D10.8 Final Standardisation Report

Project number

IST-027635

Project acronym

Open_TC

Project title

Open Trusted Computing

Deliverable type

Report

Deliverable reference number

IST-027635/D10.8/V1.0 FINAL

Deliverable title

Final Standardisation Report

WP contributing to the deliverable

WP10

Due date

Oct 2008 – M36

Actual submission date

April 30th, 2009

Responsible Organisation

IFX

Authors

IFX (Hans Brandl)

Abstract

Standardisation  is  an  important  activity  for
any new technology as it is a prerequisite for
its wide acceptance and dissemination. With
respect to Trusted Computing, the TCG has
developed  the  basic  set  of  standards  and
therefore many OpenTC participants are also
members  of  and  contributing  to  the  TCG
work.  Additionally,  project  members
contribute to other standard activities, where
TC  knowledge  is  useful  such  as:  JAVA
(JSR321), OMTP, DRM, OMA, ETSI.
This  report  describes  the  main
standardisation  activities  of    the  OpenTC
project members.

Keywords

Standardisation, TCG, TSS, DRTM, DRM,
CRTM, JAVA, OMTP, OMA, ETSI, ISO

Dissemination level

Public

Revision

V1.0 Final

Instrument

IP

Start date of the
project

1

st

 November 2005

Thematic Priority

IST

Duration

42 months

background image

D10.8 Final Standardisation report

Table of Contents

1  The Trusted Computing Group ..................................................................................3

1.1   Standardisation work and contribution within the TCG........................................3

1.1.1 Workpackage 3: Standard interfaces to TC hardware........................................4
1.1.2 Workpackage 8: Mobile phone communications................................................4

1.2 Trusted computing standardisation contributions..................................................4

1.2.1 The TSS (TPM Software Stack) ..........................................................................4
1.2.2 Contributions to additional language interfaces of the TSS...............................4
1.2.3 TSS JAVA language interface.............................................................................5
1.2.4 Mobile Phone Working Group (MPWG)...............................................................5
1.2.5 Direct Anonymous Attestation (DAA) protocol...................................................5
1.2.6 Dynamic Root of Trust Measurement standard (DRTM).....................................5
1.2.7 TCG standard correction and enhancements at the ISO PAS process................6

2  JAVA Standard contributions  (JSR321).......................................................................6

2.1 TSS JAVA language interface..................................................................................6
2.2 Standardisation work  (JSR321: Trusted Computing API for JavaTM)......................6

3  Wireless standard activities.......................................................................................9

3.1 Analysis of market, user and mobile network provider requirements....................9
3.2 OMTP (Open Mobile Terminal Platform) .................................................................9
3.3 Open Mobile Association (OMA)............................................................................10
3.4 Software Defined Radio Forum (SDRF).................................................................10

4  Digital Rights Management (DRM)...........................................................................10

4.1 Digital Rights management related standardisation activities.............................10
4.2 MPEG participation...............................................................................................11

5  ETSI standardisation................................................................................................11
6  Conclusion...............................................................................................................12
7  List of Abbreviations ...............................................................................................13

Open_TC Deliverable 10.8

2/13

background image

D10.8 Final Standardisation report

Introduction

Standardisation is required to ensure the success of the OpenTC project as future use
and exploitation of the project results will largely depend on such activities. Strong
cooperation is required between the relevant standards bodies and the OpenTC both
during  the  project  and  beyond  to  ensure  that  the  OpenTC  can  contribute  to
current/upcoming standards. The results achieved throughout the project  have been,
and will continue  to be, processed  and submitted to competent trusted  computing
standardisation bodies by the respective consortium members. As trusted computing
technology delivers universal usable features it can also support non-TC and non-TPM
standards  for  increased  levels  of  safety  and  security.  The  consortium  has  also
therefore  established other  standardisation  relations outside  of the  area of TC and
worked towards the enhancement of conventional standards with TC.

The Trusted Computing Group

The TCG is the internationally accepted standardisation body for trusted computing. It
is  therefore  important  to  continuously  exchange  standardisation  and  background
information between the TCG and OpenTC.

1.1   Standardisation work and contribution within the TCG

OpenTC  has  extended  standard  proposals  and  donated  them  to  the  relevant  TCG
standardisation  bodies.  Therefore  strong  cooperation  with  the  TCG  standardisation
body  was  necessary  during  the  project  time  frame  and  beyond.  The  intermediate
results,  gained  throughout  the  project  duration  where  feed  into  the  TCG  working
groups. Standardisation activities include those which are:

TC-orientated, as with the TCG.

Infrastructure-oriented,  like  protocols  and  interfaces  for  integrating  TC  into
today’s IT and security world.

Application-oriented for the enhancement of existing application fields with trust
and for the generation of new applications.

OpenTC members participated in the TCG work groups for transfer of information from
the newest version of the TCG standardisation work to the OpenTC project and vice
versa. They also informed the TCG work group members about the targets, results and
work of the OpenTC project.

TCG memberships within OpenTC

Infineon:

TCG  –  board  of  directors,  compliance  and  conformance  committee(co-

chairs), most of the important working groups such as TPM, TSS, PC Client, Server,
Mobile Phone, Trusted Drives, Technical Committee.

Hewlett Packard:

TCG – board of directors, compliance and conformance committee,

most of the important working groups.

IBM:

TCG – board of directors,  most of the important working groups.

AMD:

 TCG – board of directors,  most of the important working groups.

POLITO:

 University liaison program member; TPM and TSS working groups.

IAIK:

 University liaison program member; TPM and TSS working groups.

RHUL:

University liaison program member; TPM and MPWG working groups.

Open_TC Deliverable 10.8

3/13

background image

D10.8 Final Standardisation report

The

industrial  project  members

  (HP,  IBM,  AMD  and  IFX)  were  already  regular

members of the TCG at the start of the project and also members of the TCG board of
directors.   Therefore we have a very tight connection between OpenTC and the TCG
from both a technical and an organisational/political point of view.

TCG Liaison Program

This  special  program  of  the  TCG  allows  academic  institutions,  industry  standards
bodies, government  agencies and special interest groups with a stake in computer
security to participate in TCG Work Groups. Members in this program are anticipated
to help the TCG stay in touch with current research, standards and concerns of other
important institutions involved in security. Liaison program members can participate in
all work groups of the TCG and therefore influence and get first hand results from the
standardisation work.

Workpackages with intensive TCG cooperation:

1.1.1 Workpackage 3: Standard interfaces to TC hardware

WP03 centers around research on and implementation of the main TCG standards like
the TSS stack and also the development of a virtualisation layer which corresponds to
the  new  TCGs  dynamic  root  of  trust  standard.  Together  with  the  relevant  TCG
workgroups the main focus of the WP03 was the enhancement of the TSS stack with
new elements (like the inclusion of SOAP interface technology).

1.1.2 Workpackage 8: Mobile phone communications

WP8 (mobile phone communications) was also planned in the beginning with a narrow
connection to the newly started Mobile Phone Working Group of the TCG.

1.2 Trusted computing standardisation contributions

1.2.1 The TSS (TPM Software Stack)

At the beginning of the work within OpenTC it was clear that the Trusted Software
Stack (TSS) standard of the TCG (the interface between the Trusted Platform Module
(TPM) which is the elementary hardware security module and the host software and
operating system) had to be fully renewed out of new findings, development of the
state of the art and influences from other standards. The work within WP3, namely the
development of  the new TSS  was therefore done in full cooperation with the current
standardisation work of the TSS working group within the TCG. The now stable results
of  the  standardisation  work  where  immediately  implemented  within  Workpackage
WP3.2  TSS development and the  results and implementation feedback from WP3.1
influenced the practical formulation of the new TSS standard in a very large manner.
At the end of this development phase we had released a final implementation of the
new TSS standard version, which acts as a reference implementation of the new TSS
standard, which is now published as the new valid standard.

1.2.2 Contributions to additional language interfaces of the TSS

For   the   adaptation   of   the   TSS   to   different   host   systems   it   is   useful   to   implement
adaptation  layers  to  existing  accepted  standards.  Currently,  the  existing  version
contains an interface description to the Microsoft proprietary CAPI (crypto application

Open_TC Deliverable 10.8

4/13

background image

D10.8 Final Standardisation report

interface) and the open PKCS#11 standard (also cryptographic). As within Linux  a
general PKCS#11 implementation existed at the beginning of the project, Polito took
over  the  task  to  realise  a  specific  adaptation  of  PKCS#11  which  fitted  to  the
requirements of trusted computing  and especially to the TSS stack interface.   The
result of this  work  was also used as a reference for  a TSS extension of Linux and
transferred into the public Linux  repository.

1.2.3 TSS JAVA language interface

As the JAVA language system is now widely accepted and used within the community
and  also  within  WP4  and  5  of  the  OpenTC  project,  and  there  existed  no
implementation of a trusted JAVA, IAIK started work on the definition and example
implementation   of   JAVA   as   an   additional   application   interface   of   the   TSS.   IAIK
implemented a JAVA Wrapper for TSS (which was until now used within OpenTC as a
functionally  management  implementation  of  trusted  OS  within  WP5).  As  this
implementation  is already working, IAIK has started to bring these results not only
into the TCG as a contribution, but also to the JAVA forum as an extension of the
current JAVA standard.

1.2.4 Mobile Phone Working Group (MPWG)

Within   WP8   we   followed,   analysed   and   contributed   to  the   work   of   the   TCG   Mobile
Phone  Working  Group  which  produced  and  published  mobile  security  relevant
documents, namely, the TCG Mobile Trusted Module specification and The TCG Mobile
Reference Architecture specification. We looked at these documents in particular for
the preparation of an internal report 'Investigation of TC Life cycle Issues for Main Use
Cases'. See also 3. Wireless Standard Activities

1.2.5 Direct Anonymous Attestation (DAA) protocol

The DAA is an approach for digital authentication between network instances which
extends existing standard certificate based methods (like the well known digital public
key  certificate  measures).  DAA  is  a  known  and  recognised  TPM  protocol.  The  DAA
Issuer provides certification that the holder of DAA-credentials meets some  criteria
defined by the Issuer. In many cases the Issuer will be the platform manufacturer, but
other entities can also become issuers. As TCG standards contain the first practical
use   of   this   DAA   method   and   this   technology   is   very   new   with   minimal   practical
experience about implementation  worldwide analysis  and feedback  about DAA was
made in WP5 mainly by IBM  and results where contributed to the TCG standardisation
work.

1.2.6 Dynamic Root of Trust Measurement standard (DRTM)

Within SWP03a  AMD developed a universal virtualisation layer (the interface between
trusted OS and the processor chips) which has also been used as a platform for WP4
and WP5. After finishing the SWP03a package AMD brought it into the TCG where the
work  was  continued  as  a  public  TCG  standard  “The  Dynamic  Root  of  Trust
Measurement“,  an  elementary  part  of  any  TC  standard  which  applies  vitualisation.
AMD is now a TCG key contributor and editor for this piece of standard and pushes
these activities together with other companies  like Microsoft,  HP, Phoenix, Lenovo,
Intel, NSA, Fujitsu, General Dynamics, CESG and Dell. The final specification will be
probably  be published  this year and  will be a part of the PCClient,  DRTM sub WG
standards.    DRTM will become one  of the most important  standards  for  advanced,
future   operating   system   based   on   trusted   computing   virtualisation   platforms.    The

Open_TC Deliverable 10.8

5/13

background image

D10.8 Final Standardisation report

working group expects the specification to have a public release in the first half of
2009.

1.2.7 TCG standard correction and enhancements at the ISO PAS process

The  TCG  has  just  applied  to  the  international  ISO  standardisation  organisation  for
transferring its TPM standard into an worldwide ISO standard by using the so called
“public available standard” procedure. The ISO has voted successfully for accepting
the already existing  TPM-Standard and adopting it as an international ISO standard.
Part of this process is the possibility to propose advancements and add ons to the ex-
isting standards by the ISO member states to fill up deficits and broaden the use scen-
ario. RUB has developed a large proposal for such enhancements, which was presen-
ted and accepted to the german DIN standardisation  as national ISO body and also
forwarded directly to the TCG itself.
Additionally, they proposed  a new TPM command. It allows a TPM to compute a spe-
cific cryptographic primitive (called a commitment). Commitment schemes are strong-
ly used for DAA. The new command allows the realisation of concrete mechanisms for
the so-called Property-Based  Attestation which is an extension of binary attestation
(proposed by the TCG) to a more general concept of property attestation (instead of
attest binaries). Such a mechanism has already been proposed in joint research work
by RUB and HP.

JAVA Standard contributions  (JSR321)

2.1 TSS JAVA language interface

As the JAVA language system is now widely accepted and used within the community
and  also  within  WP4  and  5  of  the  OpenTC  project,  and  as  there  existed  no
implementation of a trusted JAVA, IAIK started work on the definition and example
implementation  of  JAVA  as  an  additional  application  interface  of  the  TSS.  As  this
implementation  is already working,  IAIK has started to contribute these results not
only into the TCG, but also to the JAVA forum as an extension of the current JAVA
standard.  IAIK and CUCL have been participating in the Java standardisation activity
JSR 321.  This is the Java specification request to develop a Trusted Computing API for
Java: “Develop a Trusted Computing API for Java

TM

, providing selected functionality the

TCG Software Stack offers to the C world, while following the conventions of modern
Java APIs”.
http://www.jcp.org/en/jsr/detail?id=321
https://jsr321.dev.java.net/

2.2 Standardisation work  (JSR321: Trusted Computing API for JavaTM)

Details of this work can be found in the report

D03.d7: Java-API Standardization

(Results from JSR 321).

IAIK of Graz University of Technology has been active in international standardisation
bodies for years. Among them are ETSI, OASIS, W3C and other organizations  relevant
to Trusted Computing (TC). IAIK is also a member of the Trusted Computing Group
where it is participating in the TPM, TNC, TSS and Infrastructure working groups. IAIK
has also designed and implemented the TCG Software Stack for Java

TM

 (jTSS) [1], one

Open_TC Deliverable 10.8

6/13

background image

D10.8 Final Standardisation report

of the first libraries available that allows using the TPM from Java

TM

 applications.

Based on this expertise, IAIK has initialized the standardization of a modern Trusted
Computing API in the Java

TM

 Community Process (JCP) [2].

The JCP is a program designed to allow to define industry standards while at the same
time  ensuring  compatibility  with  Java  technology.  It  is  controlled  by  the  Executive
Committee,  an  elected  body,  also  representing  most  major  players  in  the  Java
industry. The JCP consists of four phases, which are shown in Illustration1.

1. Initiation:  A  specification  targeted  for  adoption  is  initiated  by  community

member  and  approved  for  development  by  the  responsible  Executive
Committee (EC).

2. Early Draft: A group of experts is formed to develop a preliminary draft of the

specification that both the community and the public will then review. Anyone
can  read  and  comment  on  the  draft  on  the  web.  The  expert  group  uses
feedback from the review to revise and refine the draft.

3. Public Draft: The draft goes out again for review by the public. The expert group

uses the feedback to further revise the document. At the end of this review, the
EC decides if the draft should proceed. If approved by the EC, the leader of the
expert  group  sees  that  the  reference  implementation  and  its  associated
technology  compatibility  kit  are  completed.  Then  EC  will  decide  on  its  final
approval.

4. Maintenance:  The  completed  specification,  reference  implementation,  and

technology compatibility kit are updated in response to ongoing requests for
clarification, interpretation, enhancements, and revisions.

After submitting the proposal for

“JSR 321: Trusted Computing API for Java"

 [3] in

late  2007,  it  was  reviewed  by  and  voted  on  by  the  J2SE  Executive  Committee,
receiving overwhelming support with 15 out of 16 votes in favor for it (1 abstained).
At the time of writing, an Expert Group has formed. IAIK is now leading this group of
international  experts  from  academia  and industry.  Experts,  either as  individuals  or
representing  an  institution,  actively  shape  the  content  and  direction  of  new  and

Open_TC Deliverable 10.8

7/13

Illustration 1: The four phases of the Java Community Process

[www.jcp.org]

background image

D10.8 Final Standardisation report

revised Java specifications by means of discussion.

While the JCP provides a formal framework, the Expert Groups may freely decide on
their working style. In the spirit of the Open-TC project, this Java Specification Request
No. 321 (JSR321) has chosen an open, transparent and agile working style. Thus the
technical  discussion  is  also  open  for  non-members  of  the  JCP,  allowing  for  further
cooperation and integration with the open source community. At the time of writing,
IAIK is in contact with Experts from, but not restricted to,

Sun (J2SE Security Architect), USA

Intel, USA

University of Klagenfurt, Austria

University of Cambridge, UK (Open-TC partner)

Portakal, Turkey (Open-TC partner)

CSAIL, Massachusetts Institute of Technology, USA.

This  JSR321  Expert  Group  will  create  a  high-level  object-oriented  API  for  the
javax.trustedComputing  name  space.  Thus  it is to develop  a software  interface  for
Java

TM

 providing comparable functionality the TSS [4] offers to the C world.

Besides this API specification, it will also develop a Reference Implementation and a
Technology Compatibility Kit. The purpose of the Reference Implementation is to show
that the specified API can be implemented and is indeed viable. With the Technology
Compatibility Kit, a complete test suite will be provided to enable third parties to build
their own, compatible implementations.
To increase the transparency and trustworthiness both will to be released as open
source software under the GNU license (GPLv2). Even more so, the open source and
Java

TM

  community   are   invited   [6]   to   take   part   in   the   design   as   well   as   in   the

implementations.
JSR   321,   lead   by   IAIK,   will   allow   developers   to   make   use   of   Trusted   Computing
functionality  in  their  Java

TM

  applications.  Striving  for  a  new  simplified  design,  the

resulting API will be easier to use than the interfaces available today. This and the fact
that all results will be released under an open source license will foster the use of
trusted technology for research, open and also commercial applications.

[1] M. Pirker, R.Toegl, T. Winkler, T. Vejda, M. Steurer, Trusted Computing for the Java
Platform,

http://trustedjava.sf.net

, 2008

[2] Java Community Process,

http://www.jcp.org

, 2008.

[3]  R.  Toegl  et  al.,  JSR  321:  Trusted  Computing  API  for  Java,

http://www.jcp.org/en/jsr/detail?id=321

, Java Community Process, 2008.

[4]  Trusted  Computing  Group,  TCG  Software  Stack  Specifications,  Version  1.2A,

https://www.trustedcomputinggroup.org/specs/TSS/

,

 2007.

[5] L. Sarmenta et al., TPM/J Java-based API for the Trusted Platform Module (TPM) ,

http://projects.csail.mit.edu/tc/tpmj/

, 2007.

[6] R. Toegl et al, The Trusted Computing API for Java Project, Java.net Community,

https://jsr321.dev.java.net/

, 2008.

Open_TC Deliverable 10.8

8/13

background image

D10.8 Final Standardisation report

Wireless standard activities

WP8a objectives have largely contributed to Wireless Standard activities.

3.1 Analysis of market, user and mobile network provider requirements

All  relevant  stakeholders  with  demands  on  security  and  trust  requirements  are
identified. An introduction to present day mobile phone features with security needs is
given.  Amongst others, this covers system software update, installation of application
software, SIM-lock, IMEI  protection, digital rights management schemes and features
exploiting  (U)SIM  card  protection  capabilities.  Also    emerging  features  such  as
broadcast protection schemes are considered. Existing standardised mechanisms to
address the corresponding security demands in terms of functionality or robustness
are referenced, if applicable.
An analysis of documents from 3GPP, OMTP, university reports, OMA, TCG and GSMA
reports was carried out and was based on investigation of publicly available standards,
literature search, and the experience brought to the project by Infineon Technolgies
and Comneon, two companies which have been active in the mobile phone industry
for the last two decades. Recent standardization efforts on platform security provided
by the OMTP and TCG Mobile Working Group were selected for detailed  analysis.
The  market  requirements  extracted  were  considered  in  terms  of  the  different
stakeholders   in   the   mobile   phone   arena.   These   were   the   mobile   phone   network
operator, the mobile phone user, the mobile phone manufacturer, content providers
(considering the DRM business), service providers, and enterprise customers. Typical
user  requirements,  are  theft  protection,  or  privacy  protection.  The  Mobile  Network
Operator  has  many  requirements  which  are  concerned  with  protecting  outlayed
investment in mobile phone network, and subsidised mobile phones.
The more detailed analysis which focused on the platform security used the  Trusted
Computing Group's Mobile Working Groups Use Case document, as this is the most
comprehensive use case document available. In order to discuss and analyse platform
security, we took the OMTP TR0 Hardware Security Requirements, as this was the best
document available for this aspect of the work. Infineon also took part in the OMTP
TR0 Hardware Security Standardisation work.

3.2 OMTP (Open Mobile Terminal Platform)

OMTP  is an operator  sponsored  forum  which  aims  to  serve  all  stakeholders  in  the
mobile phone value chain by gathering and driving requirements. The requirements
are  technology  platform  neutral  and  aim to promote  the  adoption  of  new services
across a range of platforms.
OMTP aims to:

Make applications more usable so that user adoption is rapid.

Allow simpler customisation of services .

Allow MNOs to create a similar look and feel across platforms.

Standardise non-differentiating features (also called defragmentation).

Security issues are addressed in the OMTP Application Security Working Group, and in
the OMTP Hardware Security Requirements Group.

Open_TC Deliverable 10.8

9/13

background image

D10.8 Final Standardisation report

WP8 continued working with and observing mobile security standards developments.
We again concentrated on TCG and OMTP. We followed and analysed the work of the
TCG Mobile Working  Group which produced and published mobile  security relevant
documents. These were  the TCG Mobile Trusted Module Specification and The TCG
Mobile  Reference  Architecture  specification.  We  looked  at  these  documents  in
particular for the preparation of an internal report 'Investigation of TC Life cycle Issues
for Main Use Cases'.

OMTP security work also continued to be a main focus. OMTP is currently working on
an extension of the TR0 Basic Trusted  Environment. This is the Advanced Trusted
Environment  (TR1).  TR1  makes  use  of  a  threat  analysis  work,  and  has  defined
recommendations for  security enablers such as secure storage and trusted execution
environments.  IFX  has  been  taking  part  in  this  standardization  work.  This  includes
telecons, face to face meetings, and specification review work. We will consider the
security  architectures  defined  in  WP8  in  terms  of  these  latest  standards
developments.

3.3 Open Mobile Association (OMA)

IFX is a member of the  Open Mobile Association  (OMA) which defines most of the
issues  of  the  mobile  phone  world.  This  also  includes  the  security  requirements  of
mobile phones and implementation standards e.g. for DRM.

3.4 Software Defined Radio Forum (SDRF)

In   addition,   the   RHUL   team   has   participated   in   the   Software   Defined   Radio   Forum
(SDRF) security working group:

1. Examining how trusted computing functionality may be integrated into the SDR

security architecture in order to meet their requirement set.

2. Discussing how the work on secure software download may be integrated into

the SDR security architecture.

In  November  2006  (M13)  E.  Gallery  presented  an  invited  paper  at  the  Software
Defined  Radio  Technical  Conference.  Paper  Reference:  E.  Gallery  and  C.J.  Mitchell,
“The Use of Trusted Computing Technologies in the Provision of High Assurance SDR
Platforms”, In Proceedings of the  5

th

 Software  Defined Radio Technical Conference,

Orlando, Florida, 13-15 November 2006. E. Gallery has also participated in two SDR
members meetings, the first held on 16-17 November 2006 (M13) and the second held
on 16-17 April 2007 (M18). Work completed within this group has been drafted to a
SDR security standard which is undergoing review by the SDRF.

Digital Rights Management (DRM)

4.1 Digital Rights management related standardisation activities

The use of TCG mechanisms in digital rights implementations are expected to be one
of the main application and use fields of  trusted computing solutions in the future.
There is also a large expected economic impact for the management and trading of
media content but also as well of securing the conditional access to and processing

Open_TC Deliverable 10.8

10/13

background image

D10.8 Final Standardisation report

organisational (industrial, governmental) and private data.
Due to some political and societal discussions, the use of TC technology to support
DRM has not been analysed and researched in detail. As TUM/LDV has a broad back-
ground in working on DRM-oriented standards they made main contributions to the
use of TC technology for protecting media rights.  Media coding standards including
security features (MPEG-4 and MPEG-21 REL, RDD, IPMP), which facilitate the develop-
ment of interoperable DRM is a topic covered by Technical University Munich (LDV).
Using Trusted Computing mechanisms for digital rights applications is expected in the
future. There is a large economic impact expected in the management and trading of
media content. Additionally, ensuring conditional access to organisational data (e.g.
industrial  and  governmental  scenarios)  for  supporting  privacy  and  economical  in-
terests may be an important future use of this technology.

4.2 MPEG participation

The LDV participated in the MPEG standardisation work to promote the Open Release
MAF and especially in two main standardisation meetings.

76



th

    MPEG Meeting – Montreux





The  76

th

  MPEG  meeting  took  place  from  03.04.2006  till  07.04.2006  in  Montreux.

During this meeting a proposal for the Open Release MAF was raised for the first time.
The contributed document describes Use Cases and the preliminary requirements for
the proposal. Additionally, a prototype of the system was presented, which shows the
basic concept and the usage of the DRM System. The Proposal reached the status
“Under Consideration”.

77



th

    MPEG Meeting – Klagenfurt





The  77

th

  MPEG  Meeting  was  held  between  the  17.07.2006  and  the  21.07.2006  in

Klagenfurt.  The  LDV  presented  a  document  containing  enhanced  Use  Cases  and
Requirements for the Open Release MAF. There was a discussion about the underlying
REL Structure, which was proposed by other partners. It was agreed, that these issues
should be clarified until the next meeting.
The standardisation efforts in the MPEG group led to the specification of a lightweight
DRM system based on MPEG-21 standards and the joint development of a creative
commons  licence  scheme  for  such  a  system.  The  development  activities  for  this
standard (known as OpenRelase MAF) contributed to the extension of MPEG-21 tools in
DRM systems. In detail, this includes modules like REL (Rights Expression Language),
RDD(Rights Data Dictionary), MPEG-21 file-format, EV (event reporting) as well as the
support of Creative Commons licensing in a DRM system.

ETSI standardisation

POLITO  is  member  of  the  ETSI  Technical  Committee  on  Electronic  Signatures  and
Infrastructures  (TC-ESI)  and  has  contributed  TCG  results  to  the  field  of  signing
applications   and   worked   also   within   the   corresponding   national   body   in   Italy
(UNI/UNINFO).

Open_TC Deliverable 10.8

11/13

background image

D10.8 Final Standardisation report

Conclusion

From  the  first  planning  stage  of  this  project  we paid  attention  to ensure  intensive
cooperation between industry, SME and research organisations. At that time trusted
computing  was  still  mainly  industry  driven  and  main  standardisation  activities  for
trusted computing happened only inside the TCG.
Over the course of the project we managed to achieve intensive cooperation between
the  OpenTC  and  the  TCG.  Other  standardisation  organisations  also  benefited  as  a
consequence of our activities. One of the most important results from this cooperation
and  standardisation  activities  is  the  acceptance  and  adaptation  of  the  trusted
computing  standards  by  academic  and  research  organisations.  Today  we  have  an
increasing amount of conferences and research meetings on the subject of trusted
computing. European TC research and scientific activities are now well known all over
the world.

Open_TC Deliverable 10.8

12/13

background image

D10.8 Final Standardisation report

List of Abbreviations

CRTM

Core Root of Trust measurement

DAA

Direct Anonymous Attestation protocol. Digital authentication
between network instances based on zero knowledge algorithm.

CAPI

Crypto Application Interface

DRM

Digital rights management

ETSI

European Telecommunications Standards Institute

DRTM

Dynamic Root of Trust measurement standard

JAVA

Object oriented programming technology and language (not an
abbreviation)

ISO

International Standardisation Organisation

MAV

Multi Access Video

MPEG

Moving Pictures Expert group, Standardisation groups for Video and
Audio Coding

OASIS

Organization for the Advancement of Structured Information
Standards

OMA

Open Mobile Association

OMTP

Open Mobile Terminal Platform

PAS

Public Available Standard

TCG

Trusted Computing Group

TSS

Trusted Software Stack (API between TPM and host system)

TPM

Trusted Platform Module , TCG standards security chip

3GP

3rd Generation Partnership Project , worldwide cooperation of
standardisation gremia for mobiles, esp. for UMTS and GERAN (GSM)

Open_TC Deliverable 10.8

13/13
