 Publishable Activity Report OpenTC

D01.6 Final Reports (M01-M42)

Publishable Activity Report

Project number

IST-027635

Project acronym

Open_TC

Project title

Open Trusted Computing

Deliverable type

Report

Deliverable reference number

IST-027635/D01.6/1.1

Deliverable title

Publishable Activity Report

WP contributing to the deliverable

WP01

Due date

April 2009 - M42

Actual submission date

June 3

rd

, 2009

Responsible Organisation

TEC

Authors

TEC, HP with contribution of all partners

Abstract

This report gives a publishable summary of all
activities performed by each partner for the

full project duration.

Keywords

OpenTC, objectives, activities, presentations,
budget, management, results

Dissemination level

Public

Revision

1.2

Instrument

IP

Start date of the
project

1

st

 November 2005

Thematic
Priority

IST

Duration

42 months

OpenTC  Publishable Activity Report

1/40



background image



 Publishable Activity Report OpenTC

Table of Contents

Table of Contents

1  Introduction and Overview..................................................................................................................3

1.1  The Development of the OpenTC Framework ............................................................................4

1.1.1  Phase 1 (M01-M12)..............................................................................................................4
1.1.2  Phase 2 (M13-M24)..............................................................................................................5
1.1.3  Phase 3 (M25-M42)..............................................................................................................5

1.2  Dissemination of Knowledge and Results....................................................................................7
1.3  Exploitation of Final Results.........................................................................................................7
1.4  Future Directions.........................................................................................................................8
1.5  Open Trusted Computing Partners..............................................................................................8
1.6  OTC Logo..................................................................................................................................10
1.7  OTC Disclaimer.........................................................................................................................10

2  Project Execution .............................................................................................................................11

2.1  WP02: Requirements Definition and Specifications...................................................................11

2.1.1  Progress towards objectives...............................................................................................11
2.1.2  Major Achievements...........................................................................................................12

2.2  WP03: Basic Interfaces and Trust Layers..................................................................................13

2.2.1  Progress towards Objectives..............................................................................................13
2.2.2  Major Achievements...........................................................................................................14

2.3  WP04: Trusted OS Development...............................................................................................14

2.3.1  Progress Towards Objectives.............................................................................................14
2.3.2  Major Achievements...........................................................................................................15

2.4  WP05: Security Management and Infrastructure.......................................................................16

2.4.1  Progress Towards Objectives.............................................................................................17
2.4.2  Major Achievements ..........................................................................................................19

2.5  WP06 Use Examples / Prototype Applications for Proof-of-Concept ........................................19

2.5.1  SWP6a: Digital Rights Management...................................................................................20
2.5.2  SWP6b: Message Exchange Infrastructure........................................................................20
2.5.3  SWP 6c: Electronic Signature Application Prototype..........................................................21
2.5.4  SWP6d Encrypted File Service...........................................................................................23
2.5.5  WP6e: Multi-Factor Authentication......................................................................................23

2.6  WP07: Development Support, Quality, Evaluation and Certification Description.......................24

2.6.1  Progress Towards Objectives.............................................................................................25
2.6.2  Major Achievements...........................................................................................................26

2.7  WP 08: Trusted Computing for embedded controllers and mobile phones................................26

2.7.1  Progress towards objectives...............................................................................................27
2.7.2  Major Achievements:..........................................................................................................28

2.8  WP09: Distribution of Trusted Linux Platform and Modules.......................................................28

2.8.1  Progress towards Objectives..............................................................................................28
2.8.2  Major Achievements...........................................................................................................29

2.9  WP10: Dissemination, Exploitation and Training.......................................................................29

2.9.1  Objectives ..........................................................................................................................29
2.9.2  Progress Towards Objectives.............................................................................................30
2.9.3  Major Achievements...........................................................................................................36

3  Dissemination and Use (“Publishable Results”)................................................................................38
4  List of Abbreviations.........................................................................................................................39

OpenTC  Publishable Activity Report

2/40

background image



 Publishable Activity Report OpenTC

1   Introduction and Overview

This section describes the project's activities, progress and achievements from the
perspective of the overall technical management. We start with a brief summary of

OpenTC's initial aims and work plan.
OpenTC was conceptualised in 2004 and started in November 2005. The project's

primary   goal   was   to   research   and   implement   components   for   an   Open   Trusted
Computing framework that should be based on technology defined by the Trusted

Computing Group (TCG) and operating system virtualization techniques. Our general
aim   was   to   combine   low-level   mechanisms   for   isolation   of   data   and   execution

environments, configuration measurement and attestation to enhance the trust and
security properties of standard operating systems, middleware and applications. The

general architecture and, if possible, individual components of the framework should
be applicable to a variety of platform types. Supporting Linux in particular, practical

work address the areas of security enhanced OS architectures, of related protocols
and software and of applications using TC technology.
The   OpenTC   work   plan   defined   three   specific   objectives   to   guide   the   research
performed in the project:

1. Design and development of universal virtualization layers, a trusted software

stack for Linux, and management software for Trusted Computing in general

and Trusted Platform Modules in particular

2. Design   and   development   of   infrastructure   and   management   components

supporting   the   management,   configuration   and   monitoring   of   policies,
networks and security state information

3. Design   and   develop   supporting   software   and   applications   for   public   key

management   and   attestation,   adapting   Trusted   Computing   APIs   and

implementations   to   the   Java   development   environment,   and   investigate
components necessary for advanced use cases such as a 'What you sign is

what you see' electronic signature scheme.

The major exploitation path of the project was to release results under Open Source

licenses.   As   a   consequence,   OpenTC's   objectives   included   the   investigation   of
methodological   and   feasibility   issues   for   the   evaluation   and   certification   of   Open

Source software in general and of Linux and OpenTC results in particular.
OpenTC's technical work was structured into ten work packages. Two of them cover

the general and technical management, the overall specification and work on legal,
social and normative context factors. Work package 3 is geared towards providing

the low-level primitives for Trusted Computing technology, including software layers,
language   support,   and   cryptographic   protocols.   Work   package   4   concerns   core

characteristics   of   single   trusted   platforms,   notably   hypervisor   layers,   operating
system   support,   adaptation   of   Trusted   Computing   technology   for   virtualized

execution   environments.   Work   package   5   centers   around   the   provision   of
infrastructure and management support for distributed trusted platforms, including

an area of investigation about novel directions for Trusted Computing hardware and
software. Work package 6 is dedicated to applications utilizing Trusted Computing

technology in general and Trusted Virtual Platforms developed by WPs 3, 4 and 5 in
particular.
The task of work package 7 was to investigate and perform different approaches to
testing Open Source software packages with particular focus on the Trusted Software

stack   and   the   hypervisor   layers.   Work   package   8   addressed   questions   that   are
specific   for   employing   TC   technology   on   mobile   and   embedded   platforms.   Work

package   9   covered   the   integration,   configuration   and   packaging   of   OpenTC
components   and   tailored   operating   system   images     from   scratch,   producing   fully

fledged distributions by means of an audited and highly automated work flow. Finally,

OpenTC  Publishable Activity Report

3/40

background image



 Publishable Activity Report OpenTC

work  package   10  was   dedicated   to   documenting   and   disseminating   research   and
development results, producing training material and coursework and to planning the

exploitation of project.
We   would   like   to   remind   the   reader   of   some   important   factors   that   shaped   the

structure   and   goals   of   this   project.   It   was   conceived   in   late   2004   when   Trusted
Computing technology was a somewhat controversial topic and was equated with

locked-down, proprietary systems and the enforcement of digital rights. At that point
in time, it was even uncertain whether important Open Source licenses such as the

GPLv3 would allow future combinations software developed under these licenses with
hardware-based TC mechanisms. The level of IPR surrounding the technology was

complete unknown, and it was far from obvious which target platform type (client,
server,   mobile,   embedded)   was   the   most   future-proof   one   for   investigating   open

approaches to Trusted Computing.
OpenTC   started   out   in   an   environment   that   was   still   very   much   in   flux.   In   the

meantime,   the   project   had   to   rely   on   careful   risk   management   and   dynamically
adapted   to   technical   and   economic   changes.   As   our   work   closes   off,   many

controversial   aspects   have   been   settled   (some   still   remain).   We   are   grateful   of
having   had   the   opportunity   to   contribute   to   this   development.   Our   results   have

helped   to   shed   light   on   several   open   technical   issues,   initiated   and   influenced
standardization activities, developed new practices, and have advanced the state of

technology in this field.

1.1  The Development of the OpenTC Framework

The OpenTC framework was developed in three main stages. Each of these stages

was guided by a proof-of-concept prototype for a well understood use case that built
upon   each   other.   This   evolutionary   approach   allowed   to   gradually   increase   the

complexity   of   the   framework,   integrating   additional   components   in   a   stepwise
fashion. The following sections describe the evolution of the framework during the

three work phases. Due to its briefness, this overview is necessarily incomplete. For a
more comprehensive overview,  the reader should refer to the activity reports for the

respective reporting phases.

1.1.1  Phase 1 (M01-M12)





The   use   case   covered   in   the   first   review   period   addressed   a   security   enhanced
browser environment for critical online transactions such as electronic banking. In

essence, it provided  a virtualization layer and operating system compartments that
would   isolate   runtime   instances   of   Linux   and   standard   applications.   During   this

phase, OpenTC developed core components for trusted and authenticated boot-up,
mutual remote attestation, and interfaces to the TC hardware and its software stack.

Important   insights   gathered   during   this   period   concerned   the   measurement   of
hypervisors, operating system images and software components, their separation in

static   and   dynamic   parts,   the   management   support   necessary   for   administering
'known good' trust metrics, the build process for tailored OS images, and issues faced

when integrating TC mechanisms with cryptographic transport protocols.
Conceptual work was carried out regarding use case scenarios for trusted virtualized

clients and trusted virtual infrastructure were defined, analyzed and embedded in the
project's   high-level   technical   specification.   The   work   packages   on   applications,

mobile   platforms   and   evaluation   investigated   technical   options,   produced   their
specifications and determined the platforms, tools, and technology for development

and testing.
The major technical results at the end of this phase were a basic PKI infrastructure

for   issuing   credentials   for   attestation   identity   keys,   a   first   set   of   components   for
interfacing   TC   hardware   and   for   measuring   software   images   and   executables.

Support   for   static   and   dynamic   trusted   boot   and   for   mutual   remote   attestation
between   clients   and   servers,   IPC   mechanisms   for   generic   hypervisor   tasks   as   a

OpenTC  Publishable Activity Report

4/40

background image



 Publishable Activity Report OpenTC

prerequisite  for  service   decomposition,  and  a  partial  Java  interface  to  an  existing
Trusted   Software   Stack   were   developed.   An   application   prototype   for   multi-factor

authentication was designed and implemented.
While the framework components developed during the first reporting phase were fit

for purpose, the integrated proof-of-concept prototype built with these components
still had to cut corners since supporting components were still missing. Experiences

with the first proof-of-concept prototypes sharpened the project's focus on usability
and user interface questions for virtualized client platforms.

1.1.2  Phase 2 (M13-M24)





OpenTC released its first proof-of-concept prototype that was based on a stripped-

down version of Debian Linux (DSL). The amount of work that had to be put into this
release suggested that building more complex OpenTC distribution from these kinds

of   minimal,   but   sparsely   supported   versions   of   Linux   would   exceed   the   project's
resources. The project therefore decided to transfer and synchronize its intermediate

results with the official release cycle of OpenSuSE distributions. While this required
substantial effort, it allowed to employ an industry grade, highly automated build and

packaging system from then on.
The   technical   activities   during   this   phase   were   guided   by   requirements   from   the

'Corporate Computing at Home' (CC@H) use case developed by the project. The list
of   technical   achievements   includes   the   finalization   of   the   work   on   supporting

advanced CPU architectures for AMD CPUs. The Linux port for the Infineon TSS was
made   available,   Java   wrappers   for   C-implemented   Trusted   Software   Stacks   were

extended to cover their full functionality, and work on a purely Java based TSS was
taken   up.   Mechanisms   for   service   disaggregation   were   extended   to   cover   policy

controlled IPC and I/O mechanisms for both hypervisors. Xen services for console I/O
and GUIs, compartment launching, and networking, trusted virtualised storage and

integrity/credential   management   were   prototyped,   and   the   Xen   hypervisor   was
improved   to   allow   the   hosting   of   proprietary   operating   systems.   Selected

components of the L4 microkernel were ported to a test platform for mobile devices.
Designs,  specifications  and  test plans  were   produced  for  all  applications,  most  of

them accompanied by first prototypic implementations. The first version of the PKI
subsystem was finalized and published.
Progress   on   software   evaluation   methods   had   evolved   to   a  point  that   allowed   to
subject  large   software   packages   to  black  and   white   box  testing.  Such   tests   were

performed for the Linux port of the Infineon TSS and the core components of the Xen
hypervisors. At a conceptual level, the project developed requirements and design

for Trusted Virtual Domains applied to trusted virtual datacenter architectures, and
extensive   basic   research   on   present   and   future   directions   for   Trusted   Platform

Services was performed.
The second phase was finalized with prototypes for most security components for

single trusted platforms  in place. The  CC@H  proof-of-concept prototype combined
these components into a compelling use case: a virtualized trusted client platform

with   integrity  measurement,  support  for   hosting   legacy  operating   systems,   and   a
user   interface   supporting   easy   interaction   with   different   compartments   and

provisions to counter the mimicry of trusted GUI components.

1.1.3  Phase 3 (M25-M42)





The second proof-of concept prototype 'Corporate Computing at Home' was extended
and ported to an up-to-date distribution of OpenSUSE. By this time, OpenTC made full

use of the automated SuSE build an packaging process. The result was released as
Open Source distribution under GPLv2. It includes all components necessary to run

the use case, including infrastructure and server elements to generate certificates
and perform remote attestation.
An important strand of the work continued on selected aspects of virtualized clients.

OpenTC  Publishable Activity Report

5/40

background image



 Publishable Activity Report OpenTC

Additional user studies were performed, on the design of a suitable graphical user
interface in particular, which were soon extended into investigations on a complete

redesign   of   the   whole   graphics   subsystem.   The   result   is   a   hypervisor-agnostic
architecture for high performance graphics virtualization. A prototype was developed

for   for   client   OpenTC   platforms   running   Xen   that   proved   a   big   reduction   of   the
amount of graphics related trusted code base.
Regarding low level platform components, the Linux port of the Infineon TSS to Linux
and a new releases of the Java TSS were finalized, and key management components

were   redesigned   and   equipped   with   configuration   templates   for   ssh,   IPSec,   and
Racoon.  PKCS#11.  PKI   management   components   were   extended   with   simplified

communication   protocols   for   multiple   languages,   and   prototypes   for   Trusted
Channels   were   developed.  The   implementation   of   the   virtual   network   switch   was

extended to include IPSec as transport protocol, and the virtual TPM architecture was
integrated with the hypervisor Basic Security Management Interface (BMSI) and the

integrity management component (HIM).
The bulk of the technical work was driven by datacenter scenarios, which drove the

work on the last proof-of-concept prototype. It covers a large subset of the OpenTC
framework, including policy management security enforcement mechanisms of the

OpenTC platform. Several additional building blocks were designed and integrated as
support   for   Trusted   Virtual   Domains:   TVD   master   and   proxy,   the   virtual   network

switch,   components   for   storage,   machine   life   cycle   management,   and   extended
public key infrastructure.
The partners also developed a lightweight management infrastructure based on the
cross-hypervisor   management   interface   of

libVirt.

A   CIM   provider   for   TPM   was

prototyped   based   on   a   DMTF   draft   analysis,   Research   on   new   directions   and
foundations of Trusted Computing led to a number of high-profile publications.
All application-related sub-work packages delivered their implementations. The use
cases and proof-of-concept span the fields of digital rights management, messaging

infrastructure,   electronic   signatures,   encryption   file   service   and   multi-factor
authentication. The work package also provided the security model requirements and

refinements for a minimal API for the security services.
Confidence   in   the   underlying   hypervisors   is   empirically   supported   by   the

comprehensive   black   box   testing   and   static   code   analysis   performed   on   these
components. No vulnerabilities that would compromise Xen isolation mechanisms for

execution domains. Static analysis also indicated a high quality of the L4 and OSLO
boot loader implementations. Further targets were the new, Gallium based graphics

virtualization implementation and the TPM driver for TrouSerS. Important community
benefit was achieved by publishing the ACSL specification language, releasing and

supporting   the   FRAMA-C   analysis   toolkit   for   public   use,   and   by  disseminating   the
extended Open Source Testing Methodology.
Microkernel-based OS components and the TPM emulator were ported to the Infineon
S-GOLD3   development   platform   for   mobile   devices.   For   this   context   a   detailed

security analysis performed. Based on the analysis of requirements a Secure Wallet
design   and   implementation,   a   comprehensive   set   of   mechanisms   necessary   to

implement trusted applications for mobile platforms was determined.
OpenTC took care to base its final release on the most recent release of OpenSUSE.

This required the huge effort of two porting, integration and packaging cycles. Our
final   results  will   be   released   as   a   dedicated   distribution   OpenSUSE   11.1.   The

integration   of   the   OpenTC   build   process   with   user   friendly   graphical   interfaces
provided by SuSE Studio promises to greatly simplify the production of distributions

and   purpose   build   execution   environments   in   future.   The   exploitation   plan   was
finalized   and   started   to   put   into  practice.   First   successes   include   the   adoption   of

OpenTC   results   in   products   and   product   roadmaps   of   several   industrial   OpenTC
partners. OpenTC partners continued their work on standardizing in the context of

OpenTC  Publishable Activity Report

6/40

background image



 Publishable Activity Report OpenTC

the Java Community Process and the Open Mobile Terminal Platform Group.
Finally, OpenTC extended its activities on dissemination and exploitation, informing

the experts as well as the non-expert public about the challenges addressed and
research achieved in research on trusted computing, platforms, and infrastructure.

OpenTC has been well recognized both on the European as well as the international
scale   and   has   fostered   numerous   scientific   exchanges   between   scientists   and

researchers in Europe, Asia and the US. OpenTC was instrumental to create a thriving
research ecosystem on trust technology in IT that will continue to thrive beyond the

duration of the project. The decision to work on the basis of Open Source Software
has greatly contributed to this success.

1.2  Dissemination of Knowledge and Results

In line with the strategy pursued during the previous reporting periods, the project's
results of year two were packaged and  distributed as  Open  Source under GPLv2.

Since mid-2008, the release is produced by the OpenSUSE build system KIWI. The
packaging   of   the   end   release   is   in   progress,   and   a   version   including   the   latest

updates and bug fixes will be finalized in mid 2009. The minor shift in the planned
release   date   is   due   to   the   project's   decision   to   deliver   its   results   with   the   latest

available OpenSUSE distribution 11.1, which involved additional porting efforts.
OpenTC   maintained   a   high   level   of   dissemination   and   training   activities,   firmly

establishing its concepts and results in academic research and publishing, training,
and standardization. During the reporting period, OpenTC's results were presented in

about  100   mostly   international   conferences   and   workshops.   The   project   partners
published some  95 scientific papers and articles, and participated in more than  65

presentations, talks, and discussion rounds. In addition 16 academic courses were
designed and delivered to national and international audiences. As in the previous

period,   the   new   proof-of-concept   prototype   from   year   two   was   extended   and
employed   as   training   system.   For   the   foreseeable   future,   the   final   OpenTC   core

architecture  will be maintained  as  a base  platform  for  academic  and  professional
training.

1.3  Exploitation of Final Results

A subset of framework components developed by OpenTC during the final reporting
period was integrated for the final review in a proof-of-concept prototype for Trusted

Virtual Datacenters. This  demonstrator will be included in  the final release  of the
framework,   which   will   be   released   under   Open   Source   license   as   dedicated

OpenSUSE 11.1 distribution.
In   addition   to   this   distribution,   OpenTC   results   already   have   been   or   are   in   the

process of being exploited by various partners. The components for a disaggregated
domain   launcher,   the   new   graphics   subsystem   and   improvement   resulting   from

testing   and   code   analysis   will   become   integral   part   of   the   Xen   hypervisor.
Infrastructure and management components such as the virtual network switch and

the TVD-aware

libvirt

  management extensions will be included in future versions of

official SuSE distributions.
Trust and virtualization management approaches explored in OpenTC are considered
for inclusion in IBM's management software, and architectural concepts for Trusted

Virtual Clients investigated by this project have been included in product roadmaps
of   HP.   Applications   developed   for   the   OpenTC   framework   are   exploited   by   the

partners   either   as   products   or   for   internal   purposes.   The   distribution   will   be
maintained for the foreseeable future, including the training platform developed on

top of the OpenTC architecture.
OpenTC results have further been exploited through standardization activities   the

Java TSS API within JSR321 Expert Group with a first release of the specification for
Early Draft Review in April 2009. OpenTC partners provided input to and reviewed the

Open   Mobile   Terminal   Platform   Group's   specification   on   Advanced   Trusted

OpenTC  Publishable Activity Report

7/40

background image



 Publishable Activity Report OpenTC

Environment (TR1).

1.4  Future Directions

1. OpenTC   contributed   substantially   to   turning   trusted   platforms   and

infrastructure into a now well established area of IT security research. It was
instrumental   to   create   an   active   European   and   international   community   of

researchers and practitioners   that reaches far beyond the group of original
OpenTC partners, and has helped to foster this community through continued

presence   in   workshops,   conferences   and   seminars.   To   maintain   this   young
research   ecosystem   beyond   the   end   of   the   project,   we   would   strongly

encourage to create a European Network of Excellence for Trust in IT and offer
our support to set it up.

2. The validation efforts of OpenTC have helped to establish a baseline of trust in

the   isolation   capabilities   of   the   underlying   hypervisor   technology   and   a

number of critical core components. Still, it was only possible to cover a small
fraction of components that constitute a trustworthy system. Much remains to

be   done   in   this   area,   for   example,   the   development   and   application   of
validation methodologies and metrics, the establishment of coding practices

that   enable   static   code   analysis,   of   freely   accessible   software   production
chains that validate, build, test and deploy software packages in a trusted and

transparent   work   flow.   A   more   general   goal   is   the   creation   of   trustworthy
(meta)data repositories on characteristics of binaries and their corresponding

implementation.   We   learned   that   the   almost   complete   lack   of   this   type   of
information   is   one   of   the   main   inhibitors   for   applying   trusted   computing

technology   and   would   consider   this   line   of   research   valuable   for   future
projects.

3. A   more   fundamental   question   concerns   the   general   tendency   of   Trusted

Computing of moving ever more functionality into firmware and hardware. We

may   accept   that   certain   core   functions   and   data

must

  be   protected   from

interference and inspection. Still, it is far from clear whether the general move

towards   hardware   based   functions   can   be   equated   with   improved   trust
properties.   In   line   with   OpenTC's   general   approach,   it   can   be   argued   that

better protection at the expense of transparency may ultimately lead to less
rather   than   more   trust.   It   seems   worthwhile   to   investigate   whether   this

dilemma could be addressed by a minimal core of protected functions and
data   in   combination   with   tamper-resistant,   programmable   hardware.   The

hardware programming would lend itself to inspection, which reintroduces the
transparency that is otherwise 'lost in hardware'.

1.5  Open Trusted Computing Partners

The   OpenTC   project   is   formed   by   an   international   multidisciplinary   consortium
consisting of 23 partners:

Technikon  Forschungs- und  Planungsgesellschaft mbH (project coordination,
AT);

Hewlett-Packard Ltd (technical leader, UK);

AMD Saxony LLC & Co. KG (DE);

Budapest University of Technology and Economics (HU);

Commissariat à l’Energie Atomique – LIST (FR);

COMNEON GmbH. OHG (DE);

Forschungszentrum Karlsruhe GmbH – ITAS (DE);

Horst Görtz Institute for IT Security, Ruhr-Universität Bochum (DE);

IBM Research GmbH (CH);

OpenTC  Publishable Activity Report

8/40

background image



 Publishable Activity Report OpenTC

Infineon Technologies AG (DE);

INTEK Closed Joint Stock Company (RU);

ISECOM (ES);

Katholieke Universiteit Leuven (BE);

Politecnico di Torino (IT);

Portakal Teknoloji (TR);

Royal Holloway, University of London (UK);

SUSE Linux Products GmbH (DE);

Technische Universitaet Dresden (DE),

Technische Universitaet Graz (AT),

Technische Universitaet Muenchen (DE),

Technical Universiy of Sofia (BR)

TUBITAK – UEKAE (TR);

University of Cambridge (UK).

Picture 1: OpenTC Consortium at General Assembly Meeting in Zurich Sept. 2006

The total volume of the project is estimated to be 17.1 Million Euro, part of which will

be contributed by the EC. Visit

www.opentc.net

 to learn more.

For further information please contact:

Technikon Forschungs- und Planungsgesellschaft mbH
Burgplatz 3a,
9500 Villach,
Austria
Tel.: +43 4242 233 55-0,
Fax: +43 4242 233 55-77
Email:

coordination@opentc.net

OpenTC  Publishable Activity Report

9/40

background image



 Publishable Activity Report OpenTC

1.6  OTC Logo

1.7  OTC Disclaimer

The information in this document is provided “as is”, and no guarantee or warranty is
given that the information is fit for any particular purpose. The user thereof uses the

information at its sole risk and liability.

OpenTC  Publishable Activity Report

10/40

         Picture 2: OpenTC Logo

background image



 Publishable Activity Report OpenTC

2   Project Execution

2.1  WP02: Requirements Definition and Specifications

Work package 02 had the main objectives of identifying and defining requirements
for   the   OpenTC   platform   and   framework,   gathering   expectation   towards   proof-of-

concept prototypes, and creating the high-level specification. WP02 had to ensure
that the general requirements were  channelled  into and taken into account by the

appropriate   work   packages   specifying   single   components.   Specification   and
requirements were to be extended in multiple iterations, compiled and published in a

single report.
In summary, WP02 has reached all objectives listed above. The following sections

give an overview of the progress towards the objectives during the project and list
the major achievements of this work package.

2.1.1  Progress towards objectives





Based   on   a   consortium-internal   survey   and   an   analysis   of   external   media   and

publication,   an   initial   assessment   of   Trusted   Computing   and   virtualization   was
produced, with particular regard to perception and potential relevance for the area of

digital rights management.
OpenTC partner ITAS carried out an initial in-depth survey with external experts to

gather   expectations   towards   OpenTC   proof-of-concept   prototypes,   specifically
regarding direct user interactions with the system. The results were presented to and

discussed   with   work   packages   04,   05   and   06.   In   cooperation   with   WP04,   WP02
defined characteristics of the first, prototypic user interfaces.
For   gathering   additional   user   impressions,   the   prototypes   were   presented   at
conferences.   In   particular,   feedback   on   the   user   interface   of   the   “corporate

computing at home” CC@H  prototype has been obtained. This prototype has also
been discussed intensively inside partner organizations.
Further feedback obtained from the presentations at conferences, from reactions to
the   OpenTC   newsletter   and   from   dissemination   events   carried   out   by  WP10,   was

included to improve the design of the GUI. The user interface as implemented in the

CC@H

    prototype   was  further  enhanced   to   support   multiple   concurrent   operating

systems of both proprietary and non-proprietary nature. Results were presented in a
scientific   paper   at   Future   of   Trust,   Berlin   2008.   A   final   in-depth   high-level   expert

survey has been conducted on PC virtualization and new threats arising through the
use of this technology.
WP02   cooperated   intensively   with   the   other   technical   work   packages   (03-09)   to
create   the   requirements   and   specifications   documents   (D02.1   -   D02.3).   WP02

cooperated   with   WP10   for   disseminating   the   OpenTC   results,   e.g.   by   newsletter
articles covering the overall specifications. As an executive summary of the overall

project, WP02 produced the final report D02.4.
As a contribution to clarify the intellectual property on Trusted Computing, OpenTC

partners RUB and HPLB cooperated in WP02 to produce the first IPR study on this
technology. This study has  been made available to the TCG as well as the general

public.
WP02   contributed   to   the   definition   of   the   HASK-PP   protection   profile,   which   was

produced in a cooperative effort between the German BSI, OpenTC partners RUB and
HPLB, and Sirrix AG, Bochum. This profile defines requirements for high assurance

kernels at CC level EAL5. It has since been certified and been made available to the
general public.

OpenTC  Publishable Activity Report

11/40

background image



 Publishable Activity Report OpenTC

2.1.2  Major Achievements





WP02 presents the following major achievements:

Production   of   general   requirements   and   specifications.

  These   deliverables

include an assessment of TC, DRM and virtualization, with annual updates (D02.1,
D02.2,   D02.3).   The   report   contains   the   general   requirements   analysis   regarding

Trusted   Computing,   an   overview   of   the   architecture   and   of   single   services.   The
specification   covers   the   basic   characteristics   of   virtualized   platforms   and   the

supporting infrastructure.

Production of specifications of three proof-of-concept prototypes

 developed

by OpenTC, namely:

A secure browser environment for conducting electronic transactions, such as

home-banking, called PET (Private Electronic Transactions), isolated from the
user's main operating system,

A virtualized PC architecture with multiple isolated compartments usable for
corporate data as well as for private and other data, supporting both Open

Source based and proprietary operating systems,

A   proof-of-concept   prototype   for   a   virtualized   data   center.   It   consists   of

physical nodes and infrastructure elements realizing the concept of Trusted
Virtual domains allowing to isolate compartments and networks for different

customers.

All solutions are implemented on the basis of an advanced combination of Trusted

Computing and virtualization technology.

Production   of   specifications   for   single   applications

,   namely   the   “

Open

Publication System

” (an interoperable DRM system), the

Encrypted File System,

the

Message   Exchange   Infrastructure

and   the   “What   you   see   is   what   you   sign”

application.   The   corresponding   prototypes   demonstrate   how   to   employ   trusted
platforms   for   purposes   ranging   from   encryption   services   or   digital   rights

management  to  establishing   a  baseline   of  trust  between  multiple   parties   through
multilateral   assurance   of   platform   properties.   Using   virtualization,   the   impact   of

trusted   computing   can   be   constrained   to   defined   compartments,   leaving   other
compartments   unaffected.   Specification   summaries  for   the   use   cases   “Private

Electronic Transactions”, “Corporate computing at home”, “Trusted Virtual Domains”
and “Secure Wallets” were published in the OpenTC newsletter.

Co-design   of   the   graphical  user   interface

  based   on   data   gathered   the   initial

expert survey. The solution allows simplified manipulation of compartments through

a trusted section of the screen, using a user-selected sealed image. Findings from
this design process were taken up by WP04 to design a new graphics subsystem with

radically reduced code base and generic trusted path capabilities.

Final expert  survey  on  PC  virtualization  and  threats.

The  survey confirmed

that supporting mechanisms for mutual isolation between personal and corporate are
appreciated,   that   the   utilization   of   Trusted   Computing   technology   is   considered

beneficial   for   the   protection   of   private   data,   and   that   a   combination   of   TC   and
virtualization can support growing demands for auditability. Our findings confirm that

the project has tackled an area of growing importance and has been on the right
track with regard to the solutions it provided.

Development   and   certification   of   Common   Criteria  V3.1  EAL  5  Protection
Profile

 “High Assurance Security Kernel”, together with Sirrix AG, atsec information

security and the German Federal Office for Information Security (BSI). The PP defines
mandatory security requirements for a security kernel which provides management

and separation of compartments running on top of the security kernel. It can be used
to evaluate future kernels, e.g., products using the OpenTC architecture.

OpenTC  Publishable Activity Report

12/40

background image



 Publishable Activity Report OpenTC

Production   of   patent   study   on   Trusted   Computing:

more   than   500   related

patents have been identified. The extended summary of this study has since been

published and was made available to the Trusted Computing Group.

2.2  WP03: Basic Interfaces and Trust Layers

This work package addresses the interfaces of trusted computing hardware elements

to   the   requirements   of   software   APIs,   separating   the   functions   of   the   platform’s
enhanced main processor, security module (TPM) and relevant peripherals from the

required   abstract   software   layer.   The   main   tasks   were   to   build   a   prototypic
virtualization   platform   on   the   AMD

Presidio

  architecture,   to  port   the   Infineon   TSS

stack to Linux, to provide Java interfaces to the Trusted Computing core functionality
and   the   Trusted   Software   Stack,   and   an   exploration   whether   and   how   existing

cryptographic protocols and services can be extended to utilize Trusted Computing
functionality.

2.2.1  Progress towards Objectives





CPU   support   and   abstraction

  for   operating   systems   to   use   to   access   the

virtualization features of an AMD CPU. The prototype includes features to start an
authenticated   virtualization   environment   from   Dynamic   Root   of   Trust   of

Measurement (DRTM) base. The DRTM is agnostic of the started kernel and runs on
both kernels used in the project. The software and driver packages were finalized for

the adaptation of the new AMD CPU based platforms for Secure Virtual Machines. In
accordance with the work plan, all tasks were completed during the second reporting

period.

TSS stack

was developed with all functions mandated by the TCG TSS specifications.

The package and the Linux test bed were made available. A test plan was developed
in cooperation with WP07, which carried out further tests and functional validations.

Security protocols and services

: Following an analysis of the security and data

models of OpenSSH, OpenSSL, ipsec-tools and PKCS#11 was used for defining the

requirements   and   design   of   a   Key   Management   layer   (subsequently   called   KMA).
Specific   studies   addressed   the   external   authorisation   for   TPM   keys   bound   to   the

platform integrity and the integration of TLS extensions in OpenSSL to support the
design and implementation of a Direct Anonymous Attestation based enhancement

for TLS.

Java   wrappers   and   components:

  The   initial   work   addressed   Java   wrapper   for

existing, C or C++ implemented Trusted software stack that made the TSPI layer of
the TSS stack available to Java developers. An updated prototype developed towards

the end of the project works across different TSS implementations.  It has not yet
been released to the public, since it is still in experimental stage. A set of jTPM Tools

was developed to provide a set of command line utilities to interact with the system's
TPM.

Java   TSS   stack:

  Advanced   work   during   the   second   and   third   reporting   period

produced a fully Java implemented TSS stack that directly interfaces the operating

system   driver.   Based   on   this   implementation,   a   standardization   proposal   (Java
Standardization Request) within the JCP (Java Community Process) was initiated and

accepted.   An   extended   version   of   the   jTPM   Tools   was   integrated   within   the
implementation.

Proxy-based remote attestation:

  Client and server components were developed

for   OpenTC's   first   demonstrator   prototype,   a   proxy   based   mechanism   for   remote

attestation was developed using a proprietary attestation protocol.

Java execution environment:

 This work addressed to reduce the size of a virtual

machine hosting the Java runtime environment and the JavaTSS. Intermediate results
show   a   reduction   of   the   size   to   less   than   20MB.   An  integrity   measurement

OpenTC  Publishable Activity Report

13/40

background image



 Publishable Activity Report OpenTC

architecture   for   the   Java   VM   was   developed   and   integrated   in   the   class   loading
procedure.

2.2.2  Major Achievements





CPU   abstraction   and   prototyping   for   dynamic   trusted   boot.   The   work   was

prepared for dissemination as a basis for the creation of an industry standard
covering the topic in the Trusted Computing Group.

Trusted   Software   Stack   for   Linux:   A  ported   and   thoroughly   tested   package
implementing the TSS and a SOAP interface.

Key   Management   Adaptation   (KMA)   service   prototype:   An   architecture   for
securing configuration and key files of generic applications through the TPM,

eCryptFS and SMAC - respectively an encrypted file system and a mandatory
access control system both provided by the Linux kernel.

TC integrated SSL/TLS, ssh, and IPSec prototypes: Definition of DAA-enhanced
TLS   protocol;   design   and   implementation   of   OpenSSL   engine/DAA

enhancements (DAA implementation provided by TPM and a purely software
one   based   on   elliptic   curves).   Development   of   KMA   configuration   files   to

secure OpenSSH, OpenSSL, ipsectools and PKCS#11.

Java wrapper modules for C-implemented Trusted Software stacks, exposing

TSS functionality to Java developers.

Java implemented TSS and corresponding tool set with Simple Object Access

Protocol (SOAP) support for TSP-to-TCS communication.

Standardization of Java-APIs for Trusted Computing as JSR 321, taking the role

of the specification lead.

2.3  WP04: Trusted OS Development

Work   Package   04   aimed   at   building   the   operating   system   components   for   the

OpenTC.   Its   focus   was   the   integration   of   Trusted   Computing   and   virtualization
technology, system level security and integration with hardware capabilities. Its three

high-level goals were

To investigate the integration of the chain of trust with the virtualization layer

and virtualization of the TCG components,

To explore and utilize new CPU functionality (AMD Pacifica, Intel LT) for trusted

virtualization, and

To   investigate   commonalities   in   trust   and   security   management   for   both

hypervisors used by OpenTC, namely Xen and L4

The   main   practical   task   of   the   work   package   was   to   develop   core   security

components of the OpenTC Trusted Platform for both hypervisors, using a common,
platform-independent approach where feasible. In summary WP04 has made large

progress   towards   its   stated   goals   and   has   achieved   all   its   major   objectives.   The
following sections give an overview of the detailed activities.

2.3.1  Progress Towards Objectives





Regarding the three goals listed above, WP04 has made progress as follows:

Chain of Trust, Integration of Virtualization and TC technology, virtualization of
TCG  components:  The  WP04  partners  determined  a suitable  subset of TPM

functions   that   has   to   be   virtualized   to   enable   integrity   measurement   and
attestation   for   hosted   OS   instances   (compartments).   On   this   basis,   WP04

designed   a  chain  of  trust between   the  hardware   TPM  module  and  multiple
virtualized TPMs on the same platform. This included concepts for persistent,

protected data areas of virtualized TPMs as a prerequisite for recreating trust
environments.   Basic   mechanisms   and   interfaces   were   designed   and

OpenTC  Publishable Activity Report

14/40

background image



 Publishable Activity Report OpenTC

implemented that can support the migration of trust environments (including
virtualized TPMs) to remote hardware platforms.

Utilizing   new   CPU   Functionality   for   Trusted   Virtualization:   WP04   analyzed
hardware,   software   and   hybrid   mechanisms   for   trusted   virtualization,   in

particular   with   regard   to   engineering   trade-offs   between   isolation,
performance, and legacy support. In cooperation with WP03 (AMD), new CPU

features were used to design and implement a trusted re-boot process that
can be initiated from an already booted system. CUCL and HP adopted support

for hardware virtualization offered by the new CPUs to demonstrate that the
legacy and proprietary software can be hosted as virtual instances under Xen.

Security and Trust Management for L4 and Xen: WP04 investigated policies
and   configuration   attributes,   representation,   and   enforcement   mechanisms

appropriate for a trusted hypervisor layer, its management components and
hosted operating system instances (compartments). A basic set of functions

for managing the configuration, policy, and operation  of this software layer
was defined; the results were taken by WP05 as a basis for defining policies

for Trusted Virtual Domains. WP04 defined and prototyped a corresponding
interface common to both L4 and Xen and implemented prototypes on L4 and

Xen.

Synergetic Approaches: WP04's initial aim to fully abstract from the type of

the   underlying   hypervisor   layer   proved   to   be   somewhat   over-ambitious.
Fundamental differences between the two hypervisors architectures (notably

in process and memory management) worked against unifying the technical
semantics of the kernel interfaces of Xen and L4 with respect to the above

mentioned API, policy and configuration representation. Interoperability with
existing management software was a negligible point when the project was

conceived   four   years   ago,   but   it   became   of   increasing   importance   as   a
growing   body   of   virtualization   management   software   was   developed

independently   of   OpenTC.   We   also   realized   that   introducing   new   layers   of
abstraction for hypervisors would render most of these tools useless, which

was highly undesirable with regard to the work performed by WP05.

The   current   solution   provides   interoperability   for   the   core   security

components, striking a balance between what might be desirable and what is
actually   feasible   and   practical.   Future   attempts   to   unify   the   semantics   of

different   hypervisors   should   probably   follow   the   approach   taken   by   WP05,
namely, the utilization and extension of management interfaces such as libvirt

that have since gained wider acceptance in the community of developers and
users.

2.3.2  Major Achievements





The major achievements of WP04 are:

Dynamic Root of Trust for Measurement (DRTM) implementation:

as

part   of   our   research   on   chain   of   trust   and   new   CPU   features,   WP04   has

implemented a DRTM module for AMD processors.

Basic   Management   and   Security   Interface   specification   and

implementation

:



WP04 produced a specification of basic security features

required by hypervisors to support Trusted Computing model for all types of

applications.   This   specification   was   geared   towards   minimizing   the   Trusted
Computing Base and describes the minimal security and trust requirements

for both hypervisors. WP04 produced a prototype implementation for L4 and
Xen covering the specification.

Disaggregation   of   Trusted   Computing   Base:

WP04   developed   a

disaggregated launcher for compartments that operates independently of the

Xen management domain, allowing to remove important privileges from the

OpenTC  Publishable Activity Report

15/40

background image



 Publishable Activity Report OpenTC

latter. This 'domain builder' implements part of the BMSI requirements.

Integrity   Management   and   TPM   virtualization:

In   collaboration   with

WP05, WP04 designed and implemented an integrity management framework
which has been integrated with the BMSI implementation  and the proof-of-

concept   prototype   for   virtual   TPMs.   As   part   of   its   deliverables,   WP04   has
produced   a   design   for   TPM   virtualization.   A   partial   proof-of-concept

implementation   of   this   architecture   was   implemented   on   both   hypervisors.
WP04 investigated the factual security provided by today's TPM modules, and

RUB proved the practical feasibility of low-cost hardware attacks against TPM
hardware.

Network and Storage separation:

 WP04 designed and developed a virtual

network  switch  as   the   basic   security  component  that  manages  and  polices

compartment access to different virtual networks. This switch is an integral
part of the trusted platform and a prerequisite for Trusted Virtual Domains as

explored   by   WP05.   As   an   enabler   for   a   trusted   boot   process   WP04   co-
developed   the   file   system   overlay   method   used   in   all   proof-of-concept

prototypes.

Secure   Graphical   User   Interface:

WP04   designed   and   implemented   a

prototype for a high performance and safe sharing of the Graphics Processor
between   different   compartments.   The   prototypic   implementation   was

developed under Xen for practical reasons, however, the existing design and
implementation   can   be   ported   to   L4   with   minimal   additional   effort.   The

solution provided has reduced the reliance on untrusted driver and graphics
server code by an estimated 95%.

Hypervisor   abstraction:

All   trust   and   security   components   and   APIs

developed by WP04 are interoperable between and agnostic to the type of

hypervisors they are running on. WP04 designed and implemented common
inter-process   and   RPC   mechanisms   for   both   architectures   that   allow

communication through a trusted path.

Adoption of findings from WP07:

 results from the extensive code analysis

performed in WP07 were analysed in order to determine whether they pointed
to   actual   flaws   in   the   hypervisor   software.   Where   this   was   the   case,   the

software was fixed accordingly, resulting in improved security and robustness
of the packages.

In addition to the achievements listed above, WP04 was responsible for providing the
base   platform   for   all   proof-of-concept   prototypes   and   distributions,   including

integration, testing, bug fixing and packaging. This line of activity was not foreseen in
the original proposal, but was taken up to ensure the success of the overall project.
Similarly, work on a secure graphical user interface and 3D support was not part of
the   original   planning.   The   desirability   of   this   component   arose   from   experiences

gained   from   the   'Coporate   Computing   at   Home'   scenario   in   year   two   and   from
specific requirements for management consoles. It was addressed to prove that a

hypervisor-neutral   design   of   complex,   security   enhanced   components   can   be
achieved even under severe  performance constraints. Work in the different areas

covered by WP04 has resulted in numerous peer-reviewed publications.

2.4  WP05: Security Management and Infrastructure

Work   package   05   aimed   at   building   the   policy   management   and   public   key

infrastructures for the OpenTC framework. In particular with regard to infrastructure
for “trusted Virtual Datacenter” scenarios, the core security requirement is mutual

isolation of execution environments and domains. Customers hosted in a virtual data
center should never be  able  to perform unauthorized data exchange. This should

hold even in case of administrator mistakes. This poses several security challenges
such   as   customer   isolation   across   all   resources   and   management   by   different

OpenTC  Publishable Activity Report

16/40

background image



 Publishable Activity Report OpenTC

management tools.

2.4.1  Progress Towards Objectives





WP05   has   made   substantial   progress   in   all   areas   of   its   activities.   The   following
sections give a survey of the progress in the different work areas:

Design and Implementation of Security Services API

  for applications, e.g., as

developed in WP06. WP05 contributed to the requirement analysis for a secure UI
(SUI),   the   design   of   the   TVD   storage   and   network   infrastructure   and   the   TVD

implementation   on   L4   (TVD   Master,   TVD   Proxy,   port   of   HP   virtual   networking
infrastructure to L4, adaptation of the

libvirt

 virtualization management software and

TVD access control infrastructure to L4).

Design   and   implementation   of   trusted   channels

:   Two   alternatives   were

designed, implemented and optimized for online transactions (based on TLS) and for
situations where trusted platforms can be disconnected from their peers, for example

for   use   within   infrastructures   like   enterprise   rights   management.   The   second
alternative   is   used   as   part  of   the   L4  TVD  implementation.   The   TLS-based  trusted

channel has been published and presented at ACM STC 2008 together with POLITO.

Design and implementation of security and management components:

  The

design   and   implementation   of   the   compartment   manager   was   finalized.   WP05
designed   and   implemented   access   control   mechanisms   for

libVirt

  access   and

awareness for trusted virtual domains in the L4 Compartment Manager and libVirt.
For   the   OpenTC   demonstrator,   WP05   is   in   process   of   finalizing   the   TVD

implementation and verifying interoperability and work flow when used together with
the Xen TVD implementation. A significant amount of work was invested into the

integration   of   all   components   and   automation   of   work   flows   for   the   'Virtual
Datacenter' proof-of-concept prototype

Foundations   of   Trusted   Computing,   Privacy   and   Cryptography:

  WP05   has

contributed to the area of

privacy-enhancing Trusted Computing Protocols

based on

property-based attestation. The goal was to base policy decisions of remote parties
on abstract properties of a platform (fulfilling certain security requirements) without

referring  to specific  software  and/or  hardware  configurations. A system  model for
property-based attestation was designed and various solutions based on existing TC

functionality   were   developed.  RUB  developed   concepts   for   property-based   virtual
TPM and secure virtual private networks, a cryptographic protocol for property-based

attestation, and a framework for enterprise rights management with trusted virtual
domains. These works included detailed security analyses of the novel proposals and

prototypic implementations. Research results were published and presented at three
international, peer-reviewed scientific conferences.

New technical approaches to Trusted Computing:

 WP05 evaluated approaches

to   implement   trusted   computing   functionality   on   low-cost   embedded   and

reconfigurable   devices.   In   this   context,   “physical   un-clonable   functions”   are   a
promising   enabling   technology.  WP05  also   investigated   an   alternative   TPM

architecture, which can be used as a general purpose secure co-processor to run
arbitrary security critical tasks. Results of this research were presented in two peer

reviewed scientific publications.

Policy   Management   and   Policy   Enforcement:

WP05  partners



collaborated   on

developing a new

multi-level approach to multi-tenant isolation policies.

The goal of

this approach is to isolate all resources of multiple customers in a data center while

enabling   controlled   sharing   of   certain   resources   by  specifying   isolation   between
different domains in a base policy which is used to either validate or, alternatively,

else generate isolation policies for specific resources such as storage or networks.
The results were published in an international, peer-reviewed scientific periodical.

Auditing framework for  virtual  infrastructures:

This framework and prototype

OpenTC  Publishable Activity Report

17/40

background image



 Publishable Activity Report OpenTC

validates   the   security   of   a   virtual   infrastructure   by   discovering   the   detailed
configuration   of   multiple   virtual   hosts,   deriving   their   logical   relationships   (e.g.

VLANs),   identifying   isolation   domains   across   hosts   and   comparing   these   actual
security zones with the designated ones.

Intrusion detection in virtual environments:

 This activity aimed at moving virus

detection and intrusion response out of the many guest machines into few security

VMs per host. A dedicated security VM can then introspect other guests and scan for
viruses   in   their   virtual   memory.   It   can   also   observe   network   traffic   and   act   as   a

network-level   intrusion   prevention   system   for   virtual   networks   that   are   normally
invisible from the outside.

Security-enhanced network virtualization:

The design elements of the vSwitch

and VNET were stabilized to support for the networking elements for the intermediate

and final proof-of-concept prototypes. The results of the stabilized design have been
published   in   the   R2D2   workshop.   The   vSwitch   was   adapted   to   support   the   most

recent   Linux   kernel   versions   and   underwent   extensive   stress-testing.   The
implementation   was   improved   to   simultaneously   support   EtherIP   and   IPSec.   The

command  line  tools  and  interfaces   were  extended   to cover  more  functionality.  In
addition, WP05c provided modules and wrappers to support web based management.

As a result, the vSwitch can now be configured and managed remotely as resource of
a platform or a Trusted Virtual Domain (TVD).

Integrity   management   framework:

  HPL   has   finalized   the   design   and   the

Application Protocol Interface (API) for the Hierarchical Integrity Management (HIM)

framework. The finalized design and implementation details have been published as
an   HPL   technical   report.   HPL   has   implemented   the   majority   of   the   API   and   has

collaborated with WP06 partners (e.g. POLITO) in investigating how to co-ordinate
Virtual Machine (VM) integrity management with application integrity management. A

final achievement has  been  the finalization  of the WP05/06 API that allows  WP06
applications to control portions of the underlying hypervisor.

Resource management:

 As contribution for the final Virtual Data Center proof-of-

concept   prototype,   HPL   has   designed   and   prototyped   a   lightweight,   agent   based

resource management framework that covers essential VDC aspects (in particular
networking, virtual machine management, and basic support of Trusted Computing

hardware). The modular design allows for simplified integration of other management
aspects; modules can be turned into CIM-providers with minimal effort. With regard

to enterprise-grade management, HPL has explored CIM support for trusted platforms
and   infrastructure   components.   Based   on   a   DMTF   draft,   we   have   designed   and

prototyped a CIM provider for Trusted Computing Modules that is geared at the setup
and configuration stage of data center nodes.

Security-enhanced   storage   virtualization:

  HPL   has   investigated   policy

management issues around storage virtualization with other partners including IBM

and RUB. The results of this investigation are published in an article in a special issue
of JCS. A storage isolation prototype has been implemented by IBM.

Isolation management in Virtual Data Centers:

  HPL has worked with partners

(IBM, POLITO and RUB) to investigate policy management and enforcement in virtual

data centers. The results of this investigation are published a special issue of JCS.
The implemented TVD master and proxy ensures that each domain owned by a given

tenant has a well-defined policy that is enforced across all hosts that are members of
this   domain.   We   also   agreed   on   a   final   policy   language   for   exchanging   security

policies between Xen and L4.

Virtual Platforms:

 HPL's WP05 management related work yielded input for WP04's

design   of   security   services   that   enable   strong   binding   of   virtual   machines.   The
preliminary results of this investigation were prepared for submission to ACM CCS

STC.

Secure   User   Interface   (sUI):

The   use   case   for   a   management   console   and

OpenTC  Publishable Activity Report

18/40

background image



 Publishable Activity Report OpenTC

components     from   WP05c   guided   the   requirement   analysis,   design   and
implementation for secure graphic subsystem alternatives performed in WP04. This

work is geared at user interface virtualization (joint work with partners CUCL, RUB
and TUD).

Key Management Infrastructure:

WP05 developed a design of a PKI capable of

managing TC PKI objects as outlined in the TCG specifications. The design contains

multiple   services   (i.e.   certification   issuance,   certificate   validation),   transport
protocols   and   the   appropriate   client   software.   Ambiguities   in   the   original

specifications from the TCG led to the development of alternative solutions focused
on reconsideration  of the existing privacy-CA-prototype design with improvements

directed towards a simplified communication protocol for multiple languages. Further
practical   work   on   cryptography   concerned   a  Java-based   implementation   of   Direct

Anonymous Attestation and the partial implementation of Trusted Channel concepts.

2.4.2  Major Achievements





WP05 can present achievements for new approaches and management paradigms
for trusted computing, platform and infrastructure components that are included in

the proof-of-concept prototypes:

Components for the OpenTC Platform and the VDC Proof of Concept:

WP05   has   developed   policy   management   and   security   enforcement
components   of   the   OpenTC   platform   for   the   VDC   proof   of   concepts.   This

includes:

TVD   master   and   TVD   proxy

  and   a   trusted   channel   for   policy

distribution and host validation

Secure   virtual   networking

,   storage,   and   machine   life   cycle

management for L4 and Xen.

Extended   and   improved   public   key   infrastructure   for   Trusted

Computing

Research   and   feasibility   studies   in   multiple   areas   of   distributed

trusted   platforms:

  new   approaches   for   trusted   computing,   security

enforcement   and   audits   in   virtual   environments,   and   intrusion   defense   for

virtual systems.

Proof of concepts for particular aspects (e.g. auditing and intrusion

response)

Work from WP05 has led to a large number of peer-reviewed publications.

2.5  WP06 Use Examples / Prototype Applications for Proof-of-

Concept

This work package addresses application prototypes based on the trusted platform
architecture   and   security   services   developed   by   OpenTC   The   work   package   also

provided the security model requirements and refinements for a minimal API for the
security services. The use cases and proof-of-concept span the fields of digital rights

management, messaging infrastructure, electronic signatures, encryption file service
and multi-factor authentication. Due to the variety of topics addressed, progress and

achievements are listed per use case.
For   the   majority   of   the   work   packages   (4   out   of   5),   the   actual   technical

implementation started after the completion of the first OpenTC's platform prototype
at the mid term of the project. The use cases were then ported successively to the

two platform prototype extensions from work period two and three.

2.5.1  SWP6a: Digital Rights Management





This work package addressed the use of trusted platform technology for managing
digital content. Particular effort was spent on fair-use scenarios. The main use case is

OpenTC  Publishable Activity Report

19/40

background image



 Publishable Activity Report OpenTC

geared towards media such as audio and video, the concept is applicable for other
scenarios that demand management of content based on policies encapsulated in

trusted metadata (e.g. document management).

Progress towards objectives:

Initial requirements specification:

Based on the analysis of major DRM systems

an  initial   requirements   specification   was   given  and   contributed   to   OpenTC's
specification. During the course of the project, a concept system prototype and a

final prototype using a Rights/Content issuer framework was produced that is based
on several MPEG-21 standards.

Initial   concept   system   prototype

was   developed   with   a   DRM   Core   using   a

prototypical REL interpretation engine, and a secure media player based on VLC. This

initial prototype was further updated to be shown in the demonstrator in the 2007
review.

Final prototype:

 This prototype consists of 3 main components: the DRM core, the

Management Application and the Secure Media Player. The MPEG-A standard “Open

Access  Application   Format”  serves  as   an  exchange   format  for  files  and  metadata
between the virtualized components.

Management Application:

  It allows to create, manage and consume any content

independent of the content type. The application packages content in an exchange

format  and  attaches  metadata   to these  contents.  The   Management  Application  is
also compliant with the standard ISO/IEC 23000-7 Open Access Application Format

which extends the system with several additional functionalities, e.g. the support for
Open Content licenses. Furthermore the Management Application can communicate

with the DRM Core via an API, to exchange licenses and keys.

Secure media player:

 the player was gradually extended to support any media file

type (supported by VLC). License translation was implemented in the DRM core to
provide interoperability with OMA DRM (ODRL) system. Additional functionalities were

added to the rights expression language for fair use.

Major Achievements:

DRM   Core

supporting   secure   license   and   key   storage,   user   management,

license interpretation, translation and generation.

Management Application

 supporting content creation (protected / signed /

unprotected), exchange, export, and rendering (for audio, video, image, text
files)

Secure media player

supporting multiple media formats, license translation,

and   support   for   fair   use   (copy,   two   variations   of   adaptations,   burning   and

selling)

Integration of DRM system into the Virtual Datacenter

 proof-of-concept

prototype (web-based content server as a showcase  for fair-use DRM in this
scenario).

Leading and coordinating the activities of this work package

2.5.2  SWP6b: Message Exchange Infrastructure





This work package is concerned with a message exchange infrastructure that exploits
trusted computing mechanisms (short: MEITC). The work explores whether and how

confidentiality, integrity, source (sender) authentication and non-repudiation of sent
messages   can   be   supported   using   capabilities   of  the   OpenTC   framework   and   the

security features of TPM.

Progress towards Objectives

Determining   the   required   functionality:

  It   concerned   trusted   computing   and

OpenTC  Publishable Activity Report

20/40

background image



 Publishable Activity Report OpenTC

platform   virtualization   support   for   a   message   exchange   system   (TPM-based   key
generation,   registration,   persistent   storage,   export).   The   Software   Requirements

Specification of the MEITC system was written in compliance with the IEEE 830-1998
Guidelines and included in OpenTC's specification.

Backbone for  the  messaging  system

: It includes  OpenTC specific  components

(TSS, trusted boot loader, TPM tools, Xen) and messaging software (Postfix, Dovecot,

MySQL,  Tomcat,  x-sig,  OpenSSL,  Squirrelmail,  PHP,  Apache, Cyrus  SASL).  A  single
virtual machine was used to host all services.

First development cycle:

 The architecture used TPM sealed keys for block device

encryption with

dmcrypt

 and Xen tools to protect a dedicated virtual disk or loop file

system for the Certificate Service Provider (CSP) key database. The development for
MEITC administration and MEITC certificate manager applications using Java Servlet

Pages (JSP) was started in parallel.

First   prototype:

  Basic   implementation   of   a   web   based   e-mail   exchange

infrastructure   where   users   can   read   and   delete   their   e-mails   on   a   remote   e-mail
server   which   connects   to   a   MySQL   database.   A   web   based   interface   is   used   to

execute read and delete functions. Features still missing at this point were a fully
functional  TSS stack implementation, security services for TC, and privacy enabled

PKI for OpenTC.

Second development cycle:

  A JSP based web administration tool was developed

for   MEITC   administration.   It   supports   the  creation,   deletion   and   modification   of
accounts, domains and quotas on MEITC database. The prototype was ported from

Pardus   Linux   to   OpenSUSE   and   packaged   to   utilize   the   automated   build
infrastructure.

Second prototype:

 This prototype distinguishes application and database domains

that are hosted in isolated compartments, thereby leveraging OpenTC platform. Two

subsequently delivered revisions of the this prototype included further additions as
listed   below.   The   competed   system   comprises   a   web   server,   mail   and   database

server and services for logging, certification, and trusted computing.

Major Achievements

The final results of this SWP include the following achievements:

Requirement analysis according to IEEE 830-1998 Guidelines

, design

based trusted virtualization

Messaging system

  employing isolation and hardware based generation as

well as protection of keys as core security features,

Development of a TPM sealing module

 tailored to the need of the system

Combining TPM with OpenSSL:

 Investigation on how to merge TPM based

key generation with OpenSSL based generation of certificates for signature
keys.

Administrator   application   for   messaging   system

  with   navigation

elements reflecting the status of the TPM and TSS status information (TPM self

test, version, public endorsement key) and AJAX interface

Logging subsystem:

  provides signed logs (MySQL, Postfix and Tomcat) by

means   of   OpenSSL   and   the   TPM   Engine   and   includes   a   log   module   user
interface

2.5.3  SWP 6c: Electronic Signature Application Prototype





This work package investigated the requirements for a electronic signature system

that offers enhanced protection from display mimicry and keystroke logging during
the signing process. This goal is captured in the actual title of the use case, namely

What You See Is What You Sign (WYSIWYS). In accordance with the work plan, the

OpenTC  Publishable Activity Report

21/40

background image



 Publishable Activity Report OpenTC

efforts started in month 16.

Progress towards Objectives

Definition   of   requirements   and   specifications:

  The   introductory   analysis

determined the technical requirements for a (WYSIWYS) approach. These had to be
mapped to security properties provided by the OpenTC architecture where possible.

Missing   functionality   was   communicated   as   requirement   to   the   designers   of   the
OpenTC platform.

API definition:

  The responsible partner POLITO led the interactions between work

packages 05 and 06. A number of workshops were set to discuss the requirements

with regard to the interface definition. Further sessions with all WP06 partners took
place in order to define a first version of an application programmer interface for

security   services   that   are   provided   by   WP05   and   a   roadmap   for   its   design   and
implementation.

First  proof-of-concept  prototype:

  The prototype  was  designed  on  the  basis  of

already   existing   functionality   of   the   OpenTC   platform.   The   design   for   the   initial

version was based on a high level requirements specification originally unplanned.
The   prototype   was   mainly   developed   to   gain   first   experiences   with   the   OpenTC

concept of splitting security critical and 'normal' application components in multiple
compartments.   This   first   trial   also   helped   to   further   define   requirements   for   the

design of WYSIWYS application.

Second  proof  of  concept  prototype

:  The  application  was  based  upon  updated

requirements   and   design.   It   substantially   improved   the   first   design   by   strongly
isolating application components by executing them in separate virtual machines.

Evidence of the platform integrity (via TPM) is included in and bound to the digital
signatures

Integration with PKCS#11 hardware and software devices

: The prototype was

extended for generating legally valid signatures. It was tested with student ID cards

of Politecnico di Torino, a smart card that generates legally valid signatures.

Reduction of Trusted Computing Base:

  The prototype was further enhanced by

using the Library OS developed by WP04 that had become available upstream with
the latest version of Xen. Two of the core modules thereby became tiny and very

efficient. This work is currently wrapped up and will released to the general public.

Updated API definition for security services:

 For the duration of the project, the

API definition and its underlying security was continually revisited with regard to the
evolution services developed by WP05 and changes in the approach to management.

Based on the requirements collected from WP05 and WP06, a minimal C API was
defined that makes use the hypervisor-neutral

libvirt

  API. It includes extensions to

interact with the security services and a specific API for the Trusted Channel.

Major Achievements

The final proof-of-concept prototype combines services for control, integrity, storage

and   viewers  with   interfaces   for  trusted   and   untrusted   user  input  and  a   hardware
signing device. The particular achievements are:

Electronic signature application

 with enhanced protection against mimicry

and keystroke logging based on the OpenTC platform architecture with strong
isolation of security critical software components

Integration   of   platform   integrity   evidence

  provided   by   Trusted

Computing module in standard electronic signatures

Integration   with   PKCS#11

  hardware   and   software   components   for   the

generation of legally valid electronic signatures

Leading   requirement   and   specification   efforts

  for   OpenTC   API   for

OpenTC  Publishable Activity Report

22/40

background image



 Publishable Activity Report OpenTC

security services consumed by applications.

2.5.4  SWP6d Encrypted File Service





The   typical   support   of   TPMs   for   protecting   persistent   data   concerns   the   bulk
encryption   of   file   systems.   This   use   case   differs   from   the   standard   approach   by

covering repositories for per-file encrypted data with regard to a multiplicity of users,
owners, and roles. The use case started out from an existing application design that

was gradually re-engineered to utilize the OpenTC platform architecture.

Progress towards Objectives

First  Prototype:

Work  started  out   based   a   design   of  centralized   and   monolithic

service   for   supplying   transparent,   TPM-enabled,   and   policy-based   encryption   for
enterprise   systems   or   a   campus-wide   set   up.   TPM   utilization   was   envisaged   to

support back-end components, assuming thin clients as a standard medium.

Adapting   the   OpenTC   architecture:

The   first   prototype   implemented   a   of

heavyweight, single process architecture.  This design gradually evolved towards a
design that uses virtualization and trusted computing features offered by the OpenTC

platforms and influenced our approach to the underlying problem.

Service redesign:

  The architecture was repartitioned as a set of lightweight Java

XML-RPC services This partitioned approach enables application developers to utilize
a set of virtual machines with complementing features. The virtual machines have an

implicit trust relationship which can be realized with a virtual switch and a trusted
virtual domain (TVD) covering the corresponding sub-network of this switch.

Scoping of TC utilization:

 At the start of the project, behaviour and limits of TPM

devices   were   not   very   well   understood,   in   particular   with   regard   to   their   low

throughput. The cooperation with other OpenTC partners convinced us that TPMs are
best be used in a limited number of critical parts. This resulted in constraining TPM

utilization to back-end functionality.

Second   Prototype:

  This   implementation   addresses   the   scoping   aspects   by

supporting, but not requiring TPM equipped client machines  which have to provide
flexible compilation options and which have to be built for both TPM and non-TPM

machines

Major achievements

Redesign   of   existing   service

  towards   utilizing   the   OpenTC   architecture,

development of a robust inter-VM communication mechanism.

Encrypted   file   service

  using   multiple   compartments   to   shield   security

critical components and a recovery agent to support backup and recovery of
files.

Policy driven operation

 supported by a flexible policy language.

2.5.5  WP6e: Multi-Factor Authentication





This work package explored how to include Trusted Computing mechanisms for the
purpose of user authentication on standalone platforms. Geared towards gaining first

experiences   with   TPM   based   attestation   mechanisms,   its   main   purpose   was   to
support the developers during the first cycle of requirement analysis for the OpenTC

platform. This activity was therefore deliberately constrained in scope. In accordance
with OpenTC's Technical Annex, all work on the prototype was concluded during the

second reporting period.

Progress towards Objectives

Requirement analysis:

  the work package produced a set of initial requirements

analysis   by   evaluating   existing   authentication   solutions   used   in   open   source

operating systems. This initial analysis led to the development of a use case scenario

OpenTC  Publishable Activity Report

23/40

background image



 Publishable Activity Report OpenTC

and the requirement specifications.

Design of multi factor authentication:

  The resulting design utilizes the Trusted

Computing Module as secondary source of authentication information.

Prototype   implementation

:   A   test   concept   prototype   for   remote   logon   to   an

OpenTC platform (server) was developed. It registers and verifies user credentials for
TPM enabled client/server systems.

Re-evaluation of Design:

Potential security problems of using direct remote calls

of TSS functions from server to client computer during authentication process were

analysed,   resulting   in   modifications   of   the   MFA   architecture   to   eliminate   possible
holes.

Final prototype:

 The result for the server side comprises of the remote registration

utility, MFA SSH Authentication PAM module, user MFA policy editor, User and Policy

configuration files and Scripts. Client side components are: a utility to register user
with TPM credentials, client part of authentication server, and TPM control utility.

Major Achievements

Design of architecture for the MFA System Prototype

 to use any service

that supports the Pluggable Authentication Modules (PAM) technology

Extended   system   architecture

  for  using  MFA  system   for   common   cases

with multiple servers and clients

MFA registration and logon protocol

   writing software based on the PAM

framework

Providing   supporting   information

for   the   initial   OpenTC   platform

requirement analysis

2.6  WP07:   Development   Support,   Quality,   Evaluation   and

Certification Description

The   objectives   of   WP07   were   to   provide   support   to   the   platform   and   application
development   done   by   means   of   methods,   tools   and   methodologies   to   verify   and

validate parts of the OS software produced in OpenTC.
The initial main objective of this work package was to evaluate the reliability and

security of the OS code issued by WP04 (that is a combination of a trusted Xen/L4
virtualization layer and the Linux kernel) by means of extensive testing and static

analysis, guided by a proper methodology. The aim is to quantify the quality and
safety of this OS code, to provide feedback to the developers of this code, and to

analyse the possibility to certify (parts of) it at levels EAL5+.
Operating systems form a particular class of applications in terms of development

process and code that need particular adaptations in terms of methodology, methods
and tools. Starting from state of the art V&V techniques, solutions were developed to

analyze and test the OS code with a maximum of precision. Significant parts of our
work is   devoted  to  selecting   parts  of  the   OS  code  and  to  applying   the  tools  and

solutions to these targets.
A   further   goal   was   to   develop   an   open   trusted   methodology   for   V&V   and   apply

advanced   testing,   risk   analysis   and   verification   techniques   to   this   target.   These
techniques are further improved and adapted for application for Operating System

code.

2.6.1  Progress Towards Objectives





In summary, the objectives set for WP07 have been reached and even exceeded, as
WP07 provided a variety of tools and approaches to the OS V&V problem. These were

the results of a number of intensive research, development and application tasks.

OpenTC  Publishable Activity Report

24/40

background image



 Publishable Activity Report OpenTC

A   part   of   the   objectives   was   to   determine   the   applicability   of   different   kinds   of
analysis for OpenTC components:

Black-box testing performed on executable components, which are subjected
to a large number of test cases

Static analysis with commercially available tools, which is performed on the
source code of components, and

Static analysis using newly developed tools, which can be adapted to cover
specific challenges arising from low-level implementations

The research track of this work package covered the area of static code checking,
security and risk metrics, and methodologies. The practical track addressed the test

of   specific   OpenTC   components.   The   following   steps   were   taken   to   reach   the
objectives:

Survey   of   existing   tools

for   testing   and   analyzing   C   code.   Our   task   was   the

analysis of substantial amounts of code; the survey was performed with the goal of

selecting   the   most   appropriate   commercial   tools   for   the   analysis   of   low-level
operating system code. Our final choice was

Coverity Prevent

, which we used for all

OpenTC components. (TUS, BME).

Development   of   testing   methodology

:The   black   box   approach   requires   to

determine   the   appropriate   interfaces   for   applying   the   tests,   the   development   of
appropriate test cases in an iterative process, and the analysis of large amounts of

test   results.   The   methodology   was   developed   with   regard   to   analyzing   the
implementation of the Infineon Trusted Software Stack.

Methodologies  for  Open  Source Development:

  The  complexity of the  targets

became a subject of investigations, aiming at understanding why the hypervisors are

quite difficult targets in terms of V&V. Research also addressed security metrics for
static source code.

Trust and Security Testing Methodology:

  During the first phase, the OSSTMM

(Open Source Security Testing Methodology) with definitions of terminology  and a
production manual was published. During later phases, following a  study on how to

quantify Trust and Security in a measurable manner, trust and security metrics were
added, and it was investigated how these metrics are applied to applications.

Certifiability analysis:

  The analysis concluded the current impossibility to certify

the   Xen   hypervisor   due   to   the   non-observance   of   CC   design   criteria.   A   similar
analysis was performed for L4/Fiasco.

Test   and   verification   activities:

The   work   package   performed   the   following

extensive analysis tasks:

TSS testing:

 Tests revealed eight weaknesses and one remotely exploitable

buffer  overflow.   All  of  these   have   been   corrected   and   non-regression   tests

have confirmed this. Plans for testing the Xen core hypercalls are made.

Static analysis of the Xen core

focusing on five security critical hypercalls

using

Coverity   Prevent

  and   Frama-C   yielded  four  confirmed   errors   and

hundreds of potential bugs that were communicated back to the developers.

Testing   of   Xen   using   Flinder

:   BME   produced   a   test   plan,   and   then

performed   some   automated   security   testing   of   the   main   hypercalls   Xen,

namely   those   already   analyzed   by   TUS   and   CEA,   executing   240,718   test
cases. No major bug has been discovered. The subsequent manual security

testing on the XenAPI revealed some security weaknesses.

Static analysis of L4/Fiasco:

  the source code has been analysed by TUS

using   Coverity   prevent.   Six   categories   of   bugs   have   been   considered   and
numerous   alarms   were   found.   Most   of   them   are   related   to   the   resources

allocation, files and I/O.

OpenTC  Publishable Activity Report

25/40

background image



 Publishable Activity Report OpenTC

Static  analysis  of  OSLO

: The  OSLO  source  code  has  been  analysed  with

Frama-C. This led to a dozen of alarms.

Static   analysis   of   Xen

:  TUS   terminated   their   analysis   of   Xen   3.1   and

produced a synthetic report, where all bugs are classified into categories. The

partners CEA, BME and TUS have merged their bugs about Xen using the same
format and produced a common report.

Static   analysis   of   Vgallium

  (virtualized   version   of   the   Gallium   graphics

driver for Xen 3) using Coverity Prevent, Frama-C and SCARE: this was not

planed initially. Over 800 potential bugs were discovered.

Testing of the Trousers TPM driver code:

 this was not planed initially, but

was required by WP04 as Trousers is the only other alternative to the IFX TSS
and is fundamental to security. 16 security weaknesses were found.

2.6.2  Major Achievements





Successfully tested and corrected Linux version of the IFX TSS.

Analysed Xen 3.0.3 core with Coverity Prevent.

Analysed Xen 3.0.3 core main hypercalls with Frama-C.

C++ to C front-end prototype for the static analysis of C++ code.

Finalized security testing methodology.

Finalized operational security metrics.

Enhanced   open   AVIT   (Applied   Verification   for   Integrity   and   Trust)

methodology.

Two security and trust methodologies, one of them widely published.

A new static analysis tool, Frama-C.

A survey of the state of the art in the domains of static analysis tools, testing
tools and existing Linux kernel bugs.

Case studies on testing and analysis of selected OS code.

Research reports on difficult aspects: C++ code analysis, certification of OS

code, etc. (all)

The public web site

http://frama-c.cea.fr

 has opened and provides all facilities related

to the toolkit and its support, including forums, knowledge bases, downloads, a bug
tracking system, user and developer documentation, etc. A Trust Analyst certification

process has been started and will be available  at

http://www.trustanalyst.org

. The

completed   OSSTMM   methodology  was   published   in   the   widely   disseminated   Third

Edition of “Hacking Exposed” for Linux.

2.7  WP 08: Trusted Computing for embedded controllers and

mobile phones

WP08   task   was   to   investigate   the   use   of   Trusted   Computing   technologies   and
virtualization  on mobile  and  embedded  devices. The  major goals  were  to analyse

current standards in the mobile area, to develop and analyse appropriate use cases,
and to adapt work from other work packages to mobile scenarios.
In addition to analysing  security requirements and TPM functionality specifically for
this class of devices, the main objectives of this work package were to demonstrate

an architecture for a trusted platform for an embedded processor based system for a
mobile   phone.   This   included   porting   main   elements   from  other  work  packages   to

embedded hardware, to improve the system for the required security services and
performance,   and   to   establish   trust   and   security   profiles   for   the   system,   the

operating system, and applications.

OpenTC  Publishable Activity Report

26/40

background image



 Publishable Activity Report OpenTC

In summary, WP08 successfully reached all objectives. The following sections outline
the progress that was made throughout the project and the major achievements of

this work package.

2.7.1  Progress towards objectives





Definition of a minimum set of security requirements

 for a mobile phone trust

prototype.   WP08   performed   an   analysis   of   market   and   mobile   standards

requirements   with   regard   to   all   relevant   stakeholders   (device   owners,   device
manufacturers, content and service providers, network operators). The analysis of

applicable standards included the work of the Trusted Computing Group (TCG) and
the Open Mobile Terminal Platform Group (OMTP). In line with OpenTC's main focus

on platforms, the focus was on device security characteristics (as opposed to network
security).

Definition and analysis of use cases:

  Based on the use case document of the

TCG   Mobile   Phone   Working   group,   a   number   of   primary   use   cases   (for   example,

protection of IMEI, SIM lock, and user data DRM, secure application download) were
investigated to determine the basic security characteristics. The analysis of derived

use cases revealed that a TCG based architecture can fulfil many, but not all security
requirements.   While   standard   requirements   such   as   integrity,   authenticity   and

confidentiality can be covered, open mobile devices such as suggested by the OMTP
require additional mechanisms for trusted boot-up and secure execution.

Definition   of   life   cycle   characteristics   for   trusted   mobile   devices:

  WP08

investigated the security structures and techniques developed by the TCG and the

specifications from the TCG Mobile Working Group. Trust relationships and necessary
technological support were  analysed  and detailed for each point in the life cycle of

the device and hosted applications. The work package conceptualized how to use
TCG based techniques to support application installation, system boot, secure data

storage and end of life management.

Definition of trust and security profiles:

 Based on the security analysis of OMTP

TR0   device   characteristics,   the   L4   microkernel   and   the   use   cases   chosen,   WP06
determined the set of fundamental components that have to be embedded in order

to meet the security requirements identified in its prior investigation.

Contribution to standardization:

  During the course of the project, the OpenTC

partners Comneon and Infineon participated in the continued specification activities
of the OMTP and contributed to the review of its new Advanced Trusted Environment

(TR1)   that   was   produced   during   this   time.   Vice   versa,   the   basic   trust   functions
selected by WP08 are largely aligned with this standard. RHUL participated in the

Software Defined Radio security working group, examining on how TC functionality
may   be   integrated   in   the   SDR   architecture,   in   particular   with   regard   to   secure

software download.

Design and development of prototypic demonstration application:

WP08 has

implemented a secure wallet application prototype on a PC platform, running in an
isolated compartment and protecting user secrets by a trusted storage subsystem.

Due to resource constraints, some use case-specific parts (which include a GUI, a
complete web browser and a Java virtual machine) could not been ported to a mobile

platform.

Porting   micro-kernel   based   hypervisor   to   mobile   platform

:   The   L4-Fiasco

architecture and the user space framework L4Env underlying the secure wallet was
ported   to   Infineon   X-GOLD208   platform   which   is   based   on   ARM926   core.   The

implementation   offers   basic   support   for   on-chip   peripherals   (interrupt   controller,
timer, serial interface) and supports virtualized TPM functionality.

2.7.2  Major Achievements:





The major achievements of this work package are:

OpenTC  Publishable Activity Report

27/40

background image



 Publishable Activity Report OpenTC

A thorough examination of the TCG and OMTP standards,

The   security   analysis   of   several   use   cases   that   are   relevant   for   mobile

scenarios,

The development and analysis of the Secure Wallet use case as an example

scenario,

The port of basic microkernel-based operating system components from other

OpenTC   work   packages   (in   particular:   the   L4   microkernel,   L4   environment,
L4Linux),

The port of the TPM emulator and its modification to use security features of
the mobile hardware.

The   results   of   WP08   were   communicated   through   numerous   peer-reviewed   and
invited papers, conferences, and workshops.

2.8  WP09:   Distribution   of   Trusted   Linux   Platform   and

Modules

The general objective of this work package is the distribution of the Platform and
Modules developed by OpenTC. More specifically, this includes the selection of SW

modules   from   project,   packaging,   support   on   quality   assurance,   marketing,   and
general   developer   support   for   Linux   related   questions   and   problems.   Contrary   to

other   work   packages,   it   is   represented   by   a   single   project   partner,   namely
SuSE/Novell.

2.8.1  Progress towards Objectives





SuSE's contribution was somewhat hampered during the first year of the project due

to OpenTC's initial focus on minimal Linux distributions and its need to rapidly adopt
an existing development environment. With the production of the first CD release,

however, the participants realized that the maintenance of future distributions would
become unmanageable without an automated build system.
From   that   time   on,   SuSE   guided   the   developers   towards   adopting   OpenSuSE   as
development and target system. Not least, this concerned workflow organization and

configuration steps that have to be followed in order to make software packages of
developed components digestible for the build process.
All deliverables of this work package were moved into the second and third reporting
period. As a preparatory step, SuSE had started to include the Xen hypervisor in one

of     their   standard   distributions,   starting   with   a   re-mastered   version   of   OpenSuSE
10.1.   The   adoption   of   Xen   as   an   integral   part   of   the   distribution   still   required

considerable   effort,   but  the   integration   had   reached   a  stable   state   when   OpenTC
started to port their components to OpenSuSE 10.3 in 2007.
In parallel, SuSE created an infrastructure for the management of the software build
process, revision control, configuration management, storage and the dissemination

of RPM packages that are compiled and packaged on a dedicated build farm. This
infrastructure,   which   can   also   be   used   for   more   general   purposes,   provides   a

framework to generate any gusto of a Linux distribution using the infrastructure and
tools by the distributor.
In   the   General   Assembly   in   September   2007   POLITO   was   formally   appointed   by

OpenTC   consortium   for   leading   the   activities   for   the   next   Proof   of   Concept  (PoC)
prototypes within WP09 and under the overall supervision by SuSE as WP leader.

From  M25 onward,  POLITO's  activities   related   to  the  PoCs  were  performed   in  the
context of and accounted against WP09.
The work performed   by POLITO for the Proof of Concept (PoC) prototype for the
scenario   “Corporate   Computing   at   Home”   (CC@H)   during   M25-M42   concerns   the

general   coordination,   development,   integration   and   test   tasks   of   the   distribution,

OpenTC  Publishable Activity Report

28/40

background image



 Publishable Activity Report OpenTC

production   of   documentation   and   of   test   instructions,   and   determining   the   actual
date for the release. For the “Virtualized Data Center” PoC, it also included the co-

design of the scenario, roles and components, the co-definition of the TVD policies,
enhancements of previous components, restructuring tasks, integration and tests.
During the reporting period, POLITO and SuSE supported three cycles of adapting

OpenTC components to new versions of OpenSuSE (10.3, 11.0. 11.1). In some cases,
these adaptations were quite tedious and consumed considerable effort. They were

unavoidable,   though   critical   components   of   the   OpenTC   framework   had   to   be
implemented   as   loadable   modules   which   depend   on   low-level   mechanisms   and

interfaces of the Linux kernel. These can change between subsequent releases, and,
in fact, they did.
SuSE   acted   as   advisor   for   partners   with   little   experience   with   OSS   licenses   who

started   Open   Source   Software   review   processes   for   the   release   of   their   software
under a FOSS license. In some cases, intellectual property constraints for OpenTC

software packages not yet released under a free license demanded to separate them
from the publicly accessible OpenSUSE package repository. The build system proved

to be flexible enough to address this requirement.

2.8.2  Major Achievements





Infrastructure   for   configuration   management,   package   building,   and   bug
tracking private to the project

Packaging   of   RPM   packages   of   Trusted   Computing   and   virtualization
components

Integration of the SUSE version/port of the PET 2006 PoC prototype

Professional   development   platform   to   implement   the   2007   PoC   prototype

(

CC@H

),     including   bugfixing   of   components   relevant   to   the   Trusted

Computing and virtualization functions used by OpenTC

Packaging and distribution o

CC@H

 prototype

Packaging and distribution of Virtual Datacenter prototype

Support of three porting cycles of the OpenTC platform

Dissemination and publication of all prototype, along with documentation and

guidance. The directory is mirrored on ftp servers worldwide

As  of April 2009, all software  components  necessary to operate  a TPM  are

included and integrated in OpenSuSE

Support in licensing questions and in quality assurance

2.9  WP10: Dissemination, Exploitation and Training

2.9.1  Objectives





The   fundamental   objective   of   WP10   was   to   disseminate   the   trusted   computing

concepts and the corresponding hardware, software and applications that have been
developed   within   the   project.   In   order   to   maximise   the   benefit   for   the   project

partners and stakeholders the following measures were taken.

Close co-operation with standardisation bodies - such as, the TCG,  MPEG, Java
and OMTP standardisation  bodies - to provide input to and influence (new)

standards (SWP10a).

Dissemination of the main project results through various channels such as
conferences and trade shows, articles in technical and academic publications

and technical workshops (SWP10b).

Development   of   training   concepts   and   material   to   ensure   knowledge   and
innovation transfer (SWP10c).

OpenTC  Publishable Activity Report

29/40

background image



 Publishable Activity Report OpenTC

Development and implementation of an exploitation plan at a consortium and
partner level (SWP10d).

The general goal of all these activities is maximize the benefit of participants, project

stakeholders and the impact of the project on trusted computing and ICT in general
on the basis of an informed dialogue about the benefits and drawbacks of TC, and

the   OpenTC   approach   in   particular   (including   its   applications   such   as   DRM)   with
stakeholders, different user groups, and citizens.

2.9.2  Progress Towards Objectives





SWP 10a: Standardisation Activities Including TCG Liaison

A relationship with the TCG has been established, and involved direct and continuous

interaction through various active OTC industry members who have a prominent role
within the TCG; for example, HP, IBM, IFX and AMD are members of the TCG board of

directors and are also project partners. The TCG, however, imposes very strong non-
disclosure and non-patent agreements on its members to prevent any economic and

structural restrictions on the exploitation of patents or intellectual property (IP) by
organisations   which   have   access   to   current   standardisation   work.   The   TCG   is

attempting, however, to bring its own non-free IP into the standard and to apply for IP
rights   (like   patents)   on   the   TCG   working   group   results.   To   give   governments,

universities  and other research institutes the chance to participate and influence the
TCG   standardisation   work,   the   TCG   liaison   group   was   created.   In   this   way

organisations can participate without paying any membership fees (but receive no
voting   rights).   Currently   POLITO,   IAIK   and   RHUL   are   members   of   the   TCG   liaison

group.   Both   means   of   TCG   interaction   (via   OTC   partners/TCG   members   and   the
liaison program) is believed to have been effective.
To verify the compliance and conformance of product implementations to the TCG

standards,   the   TCG   has   created   a   special   compliance   verification   project.   Some
OpenTC members (for example, members of WP07) have participated actively in this

project.   To   make   such   compliance   test   scenarios   and   test  suites   available   to   the
public, OpenTC partners have prepared   the ''VerifyTC'' proposal for the 2

nd

  call of

FP7,   which   made   test   scenarios   and   the   results   of   testing   the   conformance   and
compliance   of   new   products   available   to   the   public;   this   has   enabled   unbiased

reports   detailing   the   strengths   and   weaknesses   of   TC   implementations   to   be
delivered.
The development of the new TPM software stack (TSS) standard version 1.2 within

the TCG was completed in parallel to the development of the OpenTC TSS in SWP03b
by IFX. This parallel implementation enabled the developers from WP03 to provide

the TCG TSS WG with valuable input regarding their experience. The implemented
result was then tested within WP07 and feedback delivered. This new TSS stack from

OpenTC WP03 was released at the same time as the TCG published the respective
standard.
LVD have participated in several MPEG meetings to support the development of the

ISO/IEC   23000-7   Open   Access   Application   Format   and   the   MPEG-21   REL   (Rights
Expression Language). Technical work on the two standards within the MPEG Group

has now been completed. Currently the standards are under final ballot and some
editorial improvements have been made. The reference software for both standards

has also been completed. An implementation of the Open Access Application Format
has   been   published   and   reference   software   for   MPEG-21   REL   is   available   on   the

MPEG-21   reference   software   site.   Standardisation   of   the   reference   software   is   in
progress.   An   amendment   of   both   standards   has   been   initiated   to   include   a

description of the software and its conformance to the standards. The current status
of the documents is “Final Committee Draft”. Finalisation of these documents within

the MPEG group has been planned for October 2008.
The proposal for *“JSR 321: Trusted Computing API for Java"*, submitted by IAIK to
the Java Community Process in late 2007, has been reviewed and voted on by the

OpenTC  Publishable Activity Report

30/40

background image



 Publishable Activity Report OpenTC

J2SE Executive Committee, receiving overwhelming support with 15 out of 16 votes
in favour (one abstention). Following this, an Expert Group was formed. IAIK is now

leading this group of international experts from academia and industry. In the spirit
of the OpenTC project, this Java Specification Request No. 321 (JSR321) has chosen

an open, transparent and agile working style. Thus,  technical discussion is open to
non-members of the JCP, allowing for further co-operation and integration with the

open source community. At the time of writing, IAIK is in contact with experts from,
but not restricted to:

Sun (J2SE Security Architect), USA;

Intel, USA;

University of Klagenfurt, Austria;

University of Cambridge, UK (Open-TC partner);

Portakal, Turkey (Open-TC partner); and

CSAIL, Massachusetts Institute of Technology, USA.

The public website of JSR 321 is available at https://jsr321.dev.java.net/. Workshops

with in-person meetings have also been held.
RUB and HP have participated in the development of a Common Criteria protection
profile for high assurance security kernels (HASK-PP), together with Sirrix AG, Atsec

Information Security, and the German Federal Office for Information Security (BSI).
Input from OpenTC was considered during the requirement definition phase of this

protection profile's development. A scientific paper which describes this work was
published at TRUST 2009 (M42).
WP08 (mainly TUD, IFX, COM and RHUL) has analysed and worked on related trusted

mobile phone standardisation with both TCG and non-TCG standards groups. For
example, RHUL worked with members of the TCG MPWG, and IFX has been heavily

involved in the security work of the Open Mobile Terminal Platform (OMTP). OMTP is
an operator sponsored forum which aims to serve all stakeholders in the mobile

phone value chain by gathering and driving requirements.  The requirements are
technology platform neutral, and aim to promote the adoption of new services across

a range of platforms. OMTP is currently working on an extension of the TR0 Basic
Trusted  Environment, i.e. to produce the Advanced Trusted Environment (TR1). TR1

has defined recommendations for security enablers such as secure storage and
trusted execution environments. IFX took part in this standardisation work. This

included teleconferences, face to face meetings, and specification review work. By
doing this, we ensured that WP8 work took the latest requirements into account as

soon as they were available.

SWP 10b: Dissemination of Project Results

Over the course of the OTC project, all partners have been actively involved in raising

public awareness on TC and in presenting the work completed by the OpenTC.  A new
version of the OpenTC website was constructed by TEC. It was created using the

content management system Joomla and provides a number of new features (e.g.
Forum, Online Newsletter registration, Newsletter archive, Download Area). Here we

have   made   more   OpenTC   documents   (deliverables,   research   papers,   other
publications) available online. TEC also installed the Subversion System for the Build

Server at SuSE Nürnberg, which is used to contain the public version of the OpenTC
proof-of-concept prototype.
The OpenTC newsletter editor, ITAS, has overseen the completion of seven issues

(June 2007, October 2007, January 2008, February 2008, March 2008, June 2008 and
April 2009) with help from various partners for contributions, corrections and proof-

reading. A facility for providing feedback to the consortium has been implemented
together with Technikon. Interested individuals may now provide feedback using a

link in the newsletter or directly though the website. A small number of feedback

OpenTC  Publishable Activity Report

31/40

background image



 Publishable Activity Report OpenTC

messages have been obtained and answered.
To fulfil the defined objectives the project has also co-operated with external bodies
and organisations and participated in public, scientific and educational events.  This

includes participation in events such as the Second Workshop on Advances in Trusted
Computing (December 2006, Tokyo, Japan), the IEEE Consumer Communications and

Networking   Conference   CCNC   2007   Conference   (January   2007,   Nevada,   USA),   the
Workshop on Trusted Computing from a European Perspective (February 2007, Bonn,

Germany),   the   CeBIT  Industrial   Conference   (March   2007,   Hanover,   Germany),  the
2007   Information   Security   Summer   School   (August   2007,   Taipei,   Taiwan),

Foundations of Security Analysis and Design 2007 (September 2007, Bertinoro, Italy),
the Trustworthy Global Computing 2007 (November 2007, Sophia-Antipolis, France),

Axmedis 2007 (November 2007, Barcelona, Spain),  FOSDEM 2008 (February 2008,
Brussels,   Belgium),  TRUST   2008   (March   2008,   Villach,   Austria),   EUROSEC   2008

(March   2008,   Glasgow,   UK),   WSES   2008   (May   2008,   Lyon,   France),   ETISS   2008
(September 2008, Oxford, UK) and Trust 2009 (April 2009, Oxford, UK). All project

partners   have   also   actively   contributed   to   academic   papers/journals,   newspapers,
books,   magazines.   Numerous   articles   have   been   published   in   magazines   and

journals, such as an invited paper at the 5

th

  SDR Technical Conference (November

2006, Orlando, USA), UbiSafe 2007 (May 2007, Ontario, Canada),  an invited paper at

FOSAD 2007 (September 2007, Bertinoro, Italy), IEEE Security and Privacy (M37/38)
and Cryptologia (to appear 2009). Contributions to books have also been made – see,

for example, an invited book chapter in Crimeware (April 2008, Addison-Wesley).  A
full list of dissemination activity is available in D10.3 – Intermediate Dissemination

Activities   Report   and   Dissemination   Plan   (M18)   and   D10.9   Final   Dissemination
Activities Report and Dissemination Plan (M40).
The   most   prominent   dissemination   event   held   during   2008   was   TRUST   2008,

organised by Technikon. Trust 2008 was an international event, which took place in
Villach, Austria in March 2008 and brought together scientific stakeholders from all

over the world in the field of trusted computing. The conference focused on trusted
computing   and   trust   in   IT,   and   saw   the   presentation   of   both   state   of   the   art

technologies   and   forward   looking   research   papers.   The   main   module,   i.e.   the
scientific conference, served to maximise communication and knowledge exchange

between   international   parties   from   both   the   scientific/research   community   and
industry.

During Trust 2008, several project meetings and workshops took place. In the foreground was the
OpenTC meeting, at which almost all partners were represented. The research papers presented
during   the   scientific   module   at   the   conference   (which   are   highly   relevant   to   the   work   being
completed within OpenTC) were published by Springer Verlag in LNCS 4968. Feedback indicated
that   the   international   audience   from   both   industry   and   science   was   pleased   by   the   mix   of
conference articles, project presentations and discussions. In total 159 participants (made up of
people of 18 different nationalities from 4 continents) registered for Trust 2008.

A   demonstration   of   the   OpenTC   PET   (Private   Electronic   Transactions)   proof-of-
concept   prototype   was   given   by   RHUL   at   the   annual   HP   Information   Security

Colloquium hosted by RHUL in December 2006. This demonstration was organised in
coordination with the OpenTC demo group (HP Labs Bristol, POLITO). It furthered the

testing of the OpenTC prototype and involved developing early documentation for
the OpenTC prototype, in particular those concerning troubleshooting. A poster for

the   OpenTC   prototype  was   also   created   and   its   content  used   during   the   OpenTC
review meeting.
A   demonstration   of   the   OpenTC   CC@H   (corporate   computing   at   home)   proof-of-

concept   prototype   was   given   at   the   annual   HP   Information   Security   Colloquium
hosted   by   RHUL   in   December   2007.   This   demonstration   was   organised   in   co-

ordination with the OpenTC demo group (HP Labs Bristol, POLITO).  A poster for the
OpenTC   prototype   was   also   created   and   presented   at   TRUST   2008,   the   HP

Information Security Colloquium hosted by RHUL in December 2008.

OpenTC  Publishable Activity Report

32/40

background image



 Publishable Activity Report OpenTC

SWP 10c: Training

As university courses on trusted computing are still rare, OpenTC academic partners
have   initiated   and   are   continuing   their   academic   training.   RHUL   and   IAIK   have

graduate level courses devoted to many aspects of trusted computing, whereas TUB
is contributing to an undergraduate course in security in which trusted computing is

also covered.
A full 11-week course on trusted computing (comprising of 11 3-hour lectures) was
initiated in January 2007 and has been delivered since then as part of the Masters in

Information   Security   at   RHUL.   This   included   2   guest   lectures   given   by   Graeme
Proudler from HP Labs Bristol and Steve Hand from the University of Cambridge in

2007 and Graeme Proudler and Chris Dalton from HP Labs Bristol in 2008 and 2009.
Two pieces of coursework and an examination were also written. The OpenTC proof-

of-concept prototype was presented during a lab session in 2009.
More   recently,   RHUL   has   also   seen   the   introduction   of   a   new   ‘security-focused’
undergraduate degree in computer science. As part of this undergraduate degree

program a course in trusted computing will be offered in 2009/10, again building
directly on the dissemination materials developed within the OpenTC project.
IAIK   started   giving   a   course   entitled   “Selected   topics   of   IT-security:   Trusted

Computing” in March 2007, with about 30 registered students. In this course, besides
teaching the theory of trusted computing in a conventional way, students also use

TPM-emulators   and   components   developed   within   OpenTC   for   practical   exercises.
This course has continued through 2008 and 2009. In 2008 students on this course

were given the opportunity to visit the educational event at Trust 2008, as well as
the scientific conference, and the task to write papers on selected topics of trusted

computing for presentation. An extended guest lecture from David Grawrock (Intel) is
planned for May 2009.
In 2006 TUB started giving a lecture entitled “New Technologies in Security” focusing

on trusted computing at the Computer Engineering Department, University of Kocaeli
(Turkey). 5 weeks of this course are dedicated to trusted computing technologies.

This course also continues.
The  course  "Project  Risk Management" was  held  in Halmstadt,  Sweden  at  project
start in November 2006 with 30 engineering students. One goal was to introduce the

students at Halmstadt to the OpenTC project. The students were ask to chart up,
identify and evaluate potential risks connected with trusted computing. Thereafter,

as second goal of deeper understanding the technology, the students were divided
into groups of 4-5 people for an OpenTC case study. The student had to choose the

identity of one of the following four groups: (a) Governmental Agency, (b) Private
Person, (c) SME (Small and Medium Enterprise) or (d) Industry, and they had to look

for the potential influence of trusted computing on their chosen identity. The case
study   questions   were   (a)   Find   the   expected   impact   on   the   identity   chosen,   (b)

Describe   the   IT   fields   in   the   sector   which   might   be   most   influenced   by   trusted
computing, and (c) Identify the major risks issued or covered by trusted computing

Technology for their identity. For the five highest risks they were asked to derive
mitigation plans and to draw a contributing factor diagram (CFD) for security issues

and to make trusted computing the chart destination.
In   addition   OpenTC   partners   worked   in   co-operation   to   realise   the   2

nd

  European

Summer school on Trusted Computing (see http://www.etiss.org/ for details) and also

presented their results in other training settings during summer 2007. HP extended
the PET Demo as a tool for training sessions at the summer school and also prepared

material for training (i.e. Asia-Pacific Summer School). POL prepared two documents
describing their work on the Demonstrator Prototype, i.e the test sequence for the

PET   Demo   and   a   lab   exercise   manual   for   a   “Trusted   Virtualisation   Lab”.   Both
documents were used in the summer school. IAIK held workshops at the summer

school and made contact with several outside organisations, already making use of
OpenTC   deliverables.   The   feedback   gained   will   certainly   contribute   to   future

OpenTC  Publishable Activity Report

33/40

background image



 Publishable Activity Report OpenTC

semesters of their course.  OTC were also visible in the 3

rd

  European Summer school

on   Trusted   Computing   where   once   again   where   HP   gave   a   presentation   on

virtualisation, POL mediated a practical workshop and RHUL gave a presentation on
mobile trusted platforms.
In   addition   to   academic   partners,   commercial   partners   are   also   trying   to   support

thesis   work   relating   to   trusted   computing.   One   MSc   student   from   Middle   East
Technical   University,   Institute   of   Applied   Mathematics   is   now   an   unpaid   graduate

intern   at   PORT.     One   MSc   and   one   PhD   student   from   Fatih   University,   Dept.   of
Computer Engineering has made use of OpenTC infrastructure on realising trusted

authentication, authorisation and auditing for an experimental voice over IP (VoIP)
system. One team of three senior students from Atılım University, Dept. of Computer

Engineering   has   developed   a   secure   e-commerce   protocol   that   works   on   public
Internet. Many students from Bilkent University, Dept. of Computer Technology and

Programming have also used OpenTC deliverables for their graduation projects.
A series of seminars have also been presented by various partners. For example, IAIK
participated in the Educational Event at Trust 2008 (March 2008, Villach, Austria)

presenting two classes on “How Trusted Systems are Programmed: A Practical View”
and “ Mobile Trusted Computing”.   RHUL also presented a session entitled “Who is

the TCG and what are the TC concepts?” at TRUST2008. TUB presented a tutorial
entitled “Trusted Virtualization and Grid Security” at CCGrid 2008 (May 2008, Lyon,

France).

SWP 10d: Exploitation

The objective of SWP10d was to develop strategies for creating revenue from the
project results. Specific goals were to:

promote rapid technology implementation and transfer;

maximize the benefit for the project participants; and

establish a European approach for trusted computing.

In cooperation with other OpenTC work packages, all goals were achieved. For the

duration   of   the   project,   WP10d   has   worked   on   the   basis   of   a   continually   refined
exploitation   plan,   which   was   supported   by   a   market   study   and   a   patent   study

performed by WP02. During this time, WP10d has made substantial progress towards
its objectives.

In order to enable rapid technology implementation and transfer, WP10d has,

from the outset, encouraged and guided an incremental development process
geared   towards   producing   conceptual   prototypes   that   address   real-world

scenarios.   This   approach   has   proven   to   be   successful   far   beyond   our
expectation.   The   proof-of-concept   prototypes   served   as   intermediate

milestones   whose   results   could   be   demonstrated   both   internally   and
externally.   In   particular   for   CUCL   and   HP   Laboratories,   it   allowed   us   to

convincingly showcase OpenTC results to product divisions as early as mid-
2007.

Work   on   OpenTC   was   instrumental   in   establishing   open   source   based

hypervisors   as   serious   alternatives   to   proprietary   solutions   for   HP's   future
commercial products, something that would have been very hard to achieve

without the preparatory groundwork HP Labs has performed in the context of
this project. Product divisions in HP and Citrix have since performed their own

studies   on   commercialising   trusted   virtualised   client   platforms,   which   are
currently evolving into concrete product roadmaps.

As a major contribution to accelerate technology implementation and transfer,

WP10d   and   WP09   jointly   developed   and   put   in   practice   a   concept   to
streamline   the   build   process   of   software   components   developed   by   the

project. OpenTC components are now provided through an industry-strength
configuration   and   distribution   management   system.   The   final   OpenTC

OpenTC  Publishable Activity Report

34/40

background image



 Publishable Activity Report OpenTC

distribution   as   well   future   ones   are   delivered   through   the   OpenSuSE   build
environment, following a defined workflow for package creation, management,

and   deployment.   The   process   is   highly   automated,   which   maximizes   the
chances of future maintainability even with limited human resources.

WP10d located several exploitation opportunities and was, in many cases, able

to   facilitate   the   adoption   of   OpenTC   results   by   industrial   partners.   Future
versions   of   the   OpenSuSE   build   service   will   benefit   from   the   experiences

gained throughout the project. Components and concepts developed during
the projects have been or are in the process of being adopted by HP, IBM,

SuSE/Novell   and   CUCL/Citrix.   Examples   include   network   virtualisation
technology, software components to support security enhanced graphical user

interfaces,   and   approaches   to   reduce   the   set   of   privileges   necessary   for
management domains.

The   OpenTC   study   on   existing   intellectual   property   has   since   been   made

available to the TCG upon their request. A comparative analysis of TPMs from
different   vendors   performed   by   OpenTC   partner   RUB   has   substantially

contributed to the TCG debate on interoperability and certification of trusted
computing components. This discussion has resulted in the creation of a new

TCG certification program that was announced in April 2009. As a cooperative
activity between the German BSI, Sirrix AG, and OpenTC partners launched in

2007, a Protection Profile for High Assurance Kernels was produced. The final
version (HASK_PP v1.14) was published in June 2008.

To further OpenTC's exploitation for education and research purposes, WP10d

has,   in   cooperation   with   other   WP10   partners,   initiated   and   supported   the
extension of the intermediate 'Corporate Computing at Home' scenario into a

platform   that   has   become   an   integral   part   of   academic   and   professional
education on trusted computing. In conjunction with the material developed

for   presentations,   conferences,   courses,   and   summer   schools,   this   line   of
exploitation   was   and   is   instrumental   for   generating   and   broadening   the

expertise on trusted computing technology in Europe.

Results of both academic and commercial interest concern the improvement
of test and validation tools, in particular in the area of static code analysis.

OpenTC's   work on   low-level  aspects  of  hypervisors  have   spawned  research
activities   on   new,   capability   based   microkernel   hypervisors   RUB)   and

advanced   methods   for  I/O   sharing   and   multiplexing   (HP).   Experiences   from
testing the Xen hypervisors have contributed to a paradigmatic shift towards

language based security: the next generation of management tools for Xen
will be developed in Objective Caml, which enables simplified and improved

static code analysis of the implementation.

The hypervisor core engines and the trusted computing stacks to extensive
testing. The natural way of exploiting this activity was to communicate test

results to the respective software developers. This has resulted in numerous
bug   fixes   and   patches,   improving   the   overall   software   quality   and   security

characteristics of the software and creating community benefits for developers
of open source software.

In   cooperation   with   WP01,   WP10d   has   ensured   that   project   results   are

exploitable by overseeing the release of all results under open source licenses.
As   it   stands,   all   relevant   components   of   the   architecture   can   freely   be

distributed and used by developers outside the project.

WP10d has initiated and facilitated a number of follow-up activities. They concern a
new   research   initiative   on   Trusted   Virtual   Client   Management   in   HP   Labs,     the

application of OpenTC results to cloud-scenarios through a cooperation with the EC
funded RESERVOIR project, and the future maintenance of the OpenTC Platform for

Training and Education.

OpenTC  Publishable Activity Report

35/40

background image



 Publishable Activity Report OpenTC

Follow-up activities that are currently in the planning stage concern the application
and extension   of the Open Source Testing Methodology developed in OpenTC and

workflows   to   create   information   on   the   trustworthiness   and   security   attributes   of
software.   OpenTC   partners   HPLB,   SuSE   and   ISECOM   are   investigating   options   to

combine   existing   metadata   repositories   and   automated   testing   processes   to
generate trust and security related metadata on packages that are integral part of a

trusted computing base for hypervisors. This line of research might be pursued in the
context of a  future EC funded project.

2.9.3  Major Achievements





Standardization:

  Through   its   partners,   OpenTC   maintained   and   extended   its

relationship with standardization bodies (i.e. 3GPP, OMA, MPEG, JAVA Community and
the TCG) via direct and continuous interactions. TCG members that are also project

partners  (i.e. HP, IBM, IFX, AMD) regularly input project results  to standardization
bodies' workgroups and stayed in touch with the latest developments. Work the TSS

directly influenced the TCG TSS work group and led to the implementation of the new
TSS API specification with the Infineon TSS Stack that was released by the OpenTC

project. Work a Java API for Trusted Computing resulted in the successful approval of
the JSR 321 (Java Standardisation  Request) which since released its first draft for

public review. This activity will continue under the leadership of OpenTC partner IAIK.
LDV   has   continued   its   contribution   to   the   Open   Release   MAF   (MPEG   Application

Format) to the MPEG-A Standard and submitted reference implementations for the
Open  Access  Application  Format   and  the  REL  OAC  profile  (license  interpreter and

license creator). POL contributed TCG results to the field of signing applications and
worked within the corresponding national body in Italy (UNI/UNINFO). Infineon and

Comneon   contributed   actively   to   the   Open   Mobile   Association   (OMA)   standards,
provided   feedback   on   implementation   experience   and   results   from   the   Open_TC

project,  and contributed to the review of the OMTP Advanced Trusted Environment
(TR1) specification.

Dissemination:

  The dissemination of results was continuously increased between

reporting periods. First, conservative estimates suggest that OpenTC partners have

contributed to  around 45  international and  15  national presentation and talks,  60
international   conferences,  around   90  international   and  5  national   publications,   as

well as publicly delivering 9 national and 22 international courses during the lifetime
of the project. OpenTC was internationally present at numerous events all around the

world, ranging from New Zealand and East Asia (e.g., Japan, Malaysia, China) to the
Americas. Extended versions of the proof-of-concept prototypes served as hands-on

training systems in multiple summer schools and educational events, and the project
partners disseminated results in  approximately 50  national and European projects.

OpenTC   has   maintained   its   own   website,   produced   a   regular   newsletter,   and
distributed   its  technical  results  through   the  infrastructure   of  SuSE with  worldwide

mirrors.   We   take   particular   pride   in   having   helped   to   lay   the   foundations   for
establishing  a new,  annual scientific  conference  (TRUST)  which  first  took place in

Villach/Austria (2008) under the auspices of and organized by project partners. In
retrospect,   OpenTC   was   instrumental   for   fostering   an   evolving,   international

academic and industrial research ecosystem for trust in IT in its early beginnings,
which has since been successfully established.

Training and education:

 OpenTC has delivered more than 35 complete courses on

Trusted   Computing   and   the   Open_TC   approach.   Most   of   the   extensive   amount   of

information   and   lecture   slides   were   all   made   publicly   available   on   the   Open_TC
partner's website and were released under the Creative Commons license, akin to

the FOSS licenses used in other parts of the project. Lectures were given e.g. at the
Information   Security   Summer   School   (ISSS'   07)   in   Taiwan,   at   the   Foundations   of

Security   Analysis   and   Design   (FOSAD   2007)   in   Italy   by   RHUL,   at   the   Asia   Pacific
Trusted Infrastructure Summer Schools (APTISS) in Zhuhai (2007, China) and Pulau

Pinang  (2008, Malaysia)  as  well as  in  practical labs  at  the  second  ETISS  summer
school and the TRUST2009 conference in Bochum (2007, 2008, Germany). Seminars

OpenTC  Publishable Activity Report

36/40

background image



 Publishable Activity Report OpenTC

on Trusted Computing were made part of the curriculum of academic partners such
as RHUL and IAIK (University Graz).

Exploitation:

HP Labs, IBM Labs, and SuSE have each introduced results of OpenTC

to product divisions of their companies and raised considerable interest. An analysis
of   the   current   market   for   trusted   computing   and   virtualization   technology   was

combined with the final version of the exploitation plan in November 2008. OpenTC
collaborated   in   the   production   of   CC   EAL5   Protection   Profile   for   High   Assurance

Security Kernel (HASK-PP). The IPR study initiated by OpenTC was made available to
the   Trusted   Computing   in   support   of   the   ISO   standardization   of   the   TCG

specifications. Many of the standardization efforts mentioned above will be continued
by the individual partners beyond the conclusion of the project.
Considerations for dissemination and exploitation of OpenTC's results have directly

influenced the following aspects

Final OpenTC distribution:

  The work package facilitated the decision to base

the OpenTC distribution on the latest official OpenSuSE distribution available

to   the   project.   While   considerable   effort   had   to   be   spent   on   porting   the
architecture recent 11.1 version, this was deemed to maximize the chances of

adopting the project result results.

Future maintainability of OpenTC distribution

: In cooperation with WP09, the

work   package   drove   the   difficult   decision   to   base   the   integration   and
packaging of all OpenTC components on the industry grade OpenSuSE build

and release system. As a result, the complete OpenTC distribution – as well as
streamlined distributions and compartments for dedicated purposes – can now

be   produced   from   scratch   in   an   automated   process   that   covers   patching,
compilation and imaging.

During M36 to M42, OpenTC partners have started to execute the exploitation plan.
Our main focus is currently directed at a dedicated OpenTC distribution based on

OpenSuSE based on the most recent stable OpenSuSE distribution available to the
project.   Further   efforts   concern   the  Xen   hypervisor,   where  features   of   service

decomposition and results of OpenTC's work on secure graphical interfaces will be
included in future releases. Core concepts of Trusted Virtualized Clients as developed

by   the   project   were   communicated   to   HP   product   divisions   and   are   subject   to   a
product study. IBM plans to include concepts from OpenTC in future architectures for

managing   virtualized   nodes   and   networks.   Future   versions   of   SuSE's   enterprise
server as well as the corresponding Desktop product will come with enhanced TC

support   with   additional   software   packages   based   on   OpenTC   components.   This
includes the vNET VPN routing package, the

libvirt

 package for TVD instrumentation

of   Xen   virtual   domains,   and   TPM   support   for   x509   frameworks   with   the   openssl
package set. Based on OpenTC's experiences with building dedicated distributions

and virtual images, SuSE is in the process of releasing an automated build service
with simplified interface to end users.

OpenTC  Publishable Activity Report

37/40

background image



 Publishable Activity Report OpenTC

3   Dissemination and Use (“Publishable Results”)

To enable maximum community benefit, the project results were integrated into, and
distributed as, Open Source software, supporting Linux in particular. A main objective

was  the   development  of  complete  trusted   Linux kernels  for  different use   classes,
which   will   be   distributed   as   part   of   the   Novell/SUSE   (a   project   member)   Linux

distribution   package.   By   making   the   project   results   widely   available,   the   OpenTC
consortium expects to encourage Europe’s IT industry to invest in trust and security

development. Especially small and medium-sized enterprises, industry, and research
institutions will be enabled to develop and market trusted computing systems and

applications independently. The integration of trust and security into next-generation
European products will make these more competitive on the world market.
An   important   result   achieved   during   the   second   period   of   the   project   was   the
publication   of   its   first   prototype   for   Privacy   Enhanced   Transactions   (PET).   It   was

released as proof-of-concept because it was an intermediate step towards a more
comprehensive   solution,   did   not   contain   all     components   of   the   architecture   and

included components that were not in a finalised form. With a few minor exceptions,
the source code was released under the GNU GPL version 2 license and provided as

both   a  Live  CD  (binaries)  and   source  code.  It  was  tested  on   HP and  IBM  laptops
equipped with Trusted Platform Modules (TPMs) and distributed with a disclaimer of

responsibility.
In 2008 the second proof-of-concept prototype, the CC@HOME (Corporate Computing

at Home) was developed. (it could also have been termed “Private Computing on
Corporate   Platforms”.)   It   reflects   the   situation   where   employers   tolerate,   within

reasonable limits, the utilization of corporate equipment (in particular notebooks) for
private purposes. However, while conniving in the private use of their equipment,

employers still want a safeguard that their machinery remains fit for being used on
their corporate network. The prototype was capable of hosting both proprietary and

non proprietary operating systems and came with a much improved graphical user
interface that allowed simplified switching between compartments and roles. It was

produced   using   SuSE's   build   environment   and   and   disseminated   under   GPLv2
through   SuSE's   repositories   that   are   mirrored   worldwide.   The   prototype   raised

considerable interest in product divisons of industrial partners. An extended version
has   been   used   extensively   as   hands-on   training   system   for   Trusted   Computing

technology since 2007.
The third proof-of-concept prototype addresses a virtual datacenter scenario and will

be   released   as   dedicated   OpenSuSE   11.1   distribution   under   GPLv2   in   2009.   The
system allows to create and manage mutually isolated “Trusted Virtual Domains”,

that   is,   clusters   of   virtual   machines   residing   on   arbitrary   nodes   of   a   managed
infrastructure.   The  architecture   provides   for  sophisticated   logical   isolation   of  data

and   management   traffic.  It   includes   platform   components   for   network  separation,
tools for managing physical and virtual components, and a console implementation

allowing to map Trusted Virtual domains to dedicated management compartments
hosting   the   administrative   frontends.   OpenTC   results   will   also   be   included   as

improvements   in   upstream   packages   and   will   thereby   become   part   of   future
distributions of Linux and Xen. Like the second proof-of-concept prototype, the third

one will be extended and maintained as training system for academic and industrial
use.
In addition to the proof-of-concept prototypes, all of OpenTC's documentation and
courseware have been made publicly available under the Creative Commons license.

Further   details   and   publishable   results   can   be   found   in   the   OpenTC   webpage
(

www.opentc.net

  in   the   Publications   and   download   sections.   Furthermore   all

released   Newsletters   can   be   read   on   the   OpenTC   webpage.   This   service   was
designed   to   inform   the   interested   public   about   downloadable   prototypes,   project

achievements and other up-to-date information, and it is meant to support discussion
about the underlying issues.

OpenTC  Publishable Activity Report

38/40

background image



 Publishable Activity Report OpenTC

4   List of Abbreviations

The following abbreviations may have appeared in this document

AMD

Advanced Micro Devices

API

Application Programming Interface

BME

Budapest University of Technology and Economics

CC

Common Criteria

CEA

Commissariat à l’Energie Atomique-LIST

CIM

Common Information Model

COM2

Comneon GmbH

CPU

Central Processing Unit

CUCL

University of Cambridge Computer Laboratory

DMTF-CIM

Distributed management Task Force – Common Information

Model

EAL

Evaluation Assurance Level

GUI

Graphical User Interface

HP

Hewlett-Packard Ltd

HTTP

Hypertext Transfer Protocol

HVM

Hardware Virtual Machine Monitor

IAIK

Graz University of Technology

IBM

IBM Research GmbH

IFX

Infineon Technologies AG

IMEI

International Mobile Equipment Identifier

INTEK

Intek

IP

Internet Protocol or Intellectual Property

ISE

Institute for Security and Open Methodologies

ITAS

Forschungszentrum Karlsruhe GmbH

KUL

Katholieke Universiteit Leuven

LDV

Lehrstuhl für Datenverarbeitung, Technische Universität
München

MPWG

(TCG) Mobile Phone Working Group

MSR

Machine Specific Register

ODBC

Open Database Connectivity

OMA

Open Mobile Alliance

OMTP

Open Mobile Terminal Platform

OS

Operating System

PC

Personal Computer

PCR

Platform Configuration Register

PIN

Personal Identification Number

PKCS

Public Key Cryptography Standards

POL

Politecnico di Torino

OpenTC  Publishable Activity Report

39/40

background image



 Publishable Activity Report OpenTC

PORT

Portakal Teknoloji Egitim Danismanlik Yazilim Turizm Taahhut

RHUL

Royal Holloway and Bedford New College

RUB

Horst Goertz Institute for IT Security, Ruhr-University Bochum

SDK

Software Development Kit

SKINIT

Secure Kernel Initialization

SOAP

Simple Object Access Protocol

SSH

Secure Shell

SSL

Secure Sockets Layer

SUSE

SUSE Linux Products GmbH

SVM

Secure Virtual Machine technology by AMD

SW

Software

SWP

Sub-Workpackage

TC

Trusted Computing

TCB

Trusted Computing Base

TCG

Trusted Computing Group

TCS

TCG Core Service

TCSI

TCG-Interface

TDDL

TCG-Device Driver Library

TDDLI

TDDL-Interface

TEC

Technikon Forschungs- und Planungsgesellschaft mbH

TPA

Trusted Platform Agent

TPM

Trusted Platform Module

TSPI

TSP-Interface

TSS

Trusted Software Stack

TSS-SDK

TSS-Software-Development-Kit

TUB

TUBITAK, National Research Institute of Electronics &
Cryptology

TUD

Technische Universität Dresden

TUS

Technical University of Sofia

VM

Virtual Machine

VMM

Virtual Machine Monitor also known as hypervisor

WP

Workpackage

WYSIWYG

What You See Is What You Get

WYSIWYS

What You See IS What You Sign

XML

Extensible Markup Language

OpenTC  Publishable Activity Report

40/40


Document Outline
