TRUSTED COMPUTING TECHNOLOGIES AND THEIR USE IN THE PROVISION OF
HIGH ASSURANCE SDR PLATFORMS
Eimear Gallery (Royal Holloway, University of London, Egham, Surrey, TW20 0EX, UK;
e.m.gallery@rhul.ac.uk); and Chris Mitchell (Royal Holloway, University of London, Egham, Surrey,
TW20 0EX, UK; c.mitchell@rhul.ac.uk).
ABSTRACT
This paper introduces the concept of trusted computing, and
highlights the ways in which it may be leveraged to enable
the provision of high assurance Software Defined Radio
(SDR) platforms.
1. INTRODUCTION
A software defined radio is a communications device
“whose operational modes and parameters can be changed
or augmented, post manufacturing via software” [1]. This
implies that the device can be reconfigured to communicate
using multiple frequency bands and protocols, or upgraded
in a low cost and efficient manner. While the concept of a
reconfigurable air interface holds considerable promise,
SDR will only be accepted if the security threats pertaining
to the secure download and execution of reconfiguration
software can be addressed.
In this paper the concept of trusted computing is
initially explored. An overview of the trusted computing
industry standard specifications is presented, in conjunction
with a synopsis of the most recent developments in trusted
computing technologies. Following this, we highlight the
threats which may impact upon an SDR device, and analyze
those threats which may be addressed through the
deployment of trusted computing functionality.
2. TRUSTED COMPUTING
In the context of trusted computing, a platform is trusted if it
“behaves in an expected manner for an intended purpose”
[2]. This does not necessarily imply, however, that a Trusted
Platform (TP) is a secure platform. For example, if an entity
can determine that a platform is infected with a virus, whose
effects are known, the platform can be trusted by that entity
to behave in an expected but malicious manner [3].
In order to implement a platform of this nature, a trusted
component, which is usually in the form of built-in
hardware, is integrated into a computing platform [4]. This
trusted component is then used to create a foundation of
trust for software processes running on the platform [4].
It is said that “trusted platforms were so-called because
they
provide
a
technological
implementation
and
interpretation of the factors that permit us, in everyday life,
to trust others” [5], i.e.
•
Either first hand experience of consistent behavior,
or trust in someone who vouches for consistent
behavior;
•
Unambiguous identification; and
•
Unhindered operation.
We examine this statement in relation to the ‘trusted
component’ upon which a trusted platform is constructed,
and the software processes running on the platform, for
which it provides a ‘foundation of trust’.
3. THE TRUSTED COMPUTING GROUP
The Trusted Computing Group (TCG)
1
is an industry forum
which is developing standards for trusted computing
platforms. Trusted computing, as currently defined by the
TCG, is built upon four fundamental concepts: integrity
measurement, authenticated boot, platform attestation, and
sealing.
3.1. Integrity Measurement
An integrity measurement is defined in [6] as the
cryptographic digest or hash of a platform component. For
example, an integrity measurement of a program can be
calculated by computing the cryptographic digest or hash of
its instruction sequence, its initial state (i.e. the executable
file) and its input.
3.2. Authenticated Boot
An authenticated boot process represents the process by
which a platform’s configuration or state is reliably
measured, and the resulting measurement is reliably stored.
During this process, the integrity of a pre-defined set of
platform components is measured, as defined in section 3.1,
in a particular order. These measurements are condensed to
form a set of integrity metrics which can then be stored in a
tamper-resistant log. Condensing enables an unbounded
number of platform component measurements to be stored.
If each measurement was stored separately it would be
1
www.trustedcomputinggroup.org
difficult to decide on an upper bound on the size of memory
required to store them [4]. A record of the platform
components which have been measured is also stored on the
platform.
3.3. Attestation
Attestation is the process by which a platform can reliably
report evidence of its identity and its current state (i.e. the
integrity metrics which have been stored to the tamper
resistant log, and the record of the platform components
which have been measured, as described in section 3.2).
3.4. Sealing
Sealing represents the process of associating data with a set
of integrity metrics representing a particular platform
configuration, and encrypting it. The data can only be
decrypted and released when the state of platform is the
same as that indicated by the integrity metrics sealed with
the data.
4. THE TRUSTED PLATFORM SUBSYSTEM
As described in section 2, in order to provide the services
described above, a ‘trusted component’ must be integrated
into a platform. This trusted component is comprised of
three so-called ‘roots of trust’ – the Root of Trust for
Measurement (RTM), the Root of Trust for Storage (RTS),
and the Root of Trust for Reporting (RTR). A root of trust is
defined as a component that must be unconditionally trusted
for the platform to be trusted [2].
4.1. The RTM
The RTM is an engine capable of measuring at least one
platform component, and hence providing an integrity
measurement, as described in section 3.1. The RTM is
typically implemented as the normal platform engine
controlled by a particular instruction set (the so-called ‘Core
Root of Trust for Measurement’ (CRTM)). On a PC, the
CRTM may be contained within the BIOS or the BIOS Boot
Block (BBB), and is executed by the platform when it is
acting as the RTM. It is required by the TCG that the CRTM
is protected against software attack: the CRTM must be
immutable, as defined by the TCG, meaning that its
replacement or modification must be under the control of the
host platform manufacturer alone [7]. It is also preferably
that the CRTM be physically tamper-evident [4].
4.2. The RTS and RTR
The RTS is a collection of capabilities which must be trusted
if storage of data inside a platform is to be trusted [4]. The
RTS is capable of maintaining an accurate summary of
integrity measurements made by the RTM, i.e. condensing
integrity measurements and storing the resulting integrity
metrics, as described in section 3.2. The RTS also provides
integrity and confidentiality protection to data and enables
sealing. In conjunction with the RTM and RTS, an
additional root of trust is necessary for the implementation
of platform attestation, namely the RTR. The RTR is a
collection of capabilities that must be trusted if reports of
integrity metrics are to be trusted (platform attestation) [4].
The RTR and the RTS constitute the minimum
functionality that should be provided by a Trusted Platform
Module (TPM) [9-11]. A TPM is generally implemented as
a chip which must be uniquely bound to a platform. In order
to support RTS and RTR functionality, a TPM incorporates
various functional components such as: I/O; non-volatile and
volatile memory; a minimum of 16 Platform Configuration
Registers (PCRs), which are used by the RTS to store the
platform's integrity metrics; a random number generator; a
hash engine; key generation capabilities; an asymmetric
encryption and digital signature engine; and an execution
engine. The TPM must be protected completely against
software attack, i.e. the RTS and RTR (i.e. the TPM) must
be immutable, which implies that the replacement or
modification of RTS and RTR code must be under the
control of the TPM manufacturer alone. The TPM is
required to provide a limited degree of protection against
physical attack (tamper-evidence) [4].
5. TP SUBSYSTEM FUNCTIONALITY
We now examine how the services described in section 3 are
provided by the RTM, RTS and RTR.
5.1. The Authenticated Boot Process
An authenticated boot process enables the state of a platform
to be measured and recorded so that it can be reported to a
challenger of the platform, as described in section 3.3. A
simplified authenticated boot process may proceed as
follows, where we assume that the CRTM is part of the
BBB. The CRTM measures itself and the rest of the BIOS
(i.e. the POST BIOS). The computed measurements are then
passed to the RTS which condenses them and stores the
resulting integrity metric to the first of the 16 PCRs (PCR-
0). Control is then passed to the POST BIOS which
measures the host platform configuration, the option ROM
code and configuration, and the Operating System (OS)
loader. The computed measurements are passed to the RTS,
which condenses them and stores the resulting integrity
metrics to PCRs 1-5. Control is then passed to the OS loader
which measures the OS. This process of measuring,
condensing, storing, and handing-off, continues until the
platform’s configuration has been measured and stored. The
exact measurement process is dependent on the platform; for
example, the TCG specifications detail authenticated boot
processes for a platform which has a 32-bit PC architecture
BIOS, [7] and for an Extensible Firmware Interface platform
[8].
5.2. The TPM Protected Storage Functionality
The
TPM
protected
storage
functionality,
which
incorporates its sealing capability, was designed so that an
unbounded number of secrets/data could be confidentiality
and integrity protected on a TP. Asymmetric cryptography is
used to confidentiality-protect data.
Protected storage also provides implicit integrity
protection of data objects. Data can be associated with a
string of 20 bytes of authorization data before it is
encrypted. If data decryption is requested, the authorization
data must be submitted to the TPM. The submitted data is
compared to the authorization data in the decrypted string,
and the decrypted data object is only released if the values
match. If the encrypted object has been tampered with, after
decryption the authorization data will most likely have been
corrupted (because of the method of encryption employed)
and access will not be granted even to an entity which has
submitted the correct authorization data. Functionality to
control how data is used on its release, or to protect data
from deletion, is not provided.
The TPM protected storage functionality incorporates
an asymmetric key generation capability. This capability
enables the generation of key pairs, where the private keys
from these pairs can only be used on the TPM on which they
were generated, and/or can only be used if the TPM host
platform is in a specified state. These private keys are never
exposed outside the TPM in the clear. The TPM enables the
encryption of keys or data external to the TPM so that they
can only be decrypted on a particular TPM; it also enables
the encryption of keys or data external to the TPM so that
they can only be decrypted by a particular TPM when the
TPM host platform is in a particular state. Finally, sealing is
provided, i.e. the association of data with a particular
platform configuration (i.e. a set of integrity metrics) and its
encryption by a particular TPM. The sealed data can only be
decrypted by the same TPM and will only be released if the
TPM host platform is in the specified state.
5.2. Platform Attestation
Platform attestation enables a TPM to reliably report
information about its identity and the current state of the
TPM host platform. Each TPM is associated with a unique
asymmetric key pair called an endorsement key pair, and a
set of credentials. A trusted platform management entity
(which is generally the TPM manufacturer) attests to the fact
that the TPM is indeed genuine by digitally signing an
endorsement credential, which binds the public endorsement
key to a TPM description. Conformance credentials may be
issued by laboratories: these attest that a particular type of
TPM, associated components such as a CRTM, the
connection of a CRTM to a motherboard, and the
connection of a TPM to a motherboard, conform to TCG
specifications. A platform entity (usually the platform
manufacturer) offers assurance in the form of a platform
credential that a particular platform is an instantiation of a
TP. In order to create a platform credential, a platform entity
must examine the endorsement credential of the TPM, the
conformance credentials relevant to the TP, and the platform
to be certified.
Since a TPM can be uniquely identified by its
endorsement key pair, this key pair is not routinely used by a
platform, ensuring that the activities of a TP cannot be
tracked. Instead, an arbitrary number of pseudonyms in the
form of attestation identity key (AIK) pairs can be generated
by a TPM and associated with a TP. Privacy-Certification
Authorities (P-CAs) enable attestation identity public keys
to be associated with TPs through the generation of AIK
credentials. Once a platform has requested an AIK
credential from a specified P-CA, the P-CA verifies all the
TP credentials, as described above, to ensure that the TP is
genuine, and then creates (signs) an AIK credential which
binds the public AIK to a generic description of the TP. The
private AIK is used by the TPM during platform attestation.
Platform attestation is a process by which a platform
signs a nonce (sent by a challenger of the platform) in
conjunction with integrity metrics reflecting the current state
of the platform, using one of its private AIKs. This signed
bundle is returned to the challenger with the record of the
platform components which are reflected in the integrity
metrics, together with the appropriate AIK credential. The
challenger then uses this information to determine whether it
is:
1.
Safe to trust the TP from which the statement has
originated;
2.
Safe to trust (part of) the software environment
running on the platform.
6. TRUST
We now evaluate the factors which make it safe to trust a TP
and (part of) the software environment running on the
platform. It is safe for the challenger to trust a TP on
validation of two elements.
•
An AIK credential, in which a trusted entity
vouches for the consistent behavior of the TP, i.e.
that the CRTM and TPM comply with TCG
specifications. If the CRTM and TPM comply with
the TCG specifications, this also implies that both
the CRTM and TPM are immutable and tamper-
evident and can therefore be trusted to operate
unhindered.
•
The signature of the TPM generated using its
private AIK, which serves to unambiguously
identify a TP.
It is only safe to trust (part of) the software environment of
the platform which has been attested to after examining two
elements.
•
The signed integrity metrics reported by the TP,
which enable the challenger to verify (part of) the
platform’s software environment.
•
The expected integrity measurements of each
platform component, which can be extracted from
the component’s validation certificate. A validation
certificate gives the expected integrity measurement
of a component if it is behaving as intended. These
measurements are then condensed and compared to
the integrity metrics attested to by the TP and
received by the challenger. The reported identity of
(part of) the TP’s software environment can thence
be validated. After validation, (part of) the TP’s
software environment can be unambiguously
identified.
In order to ensure software can operate unhindered, the
definition
of
what
constitutes
trusted
computing
functionality, as defined by the TCG, must be revised and
extended to incorporate concepts such as software isolation
or protected software execution.
7. ISOLATED EXECUTION ENVIRONMENTS
Isolation enables the unhindered execution of software [5].
In addition to the services provided by the TCG and
described above, an isolated execution environment should
provide the following services to hosted software [6].
•
Protection from external interference.
•
Observation of the computations and data of a
program running within an isolated environment
only via controlled inter-process communication.
•
Secure communication between programs running
in independent execution environments.
•
A trusted channel between an input/output device
and a program running in an isolated environment.
In order to provide software isolation and the services
described, an isolation layer or virtual machine monitor can
be deployed on the platform. Such a mechanism is not
defined by the TCG. An isolation layer may be implemented
using a number of approaches, as described below. Many of
these approaches, however, have associated difficulties with
respect
to
assurance,
device support, legacy OS
compatibility and performance.
7.1. OS-Hosted Virtual Machine Monitor
In the case of an OS-hosted virtual machine monitor, such as
VMWare workstation, all guest OSs executing in VMs
utilize the host OS device drivers. While this implies that
every guest can utilize drivers developed for the host
machine, it also means that the isolation layer essentially
incorporates the VMM and the host OS, making assurance
problematic [6, 13].
7.2. Standalone VMM
In a standalone VMM, such as Terra [14], all devices are
virtualized or emulated by the VMM. This means that the
VMM must contain a virtual device driver for every
supported device. As the set of devices in consumer systems
is often large, and as many virtual drivers are complex, the
size of the VMM quickly grows at the cost of assurance.
A standalone VMM exposes the original hardware
interface to its guests. While this implies that legacy OSs
can be supported, it also means that the VMM size is
increased due to the complexity involved in virtualizing the
x86 CPU instruction set [6].
7.3. Para-Virtualization
Isolation layers using para-virtualization techniques, such as
XEN [15], have been designed for efficiency, and try to
alleviate the complexity introduced when devices are
virtualized. Two common approaches used in order to para-
virtualize I/O are as follows [13].
In the first case, an I/O-type-specific API for each
device is integrated into the VMM, in conjunction with the
device drivers [13]. This approach requires a guest OS to
incorporate
para-virtualized
drivers
which
enable
communication with the VMM APIs rather than the
hardware device interfaces. While this gives performance
gains over full virtualization, the guest OS must be modified
to communicate with the I/O-type-specific APIs.
Alternatively, a service OS, which incorporates the
VMM APIs and the device drivers, may execute in parallel
to guest OSs, which are modified to incorporate para-
virtualized drivers [13]. To enable this approach, devices are
exported to the service OS. While this approach means that
device drivers do not have to be implemented within the
isolation layer, the isolation layer may become open to
attack from a guest in control of a direct memory access
device which is, by default, given unrestricted access to the
full physical address space of the machine.
7.4. An Isolation Layer with Hardware Support
The isolation layer described as part of the NGSCB [6, 16]
was designed to take advantage of CPU and chipset
extensions in the next generation of hardware. Such
extensions are being provided, for example, by Intel’s
LaGrande [3]. The isolation kernel has been designed to
execute in a CPU mode more privileged than the existing
ring 0, effectively in ring -1, which will be introduced in
forthcoming versions of the x86 processors. This enables the
isolation layer to operate in ring -1 and all guest OSs to
execute in ring 0. Thus, complexity problems which arise
when virtualizing the x86 instruction set are avoided [6].
The original hardware interface is exposed to one guest
OS [6]. However, rather than necessitating the virtualization
of all devices, as a VMM does, devices are exported to guest
OSs which contain drivers for the devices they choose to
support. Guest operating systems may then efficiently
operate directly on the chosen device. This does, however,
leave the problem of uncontrolled Direct Memory Access
(DMA) devices, which by default have access to all physical
memory. In order to prevent DMA devices circumventing
virtual memory-based protections provided by the isolation
layer, it is necessary for the chipset manufacturers to provide
chipset extensions. This enables a DMA policy to be set by
the isolation layer which indicates, given the state of the
system, if a particular subject (DMA device) has access
(read or write) to a specified resource (physical address),
[6]. The DMA policy is then read and enforced by hardware,
for example the memory controller or bus bridges.
Hardware extensions required in order to facilitate the
implementation of the NGSCB isolation layer have been
provided as part of Intel’s LaGrande [3] and AMD’s
Presidio initiatives. Both enable the efficient and secure
implementation of an isolation layer, as described by
Microsoft, through the implementation of CPU and chipset
extensions. Both also support the establishment of trusted
channels between the input and output devices and programs
running within an isolated environment.
8. SOFTWARE DEFINED RADIO
Software defined radio is an important innovation for the
communications industry, providing many advantages over a
wireless networking infrastructure and terminals that are
implemented completely in hardware. Cost reductions may
result from the deployment of a generic hardware platform
which can be customized using software [17]. The value of
terminals is increased as p
ublic/private sector radio system
sharing becomes possible and as terminals can be upgraded
to comply with evolving communications standards. In
conjunction with this, SDR enables operation and
maintenance cost reductions, as bug fixes may be completed
by software download rather than terminal recall.
Re-configurable radios can also be adapted to meet user
and/or operator preferences. A terminal can also be
reconfigured to efficiently cope with changing network
conditions such as utilization, interference or radio channel
quality, thereby offering an enhanced user experience [18].
Efficient roaming is also enabled, as air interface and
frequency bands can be reconfigured as required.
While there are many advantages associated with the
introduction of SDR terminals, if SDR is to be accepted the
security threats introduced by reconfigurable terminals must
be analyzed, and measures taken to mitigate these threats.
9. SDR THREAT ANALYSIS
The threats which impact upon a reconfigurable SDR device
may be categorized as follows:
•
Those which impinge on the security of the
downloaded reconfiguration software; and
•
Those which impinge on host security.
The fundamental threat to the security of the
downloaded reconfiguration software is:
•
Unauthorized reading of software while in transit
between the software provider and the end host, or
while in storage or executing on the end host.
This threat may result in an infringement of the intellectual
property rights associated with the software. It may also
result in unauthorized access to and execution of software.
Fundamental threats to end host security include:
•
Malicious or accidental modification or removal of
security-critical software while in storage or
executing on the end host.
•
The download of inappropriate reconfiguration
software which does not meet the capability
requirements of the SDR device.
•
Malicious or accidental modification, addition or
removal of downloaded software in development,
in transit or while in storage or executing on the
end host.
These threats may result in:
•
An inoperable device. For example, if a device uses
software modulation, an improper change of the
modulation format can render the individual device
inoperable [19].
•
Violation of Radio Frequency (RF) spectrum rights.
This may, for example, result in RF interference. If
a device can be programmed to transmit on a
frequency for which it is not authorized, signals
from other nodes, which are authorized to use this
frequency, may be jammed [19]. Alternatively,
spurious emissions resulting from unauthorized
radio spectrum use could violate user safety [20].
•
Increased output power. If a device, for example,
operates at maximum power, its performance may
be increased at the expense of other users in the
communications network [19]. This in turn may
force other users to use increased power. In this
way, the device battery life is severely shortened. If
the radiated power is too high, user safety may also
be put at risk [20].
•
Compromise of user applications and/or data by
malicious software.
The threats listed above, and the possible impacts of their
exploitation, include those defined by the SDRF security
working group in [21].
10. ADDRESSING THREATS TO SDR USING TC
We now investigate some of ways in which trusted
computing functionality may be used in order to address the
threats outlined above or, failing that, to limit the level to
which a threat may be exploited.
10.1. Protecting the Reconfiguration Software
TC mechanisms may be used to confidentiality-protect the
reconfiguration software in transit between the software
provider and the end host, while in storage or executing on
the end host, and to ensure that only the intended recipient
device can access the software.
In [22], we describe a software download protocol
which leveraged trusted computing functionality, or, more
specifically, sealed storage, platform attestation, and
isolation techniques. This protocol is now summarized.
Before the required reconfiguration software can be
downloaded to a TP, the TPM is used to generate an
asymmetric key pair. This key pair is bound to a set of
integrity metrics such that the private key can only be
utilized by the TPM on which it was generated when the
TPM host platform is in the specified state. The public key
from this pair, and the integrity metrics with which its
private key are associated, are then certified by the TPM
using a TP AIK, described in section 5.2, so that the state to
which the private key is bound can be shown to the software
provider. The certified public key and the corresponding
AIK credential are then sent to the software provider.
On receipt of the certified key and the AIK credential,
the software provider verifies the TP’s AIK credential and
the signature of the TPM on the public key and the
associated integrity metrics. If these two elements can be
verified, and if the software provider considers the platform
software state to which the key is bound to be trustworthy,
the provider computes a MAC on and encrypts the
reconfiguration software, encrypts the symmetric MACing
and encryption keys using the public key received from the
TP, signs the encrypted symmetric keys using his private
signature key, and transmits this data to the TP. The
symmetric keys received by the TP, and therefore the
reconfiguration software, can only be accessed when the TP
is in the state deemed trustworthy by the software provider.
The software provider may require that the integrity
metrics to which the private key is bound, represent an
isolated execution environment executing on a specified
isolation layer, which is turn is supported by a TP which
incorporates hardware extensions that enable efficient and
secure isolation, as described in section 7. In this way, the
confidentiality of the reconfiguration software can be
protected in transit between the software provider and the
TP, in storage, and while executing on the device. The
software provider is also assured that only a specified TP in
a particular state can access the software.
Alternatively, if a more traditional mechanism such as
SSL/TLS is used in order to provide secure download of the
reconfiguration software, TC functionality can be used in
order to harden the SSL/TLS implementation. In this case,
prior to the completion of any SSL/TLS protocol, the TPM
is used in order to generate the client-side (the SDR device)
asymmetric key pair for authentication, which is bound to a
set of integrity metrics such that the private key can only be
utilized by the TPM on which it was generated when the
TPM host platform is in the required state. This key is then
certified using a TP AIK. Evidence that this SSL/TLS key
pair has been generated on, and certified by, a TPM is then
provided by a Certification Authority (CA) in an extension
of the SDR device’s X.509 SSL/TLS certificate.
During an SSL/TLS protocol run between a software
provider and the SDR device, the information provided in
the extension of the SDR device’s X.509 SSL/TLS public
key certificate enables a software provider to trust that the
SDR device’s private SSL/TLS key is held within a TPM,
and that the key can only be used when the platform is in a
particular state. As above, the software provider may require
that the integrity metrics to which the private key is bound,
represent an isolated execution environment into which the
software will be downloaded and executed. This hardened
implementation of SSL/TLS gives the software provider
some assurance that the SDR device’s SSL/TLS private key
is stored securely and cannot been stolen. Evidence of the
device’s ability to provide an isolated execution
environment for the downloaded software can also be
demonstrated. This process is described in [23]. The
protocol described in [22] has the advantage that less
processing is required on the potentially resource-
constrained SDR device in order to complete the download.
10.2. Protecting the Host
10.2.1. Security-Critical Software
While the integrity of security-critical software while in
storage cannot be ensured using TC functionality, TC
mechanisms may be utilized to help detect its malicious or
accidental modification or removal.
A secure boot process can be used to ensure that a set of
security-critical platform components boot into the required
state. Secure boot is not currently enabled by the TCG TPM
main specifications. However, much work on secure boot
has been conducted independently of the TCG, including by
Tygar and Yee [24], Clark [25], Arbaugh, Farber and Smith
[26] and Itoi and Arbaugh [27]. Each of these papers
describe a similar process, in which the integrity of a pre-
defined set of system components is measured, as described
in section 3.1, and these measurements then compared
against a set of expected measurements which must be
securely stored and accessed by the platform during the boot
process. If, at any stage during the boot process, the removal
or modification of a platform component is detected, the
boot process is aborted. While a secure boot process is not
specified in the TPM specification set, the TCG mobile
phone working group has recently released a specification
for a Mobile TPM which enables a secure boot process [28].
TC functionality also enables the isolation of security-
critical software in a secure execution environment so that it
cannot be observed or modified when executing by software
executing in parallel insecure execution environment.
10.2.2. Reconfiguration (Radio) Software
A capability exchange must be completed by the network
and the SDR prior to software download to ensure that the
appropriate software entities and parameter sets are selected
for a particular SDR device, [29]. The use of platform
attestation, as described in section 3.2, could be used to
ensure that the reports sent by the device are accurate.
TC cannot prevent denial of service attacks resulting
from the removal/deletion of the downloaded radio software,
either in development, or in transit between the software
provider and the host or in storage on the host. While TC
functionality cannot prevent the malicious or accidental
modification or addition of downloaded software in
development or in transit, in the advent of malicious or
buggy software being downloaded to and executed on a
device, there are a number of ways in which TC can lessen
the impact of the exploitation of this threat.
If the downloaded software is isolated in its own
execution environment, as described in section 7, then any
malicious behavior can be controlled and its effects limited.
If sealed storage is utilized by the end user to protect
their private data (e.g., credit card numbers), then the impact
of malicious software may be lessened, as it cannot gain
access to security sensitive data which has been protected.
On reconnection to a commercial network, a trusted
SDR device could be required to attest to its state so that a
decision can be made as to whether the device should be
authorized to access the network. Building upon basic
attestation, as described in section 3.2, the specifications of
the TCG Trusted Network Connect work group describe a
process which may be completed in order to ensure that
devices connecting to a network are in a trustworthy state.
This 3-stage process involves:
•
Assessment (is the platform in a trustworthy state?);
•
Isolation (of the device if its state is not considered
trustworthy by the network); and
•
Remediation (where the state of the device can be
updated/modified as required) [30].
Process isolation may be utilized in order to ensure that
the downloaded radio software can execute unhindered.
11. CONCLUSIONS
In this paper we have introduced the concept of trusted
computing. Following a brief overview of the threats
introduced by the deployment of re-configurable terminals
we highlighted some of ways in which TC functionality may
be used in order to mitigate, or lessen the impact of, these
threats. While trusted computing is not a panacea to the
plethora of security threats pertaining to the secure
download and execution of reconfiguration software, it
enables us to address a significant number of them, either
through threat mitigation or through threat impact reduction.
12. REFERENCES
[1] Software Defined Radio Forum (SDRF), Overview and
Definition of Software Download for RF Reconfiguration,
SDRF Archived Approved Document, DL-DFN Document
SDRF-02-A-0002-V.0.0, 27th August 2002.
[2] Trusted Computing Group (TCG), “TCG Specification
Architecture Overview”, TCG Specification Version 1.2, The
Trusted Computing Group, Portland, Oregon, USA, April
2003.
[3] D. Grawrock, The Intel Safer Computing Initiative Building
Blocks for Trusted Computing, Intel Press, Oregon, USA,
2006.
[4] B. Balacheff, L. Chen, S. Pearson, D. Plaquin, and G.
Proudler, Trusted Computing Platforms: TCPA Technology
in Context, Prentice Hall, Upper Saddle River, New Jersey,
USA, 2003.
[5] G.J. Proudler, “Concepts of Trusted Computing”, In C.J.
Mitchell, editor, Trusted Computing, IEE Professional
Applications of Computing Series 6, chapter 2, pages 11-28,
The Institute of Electrical Engineers (IEE), London, UK,
2005.
[6] M. Peinado, P. England and Y. Chen, “An Overview of
NGSCB”, In C.J. Mitchell, editor, Trusted Computing, IEE
Professional Applications of Computing Series 6, chapter 4,
pages 115-144, The Institute of Electrical Engineers (IEE),
London, UK, 2005.
[7] Trusted Computing Group (TCG), “TCG PC Client Specific
Implementation Specification for Conventional BIOS - for
TPM Family 1.2; Level 2”, TCG Specification Version 1.2
Final Revision 1.00, The Trusted Computing Group, Portland,
Oregon, USA, July 2005.
[8] Trusted Computing Group (TCG), “TCG EFI Platform - for
TPM Family 1.1 or 1.2”, TCG Specification Version 1.2 Final
Revision 1.00, The Trusted Computing Group, Portland,
Oregon, USA, June 2006.
[9] Trusted Computing Group (TCG), TPM Main, Part 1 Design
Principles, TCG Specification Version 1.2 Revision 94, The
Trusted Computing Group, Portland, Oregon, USA, March
2006.
[10] Trusted Computing Group (TCG), TPM Main, Part 2 TPM
Data Structures, TCG Specification Version 1.2 Revision 94,
The Trusted Computing Group, Portland, Oregon, USA,
March 2006.
[11] Trusted Computing Group (TCG), TPM Main, Part 3
Commands, TCG Specification Version 1.2 Revision 94, The
Trusted Computing Group, Portland, Oregon, USA, March
2006.
[12] National Institute of Standards and Technology (NIST),
Security Hash Standard, Federal Information Processing
Standards Publication FIPS PUB 180-2, The National
Institute of Standards and Technology, August 2000.
[13] D. Abramson, J. Jackson, S. Muthrasanallur, G. Neiger, G.
Regnier, R. Sankaran, I. Schionas, R. Uhlig, B. Vembu and J.
Wiegert, “Intel Virtualization Technology for Directed I/O”,
Intel Technology Journal, 10(3): pages 179-192, 10
th
August
2006.
[14] T. Garfinkel, B. Pfaff, J. Chow, M. Rosenblum and D. Boneh,
“Terra: A Virtual Machine Based Platform for Trusted
Computing”, In Proceedings of the 19
th
Symposium on
Operating Systems Principles (SOSP 2003), pages 193-206,
Bolton Landing, New York, USA, 19-22 October 2003, ACM
Press, New York.
[15] P. Barham, B. Dragovic, K. Fraser, S. Hand, T. Harris, A. Ho,
R. Neugebauer, I. Pratt and A. Warfield, “Xen and the Art of
Virtualization”, In Proceedings of the 19
th
ACM Symposium
on Operating System Principals (SOSP 2003), pages 164-177,
Bolton Landing, New York, USA, 19-22 October 2003, ACM
Press, New York.
[16] M. Peinado, Y. Chen, P. England, and J. Manferdelli,
“NGSCB: A Trusted Open System”, H. Wang, J. Pieprzyk,
and V. Varadharajan, editors, In Proceedings of 9th
Australasian Conference on Information Security and
Privacy, ACISP 2004, volume 3108 of Lecture Notes in
Computer Science (LNCS), pages 86-97, Springer-Verlag,
Berlin-Heidelberg, Germany, July 2004.
[17] S.M. Blust, Presentation on “Perspective on Software Defined
Radio Focusing on Reconfiguration and Radio Software
Download”, Cingular Wireless, 8
th
September 2003.
[18] R. Falk, R.K. Atukula and U. Lucking, “Secure
Communications in Future Mobile Communication Systems”,
In Proceedings of the 14
th
IST Mobile and Wireless
Communication Summit, Dresden, Germany, 19-23 June
2005.
[19] R.L. Hill, S. Myagmar and R. Campbell, “Threat Analysis of
GNU Software Radio”, In Proceedings of the World Wireless
Congress (WWC 2005), Palo Alto, California, USA, 24-27
May 2005.
[20] Software
Defined
Radio
Forum
(SDRF),
Security
Considerations for Operational Software Defined Radio
Devices in a Commercial Wireless Domain, SDRF Working
Document, DL-SIN Document SDRR-04-A-0010-V.0.00,
27th October 2004.
[21] Software Defined Radio Forum (SDRF), Security Functional
Requirements for a Software Reconfigurable Communications
Device, SDRF Working Document, SDRF-06-W-0002-
V0.15, 3rd October 2006.
[22] E. Gallery and A. Tomlinson, “Protection of Downloadable
Software on SDR Devices”, In Proceedings of the 4th
Software Defined Radio Forum Technical Conference (SDR
2005), Orange County, California, USA, 14-18 November
2005, Software Defined Radio Forum (SDRF).
[23] Trusted Computing Group (TCG), Subject Key Attestation
Evidence Extension, TCG Specification Version 1.0 Revision
7, The Trusted Computing Group, Portland, Oregon, USA,
16
th
June 2005.
[24] J. Tygar and B. Yee, “Dyad: A System for Using Physically
Secure Co-processors”, Technical report CMU-CS-91-140R,
Carnigie Mellon University, May 1991.
[25] P.C. Clark and L.J. Hoffman, “BITS: A Smartcard Protected
Operating System”, Communications of the ACM, 37(11):
pages 66-94, November 1994.
[26] W.A. Arbaugh, D.J. Farber and J.M. Smith, “A Secure and
Reliable Bootstrap Architecture”, In Proceedings of the 1997
IEEE Symposium on Security and Privacy, pages 65-71,
Oakland, California, USA, 4-7 May 1997, IEEE Computer
Society, IEEE Computer Society Press.
[27] N. Itoi, W.A. Arbaugh, S.J. Pollack, and D.M. Reeves.
“Personal Secure Booting”, In Proceedings of the 6th
Australasian Conference on Information Security and Privacy,
volume 2119 of Lecture Notes in Computer Science (LNCS),
pages 130-141, Springer-Verlag, London, UK, July 2001.
[28] Trusted Computing Group (TCG), TCG Mobile Trusted
Module Specification, TCG Specification Version 0.9
Revision 1, The Trusted Computing Group, Portland, Oregon,
USA, 12
th
September 2006.
[29] Software Defined Radio Forum (SDRF), Requirements for
Radio Software Download for RF Reconfiguration, Technical
Report SDRF-02-A-0007-V0.0, SDR Forum, November
2002.
[30] Trusted Computing Group (TCG), Trusted Network Connect
Architecture for Interoperability, TCG Specification Version
1.1 Revision 2, The Trusted Computing Group, Portland,
Oregon, USA, 1
st
May 2006.
Copyright Transfer Agreement:
The following Copyright Transfer Agreement must be included on the cover
sheet for the paper (either email or fax)—not on the paper itself.
“The authors represent that the work is original and they are the author or authors of the work, except for material
quoted and referenced as text passages. Authors acknowledge that they are willing to transfer the copyright of the
abstract and the completed paper to the SDR Forum for purposes of publication in the SDR Forum Conference
Proceedings, on associated CD ROMS, on SDR Forum Web pages, and compilations and derivative works
related to this conference, should the paper be accepted for the conference. Authors are permitted to reproduce
their work, and to reuse material in whole or in part from their work; for derivative works, however, such authors
may not grant third party requests for reprints or republishing.”
Government employees whose work is not subject to copyright should so certify. For work performed under a
U.S. Government contract, the U.S. Government has royalty-free permission to reproduce the author's work for
official U.S. Government purposes.
