Executive Summary

V0.1

OpenTC

Executive summary of the first project year

1   Executive summary

Introduction

The Open Trusted Computing (OpenTC) project develops a trusted and secure
computing   systems   based   on   open   source   software.   This   IST   FP6   project   No
027635   targets   traditional   computer   platforms   as   well   as   embedded   systems
such   as   mobile   phones,   aiming   to   reduce   system-related   threats,   errors   and
malfunctions. In today's computing platforms, the lack of security has given rise
to waves of successful  attacks and system crashes, resulting in severe economic
damage   to   enterprises   and   private   users,   as   well   as   endangering   critical
infrastructure.   Using   the   trust   and   security   approach   of   the   OpenTC   project,
system-protection   measures   will   be   an   integral   part   of   the   computer   system
kernel.   The   weaknesses   of   today's’   computers,   which   require   that   insecure
operating systems are shielded by an ever increasing number of protective layers
such   as   virus   scanners   and   firewalls,   will   be   complemented   and   potentially
replaced by integrated trust and security.
OpenTC will improve reliability during authentication, making it easier to defend
against   current   network   threats   such   as   phishing,   viruses,   trojan   horses,
corruptive software and other attacks from hostile sources. Another advantage of
OpenTC is that it enables computers to run critical applications such as trusted
banking or e-commerce software in their own, sealed off, compartments that are
protected against external access. The framework developed in this project can
eliminate most current assaults and dangers in the computing world.
These techniques can also be employed to ward off threats to the reliability and
security  of   applications   and  software  in  devices  such  as,   for  example,  mobile
phones. Insecure and unreliable behaviour can be eliminated from the start in
new IT-based equipment and applications by exploiting the results of the OpenTC
project.   The   results   will   be   open   source   and   freely   available   to   users   and
researchers.

General technical goals

The enabling technology used in OpenTC for computer security is the design and
implementation   of  a  layered  system  architecture   in  which  a  special  computer
chip, the Trusted Platform Module (TPM) – similar to a smart card – performs the
security functions in a protected hardware environment. The OpenTC project has
three major technical objectives:

Developing a secure operating system architecture consisting of universal
virtualization layers, Trusted Software Stack (TSS) for Linux, and TC and
TPM management software

Producing management infrastructures and software protocols for Trusted
Computing in the areas of policy management, including distributed policy
enforcement,   security   state   monitoring   and   management

,

network

management, and configuration management software

Producing prototype applications for Trusted Computing system support in
the   areas   of   CA,   PKI,   attestation   and   zero   knowledge   authentication,
Trusted WYSIWYS (What You See Is What you Sign) and Proof-of-Concept
for digital signing and verification).

Open_TC  Activity Report 1

1/4

background image



Executive Summary

V0.1

To   support   these   prototypes,   OpenTC   addresses   the   Integration   of   TC   into
existing Public Key Infrastructures and the adaptation of TC APIs (especially the
TSS stack of the TPM) to other programming languages, in particular JAVA.

First years results

The General Requirement and Specification was produced and reviewed within
the first six months. Work on this document also yielded a number of convincing
use cases that served as guidance for subsequent work on platform, protocol and
management characteristics. The document also includes a user survey and a
media   analysis.   It   is   currently   under   review   for   its   second   version   to   include
additional aspects revealed during the work on prototypes.
At the level of basic interfaces and trust layers, we have produced components
for bootup measurement. They cover both the legacy concept of a trusted boot
chain as defined by the TPMv1.1b specification (Trusted GRUB v0.9.8) as well as
the the new mechanisms provided by the TPMv1.2 specification in conjunction
with  new  CPU  initialization  features  (OSLO boot  loader for L4,  TPM  v1.2/

skinit

support integrated in GRUB 2.0 and

Xen

). A Linux-based implementation for the

Trusted Software Stack

 as defined by the TCG was produced. In parallel, a JAVA

interface for the TSS was developed using an existing TSS. The integration of
both components is currently under test.
At the level of trusted virtualization and operating systems, we developed a first
version of a basic management interface common to both virtualization layers
(Xen   and   L4)   used   by   OpenTC.   Mechanisms   for   generic   tasks   and   inter-task
communication   were   developed   for   Xen   that   will   allow   to   implement   security
services with a drastically reduced Trusted Computing Base.   Several security
services for Xen and L4 were designed and prototyped. Working towards the goal
of a unified user experience and common architectural principles we designed
and implemented a demonstrator prototype.
At the level of security management and infrastructure we gathered, analysed
and   compiled   requirements   for   data   centre   based   computing   services.   The
results of this analysis were submitted as input for the specification activities of
the Basic Management Interface. The analysis resulted in a comprehensive white
paper detailing use case scenarios, corresponding work flows, and management
activities. We delivered a life cycle model for managed execution environments
and the first version of a design and prototype for configuration management, an
analysis of the requirements for property-based attestation and the design of a
corresponding system model.  Finally, we designed and implemented prototypic
security services as part of the the demonstrator prototype.
At   the   level   of   prototype   and   test   applications   for   proof-of-concept   and   use
examples, we have produced outlines of their applications designs as part of the

General Requirement and Specification

. These application designs were refined in

a   subsequent   cycle   and   broken   down   into   work   plans   where   required   by   the
Technical  Annex.  The  start  of implementation  activities  on  the  actual OpenTC
architecture is linked to the release of the project's first demonstrator prototype,
which   is   scheduled   for   end   of   January   2007.   One   application   (multi-factor
authentication)   was   chosen   as   early   proof-of-concept   'yardstick'   for   the
demonstrator prototype.
At the level of development support, quality evaluation and certification, we have
investigated   the   appropriateness   of   currently   available   tools,   development
models and procedures for Open Source software development in general and
OpenTC's development efforts in particular. This yielded a general methodology
for the production of trustworthy systems and software. Within the first year we
developed, extended and adapted tools for automated source code analysis and
vulnerability testing to make them applicable for the code base of OpenTC. They

Open_TC  Activity Report 1

2/4

background image



Executive Summary

V0.1

are the starting point for an in-depth analysis to carefully chosen, security critical
components of the OpenTC architecture (e.g., memory or I/O management and
sharing).   We   have   also   worked   on   best-practice   principles   and   programming
guidelines for developers that are geared towards the production of evaluable
code.
In the work area of applying trusted computing for embedded controllers and
mobile   phones,   we   have   produced   an   analysis   of   market,   user   and   mobile
network   provider   requirements   which   yielded   a   minimum   set   of   trust
functionalities for this application context. Security and policy requirements for
TC   on   a   mobile   platform   were   determined   by   analysing   key   application
requirements, resulting in an initial design overview of a trusted mobile OS. The
L4/fiasko   microkernel   was   selected   as   appropriate   starting   point   and   partially
ported to the S-GOLD platform. We have produced OMA DRM v2 and IMEI: use
case description, requirement analysis and TPM and TSS mapping/profiling and is
currently   competing   the   same   procedure   for   software   download   and   secure
software use.

Dissemination of knowledge and results

To  enable  maximum  community   benefit,  the  project  results  will  be integrated
into, and distributed as, Open Source software, supporting Linux in particular. A
main objective is the development of complete trusted Linux kernels for different
use   classes,   which   will   be   distributed   as   part   of   the   Novell/SUSE   (a   project
member) Linux distribution package.
At   the   level   of   dissemination   and   training,   we   have   worked   on   establishing
concepts   and   results   of   OpenTC   in   the   areas   of   scientific   activities,
standardization, and education. OpenTC partners were present at 12 national and
14 international presentations at public events (conferences, business events),
10 national and 12 international articles published in various media, ranging from
scientific   conferences   to   Internet   websites.   Further,   2   national   and   12
international   collaborations   were   set   up   between   project   partners   and   other
institutions   or   companies,   and   a   close   partnership   with   the   German   EMSCB
project was established. Activities on standardization included a proposal for the
Open Release MAF (MPEG Application Format) in particular within the MPEG-A
Standard, and collaborations on standardization activities with companies from
Spain and Korea. We actively participated at the First European Summer School
on Trusted Infrastructure Technologies in Oxford, including a research workshop
on “Future TPM Functionalities”.
By making the project results widely available, the OpenTC consortium expects to
encourage   Europe’s   IT   industry   to   invest   in   trust   and   security   development.
Especially   small   and   medium-sized   enterprises,   industry,   and   research
institutions will be enabled to develop and market trusted computing systems
and applications independently. The integration of trust and security into next-
generation European products will make these more competitive on the world
market.

Open Trusted Computing partners

The OpenTC project is formed by an international multidisciplinary consortium
consisting of 23 partners: Technikon Forschungs- und Planungsgesellschaft mbH
(project   coordination,   AT);   Hewlett-Packard   Ltd   (technical   leader,   UK);   AMD
Saxony LLC & Co. KG (DE); Budapest University of Technology and Economics
(HU);   Commissariat   à   l’Energie   Atomique   –   LIST   (FR);   COMNEON   GmbH   (DE);
Forschungszentrum   Karlsruhe   GmbH   –   ITAS   (DE);   Horst   Görtz   Institute   for   IT
Security,   Ruhr-Universität   Bochum   (DE);   IBM   Research   GmbH   (CH);   Infineon
Technologies   AG   (DE);   INTEK   Closed   Joint   Stock   Company   (RU);   ISECOM   (ES);
Katholieke Universiteit Leuven (BE); Politecnico di Torino (IT); Portakal Teknoloji

Open_TC  Activity Report 1

3/4

background image



Executive Summary

V0.1

(TR); Royal Holloway, University of London (UK); SUSE Linux Products GmbH (DE);
Technische   Universitaet   Dresden   (DE);   Technische   Universitaet   Graz   (AT);
Technische   Universitaet   Muenchen   (DE);   Technical   University   of   Sofia   (BR);
TUBITAK – UEKAE (TR); and University of Cambridge (UK).

Open Trusted Computing consortium

The total volume of the project is estimated to 17.1 Million Euros, part of which
will be contributed by the EC. Visit www.opentc.net to learn more.

For further information please contact:
Technikon Forschungs- und Planungsgesellschaft mbH
Richard-Wagner-Strasse 7, 9500 Villach, Austria
Tel.: +43 4242 233 55-0, Fax: +43 4242 233 55-77
Email:

coordination@opentc.net





OTC Logo

OTC Disclaimer

The   information   in   this   document   is   provided   “as   is”,   and   no   guarantee   or
warranty is given that the information is fit for any particular purpose. The user
thereof uses the information at its sole risk and liability.
