.2 and a MTPM.

Teaching methods
and materials

Lecture/guided discussion through OpenDocument/PowerPoint presentation.
Students are expected to attend the lecture, to ask questions and to discuss
the subject matter with the lecturer.
Students are also expected to engage in appropriate private study.

Open_TC Deliverable 10.4

29/40

background image

Training Concepts and Training Plans

1.0 Final

Bibliography

The TCG specification set (www.trustedcomputinggroup.org),

Lecture

6

Author

Steven Hand

E-mail Address

Steven.Hand@cl.cam.ac.uk

Institution

University of Cambridge

Course

MSc in Information Security / Trusted Computing (IY5608)

Duration

3 hours

Subject

XEN and the Art of Virtualisation

Prerequisites

Core MSc courses and lectures 1 – 5

Aims

The lecture will:

describe the basic architecture/idea and historical context of security
kernels and examine some specific examples, e.g. hydra, cap;

examine multi-level secure systems: concepts and architectures;

explore previous attempts to implement multi-level secure systems, e.g.
Mach, TrustedSolaris, SELinux;

analyse why some attempts to implement multi-level secure systems
were successful and some were unsuccessful;

explore the relationship between virtualisation and trusted  computing;

examine Xen in the context of trusted computing;

have an appreciation for Xen, XenSE, OpenTC;

investigate the XenSE architecture: secure/trusted boot, policies + xsm,
off-box  management and some open issues.

Learning
Outcomes

On successful completion of this lecture students will be able to:

have an awareness of the basic architecture/idea and historical context
of security kernels and some specific examples of same, e.g. hydra, cap;

describe the concepts and architectures relating to multi-level secure
systems;

have an appreciation of previous attempts to implement multi-level
secure systems, e.g. Mach, TrustedSolaris, SELinux;

have an awareness of why some attempts to implement multi-level
secure systems were successful and some were unsuccessful;

understand the relationship between virtualisation and trusted
computing;

have an understanding of Xen in the context of trusted computing;

have an appreciation for Xen, XenSE, OpenTC; and

describe the XenSE architecture: secure/trusted boot, policies + xsm,
off-box  management, open issues.

Lecture Content

This lecture will cover the following main topics:

security kernels: basic architecture/idea; historical context (hydra, cap,
etc);

multi-level secure systems: concepts and architectures;

previous attempts both successful and not (and why?) - Mach,
TrustedSolaris, SELinux;

VMs + trusted computing - maybe something on NetTop?

Trusted computing + Xen: XenSE, OpenTC- why now, what's different
(what's not); and

XenSE architecture: secure/trusted boot, policies + xsm, off-box
management, open issues.

Open_TC Deliverable 10.4

30/40

background image

Training Concepts and Training Plans

1.0 Final

Teaching methods
and materials

Lecture/guided discussion through OpenDocument/PowerPoint presentation.
Students are expected to attend the lecture, to ask questions and to discuss
the subject matter with the lecturer.
Students are also expected to engage in appropriate private study.

Bibliography

To be announced.

Lecture

7

Author

Stephane Lo Presti

E-mail Address

Stephane.Lo-Presti@rhul.ac.uk

Institution

Royal Holloway, University of London

Course

MSc in Information Security / Trusted Computing (IY5608)

Duration

3 hours

Subject

Next generation of hardware platforms

Prerequisites

Core MSc courses and lectures 1 – 6

Aims

The lecture will:

describe the new major hardware platform architectures;

examine their security components and understand to which element of
trusted computing they correspond;

compare the new functionalities with trusted computing.

Learning
Outcomes

On successful completion of this lecture, the students will be able to:

describe the improvement added to new hardware architectures;

identify the significant security elements;

relate the security elements to the TCG specifications.

Lecture Content

The lecture will cover the following main topics:

Intel LaGrande;

AMD Pacifica;

ARM TrustZone.

Teaching methods
and materials

Lecture/guided discussion through OpenDocument/PowerPoint presentation.
Students are expected to attend the lecture, to ask questions and to discuss
the subject matter with the lecturer.
Students are also expected to engage in appropriate private study.

Bibliography

D. Grawrock, The Intel Safer Computing Initiative. Intel Press, 2006.
C. J. Mitchell (ed.), Trusted Computing. IEE Press, 2005.

Lecture

8

Author

Stephane Lo Presti

E-mail Address

Stephane.Lo-Presti@rhul.ac.uk

Institution

Royal Holloway, University of London

Course

MSc in Information Security / Trusted Computing (IY5608)

Duration

3 hours

Subject

Trusted Computing Applications, part 1 (Operating Systems)

Prerequisites

Core MSc courses and lectures 1 – 7

Aims

The lecture will:

present how Operating Systems are using trusted computing;

describe how trusted computing improves these Operating Systems.

Open_TC Deliverable 10.4

31/40

background image

Training Concepts and Training Plans

1.0 Final

Learning
Outcomes

On successful completion of this lecture, the students will be able to:

understand the use of trusted computing at the Operating System level;

describe how Operating Systems are secured or made more trustworthy
by trusted computing.

Lecture Content

The lecture will cover the following main topics:

Open Trusted Computing;

NGSCB;

Trusted/SEcure Unixes.

Teaching methods
and materials

Lecture/guided  discussion  through  OpenDocument/PowerPoint  presentation
and OpenTC demonstration.
Students are expected to attend the lecture, to ask questions and to discuss
the subject matter with the lecturer.
Students are also expected to engage in appropriate private study.

Bibliography

B. Balacheff, L. Chen, S. Pearson, D. Plaquin, G. Proudler Trusted Computing
Platforms: TCPA Technology in Context. Prentice Hall PTR, 2002.
C. J. Mitchell (ed.), Trusted Computing. IEE Press, 2005.

Lecture

9

Author

Stephane Lo Presti

E-mail Address

Stephane.Lo-Presti@rhul.ac.uk

Institution

Royal Holloway, University of London

Course

MSc in Information Security / Trusted Computing (IY5608)

Duration

3 hours

Subject

Trusted Computing Applications, part 2 (Applications)

Prerequisites

Core MSc courses and lectures 1 – 8

Aims

The lecture will:

examine several software applications that use trusted computing;

analyse how trusted computing improves the application security and/or
trustworthiness.

Learning
Outcomes

On successful completion of this lecture, the students will be able to:

understand the use of trusted computing at the application level;

describe how applications are secured or made more trustworthy by
trusted computing.

Lecture Content

The lecture will cover the following main will:

DRM;

Secure banking;

Windows Vista BitLocker

Grid and Peer-to-Peer Computing.

Teaching methods
and materials

Lecture/guided  discussion  through  OpenDocument/PowerPoint  presentation
and application demonstrations .
Students are expected to attend the lecture, to ask questions and to discuss
the subject matter with the lecturer.
Students are also expected to engage in appropriate private study.

Bibliography

B. Balacheff, L. Chen, S. Pearson, D. Plaquin, G. Proudler Trusted Computing
Platforms: TCPA Technology in Context. Prentice Hall PTR, 2002.
C. J. Mitchell (ed.), Trusted Computing. IEE Press, 2005.

Lecture

10

Open_TC Deliverable 10.4

32/40

background image

Training Concepts and Training Plans

1.0 Final

Author

Stephane Lo Presti

E-mail Address

Stephane.Lo-Presti@rhul.ac.uk

Institution

Royal Holloway, University of London

Course

MSc in Information Security / Trusted Computing (IY5608)

Duration

3 hours

Subject

Technologies and Approaches related to Trusted Computing

Prerequisites

Core MSc courses and lectures 1 – 9

Aims

The lecture will:

provide an overview of various other technologies related to trusted
computing;

compare these approaches with the TCG approach.

Learning
Outcomes

On successful completion of this lecture, the students will be able to:

have a broader overview of trusted computing;

describe alternative approaches to trusted computing;

compare the various approaches.

Lecture Content

The lecture will cover the following main topics:

XOM;

AEGIS;

EMSCB;

Trust management.

Teaching methods
and materials

Lecture/guided discussion through OpenDocument/PowerPoint presentation.
Students are expected to attend the lecture, to ask questions and to discuss
the subject matter with the lecturer.
Students are also expected to engage in appropriate private study.

Bibliography

B. Balacheff, L. Chen, S. Pearson, D. Plaquin, G. Proudler Trusted Computing
Platforms: TCPA Technology in Context. Prentice Hall PTR, 2002.
C. J. Mitchell (ed.), Trusted Computing. IEE Press, 2005.

Lecture

11

Author

Stephane Lo Presti

E-mail Address

Stephane.Lo-Presti@rhul.ac.uk

Institution

Royal Holloway, University of London

Course

MSc in Information Security / Trusted Computing (IY5608)

Duration

3 hours

Subject

Trust and the Future of Trusted Computing

Prerequisites

Core MSc courses and lectures 1 – 10

Aims

The lecture will:

provide an overview of the notion of trust from a multidisciplinary point
of view;

discuss the relationship between trust and security;

discuss how trusted computing facilitates the establishment and
provision of trust;

examine the limits of trusted computing;

discuss the future of trusted computing.

Open_TC Deliverable 10.4

33/40

background image

Training Concepts and Training Plans

1.0 Final

Learning
Outcomes

On successful completion of this lecture, the students will be able to:

understand the concept of trust outside of the context of trusted
computing and identify its various facets;

compare the notions of security and trust and understand how they
relate;

describe the benefits and drawbacks of the various aspects of trusted
computing and its alternatives.

Lecture Content

The lecture will cover the following main topics:

multidisciplinary point of view on trust (sociology, psychology, economy,
management, legal);

trust and security;

trust in the context of trusted computing;

the future of trusted computing.

Teaching methods
and materials

Lecture/guided discussion through OpenDocument/PowerPoint presentation.
Students are expected to attend the lecture, to ask questions and to discuss
the subject matter with the lecturer.
Students are also expected to engage in appropriate private study.

Bibliography

B. Balacheff, L. Chen, S. Pearson, D. Plaquin, G. Proudler Trusted Computing
Platforms: TCPA Technology in Context. Prentice Hall PTR, 2002.
C. J. Mitchell (ed.), Trusted Computing. IEE Press, 2005.

4.3 TEC

Technikon's  training  concept  foresees  several  different  contributions  to  future
educational activities in Trusted Computing. During the first year we worked on the
following three topics:

1) Library Concept for Trusted Computing

Trusted computing is a new expanding research area. We researched the different
books  available  in  public  stores.  The  books  were  analyzed  in  respect  to  technical
content, technical level and usability for course preparation work.
The books identified are displayed on the internal OpenTC website and will be made
publicly  available  in  the  future  as  a  dynamic  list.  Every  OpenTC  partner  can  add
additional  entries  and  comment  using  a  Wiki-style  editor.  Illustration  1  shows  a
snapshot of the library webpage.

Open_TC Deliverable 10.4

34/40

background image

Training Concepts and Training Plans

1.0 Final

2) Preconceptions on Trusted Computing

A major  obstacle  to the popularity  of courses  on Trusted Computing  might be  the
preconception  of  persons  towards  the  known  and  unknown  features  of  trusted
computing. Technikon prepared and headed a case study on this topic with students
of  the  master  program  in  Innovation  engineering  at  the  Halmstad  University  in
Sweden, developed during a three days workshop in October 2006. The students were
divided in groups and were asked to take the position for the following four groups:
SME, Industry, Governmental Body and an individual not related to any group. The
students did not have any prior knowledge on trusted computing. They were given
hints on locations for public information. The goal was to identify the major impact
factors and risk contribution factors for the four individual groups. The results were be
made available to the OpenTC consortium via the SVN repository. It could be shown
that even with non-biased information on trusted computing the students tended to
absorb  in  high  proportions  critical  information  on  trusted  computing  threads.  The
following  table  shows  different  contributing   factor   diagram   derived   by   students   at
Halmstad University.

Open_TC Deliverable 10.4

35/40

Illustration 1: Screen Shot of internal Trusted Computing book list

background image

Training Concepts and Training Plans

1.0 Final

Table 1:

 Contribution Factor Diagram for Private, SMEs, Industry and Governmental Users

(Workshop at Halmstad University October 2006)

3) Course Development for Austrian Universities
Technikon presented a course on OpentTC developed for Austrian Universities. It is
planned to have a 3 to 4 days course on Trusted Computing Research. The course is
composed of 2 days of lectures and 1 day of practical work in teams, with finally half a
day  of  examination  including  presentations  of  research  results  from  the  students.
Lecturers are Dr. Klaus-Michael Koch, Dipl. Ing. Herbert Petautschnig, MSC Joel Björk.
The course will be taught in English. The course outline is the following:

a) Concepts and security technologies of Trusted Computing

- PC and server (examples);
- mobile applications (examples);
- embedded systems (examples from the automotive and aviation industries);

b) State-of-the-art developments

- operating systems (Vista, Linux, SunOS,..);
- TPM (version 1.2, outline of future possible developments)

Open_TC Deliverable 10.4

36/40

background image

Training Concepts and Training Plans

1.0 Final

- virtualisation

c) Practical exercises

- Trusted boot with microkernel;
- proof of concept applications;
- parameterising and securing of certificates and keys;

d) Final exam

- presentation of the exercise results;
- questions.



4) Professional Documentation for OpenTC
Technikon intends to contribute its expertise in professional technical documentation
to the creation of an overall description to be added to the final OpenTC software
distribution. Our proposal is to use for the OpenTC documentation framemaker Version
7.x , a professional desktop top publishing tool from Adobe together with OpenOffice.
Work on this topic will start in month 25.

4.4 TUB

TUBITAK has prepared aa 14-week course on Trusted Computing, to be presented at
the  University  of  Galatasary  Computer  Engineering  Department  during  the  Spring
semester.  The  course  is  planned  to  be  delivered  as  a  part  of  an  undergraduate
elective course where we expect to have between 10 and 20 students.

The course will be consisting of 3 hour lectures each week, with a total of 39 hours.
There  will  be  one  midterm,  and  one  final  examination.  The  course  content,
prerequisites, aims and course resources are described below.

Name of the course:

 Trusted Operating System Architectures

Prerequisites:

The students should have knowledge of operating systems, computer

architecture and object oriented programming.

Aims

In this course,

An introduction to trusted computing will be given,

The  hardware  and  software  components  and  solutions  used  in  trusted
computing will be identified,

Virtualization, isolation and future state-of-the-art models will be presented,

Hardware  and  software  solutions  that  will  benefit  from  and  utilise  trusted
computing technologies will be examined,

Students will be given programming assignments to learn the basics of trusted
computing.

Course materials

For the course material, Trusted Computing book by Chris Mitchell (IEEE, 328 pages,
English,  ISBN:  0863415253)  will  be  used.  As  a  supplementary,  Trusted  Computing
Platforms  (TCPA  technology  in  context)  by  Siani  Pearson  and  Trusted  Computing
Platforms (Design and Applications) by Sean W. Smith will be used.

Format of the course

This 3-credit elective course will last for 14 weeks, featuring 3 hours a week. For the
first 4 weeks, theoretical points will be discussed. The 5

th

 week will be devoted to a

Open_TC Deliverable 10.4

37/40

background image

Training Concepts and Training Plans

1.0 Final

programming  assignment  which  aims  to  make  students  understand  basic  trusted
computing  components.  In  the  6

th

 week, each  student  will  be  selecting a research

topic  and notify the instructor.  A report  and a presentation  on this subject will be
prepared and submitted at the end of the semester. The first examination will be held
on the 8

th

 week. Another programming assignment will be given on the 11

th

 week.

Both assignments will require writing programming code as well as a written report.
The course will be composed of 13 weeks of lectures, 2 programming assignments, 1
presentation, 1 midterm examination and 1 final examination.

Assessment

1

st

 programming assignment: 8% (code: 4%, report: 4%)

2

nd

 programming assignment: 12% (code: 6%, report: 6%)

1

st

 midterm examination: 20%

Research project presentation: 10%
Research project report: 10%
Final examination: 40%
Total: 100%

4.5  IAIK

IAIK has announced a summer-term class on trusted computing that will start in March
2007.  The following table contains the information available through the universities
on line course information system. A detailed course schedule will be available soon.

Course-ID:

705.052 (VO) 705.053 (KU)

Status:

ie:Core, or Optional

Optional

Title:

AK IT-Sicherheit 1

Semester:

SS 2007

Prerequisites:

None, but knowledge of the topics

discussed in IT-Security and

Applied Cryptography
are strongly recommended

Language:

English

Co-ordinator:

Peter Lipp

Course Staff:

Kurt Dietrich, Martin Pirker, Thomas Winkler

Aims:

This course will:

provide an introduction to the topics that TC is based on where

necessary (like cryptography);

provide a basic introduction to trusted computing;

discuss the importance and role of trusted computing for future secure

systems;

describe the basic hardware and software technologies underlying

trusted computing;

explore the concepts of virtualisation and isolation, which play an

important role in future trusted environments;

discuss possible applications of trusted computing technology.

Learning
Outcomes:

Students will learn to understand the concepts of trusted computing, the
technology involved and its applications. They will appreciate that trusted
computing is not the basis for all evil and can be used to achieve security
not  achievable  without  it.  Students  will  be  able  to  set  up  and  run  PCs
equipped with trusted platform modules. They will learn how to make use
of  TC-features  within  an  application  environment.  In  practical  exercises
they  will  learn  to  design  application  scenarios  making  use  of  trusted
computing technology.

Open_TC Deliverable 10.4

38/40

background image

Training Concepts and Training Plans

1.0 Final

Course Content:

The course will cover the following main topics.

What is "Trusted Computing"?;

The Trusted Platform and its properties;

The life-cycle of a trusted platform;

Platform identification and certification;

Integrity measuring, recording and reporting;

Protected Storage;

Transport Security;

Delegation;

Migration;

Virtualisation and Trusted Computing;

The Next Generation Secure Computing Base;

LaGrande;

Applications of Trusted Computing.

Teaching &
Learning
Methods:

The  course  will  be  delivered  through  14  two-hour  sessions.    The  main
lectures   will   be   delivered   by   IAIK   staff,   a   small   number   of   lectures   on
specialist  topics  may  be  delivered  by  industry  or  external  academic
experts.  Depending on the attendance, special topics will be presented by
students as part of the exam work.

Key
Bibliography:

Chris Mitchell (ed.),

Trusted Computing

.  IEE Press, 2005.

David Grawrock, The Intel Safer Computing Initiative; Intel Press 2006.
Public Standards of the TCG.

Exercises

Students will do practical programming exercises on workstations equipped
with a TPM and/or on simulated TPMs. They will learn how to set up a
trusted computing platform and develop applications that make use of TPM
features.

Open_TC Deliverable 10.4

39/40

background image

Training Concepts and Training Plans

1.0 Final

5 List of Abbreviations

AACP

Asymmetric Authorization Change Protocol

ACL

Access Control List

ADCP

Authorization Data Change Protocol

AIK

Attestation Identity Key

BMI

Basic Management Interface

CA

Certification Authority

CMI

Common Information Model

DAA

Direct Anonymous Attestation

DRM

Digital Rights Management

LO

Learning Objective

MCG

Major Course Goal

OIAP

Object-Independent Authorization Protocol

OS

Operating System

OSAP

Object-Specific Authorization Protocol

P2P

Peer-to-Peer

PCR

Platform Configuration Register

RIM

Reference Integrity Metric

RTM(S,R)

Root of Trust for Measurement (for Storage, for Reporting)

SOAP

Simple Object Access Protocol

SRK

Storage Root Key

TCG

Trusted Computing Group

TCS

TCG Core Service

TCSI

TCG Core Service Interface

TDD

TPM Device Driver

TDDLI

TPM Device Driver Library Interface

TPM

Trusted Platform Module

TSPI

TCG Service Provider Interface

TVL

Trusted Virtualization Layer

TSS

Trusted Software Stack

UUID

Universal User Identity

VM(M)

Virtual Machine (Monitor)

Open_TC Deliverable 10.4

40/40
