 Publishable Executive Summary P

eriod 3

D01.6 Periodic Reports (M25-M42)

Publishable Executive Summary

Project number

IST-027635

Project acronym

Open_TC

Project title

Open Trusted Computing

Deliverable type

Report

Deliverable reference
number

IST-027635/D01.6/1.1 FINAL

Deliverable title

Publishable Executive Summary

WP contributing to the
deliverable

WP01

Due date

April 2009 - M42

Actual submission date

June 3

rd

, 2009

Responsible Organisation

HP

Authors

Dirk Kuhlmann

Abstract

The Open Trusted Computing (OpenTC)
project develops a trusted and secure

computing system based on open source
software. The major goals are: developing a

secure operating system architecture,
producing management infrastructures and

software protocols as well as producing
prototype applications. This report shows

the activities performed towards reaching
the goals set for the period M25- M42.

Keywords

OpenTC, summary, progress, objectives,

activities, presentations, budget,
management,

Dissemination level

Public

Revision

1.1

Instrument

IP

Start date of the
project

1

st

 November 2005

Thematic
Priority

IST

Duration

42 months

Open_TC  Activity Report period 3

1/6



background image



 Publishable Executive Summary P

eriod 3

   Publishable Executive Summary

Introduction

The Open Trusted Computing (OpenTC) project develops components for a trusted
and secure computing system based on open source software. This IST FP6 project

No 027635 targets traditional computer platforms as well as embedded systems such
as mobile phones, aiming to reduce system-related threats, errors and malfunctions.

In   today's   computing   platforms,   the   lack   of   security   has   given   rise   to   waves   of
successful   attacks   and   system   crashes,   resulting   in   severe   economic   damage   to

enterprises and private users, as well as endangering critical infrastructure. Using the
trust and security approach of the OpenTC project, system-protection measures will

be   an   integral   part   of   the   computer   system   kernel.   The   weaknesses   of   today's
computers, which require that insecure operating systems are shielded by an ever

increasing number of protective layers such as virus scanners and firewalls, will be
complemented and potentially replaced by integrated trust and security.
OpenTC   aims   at   improving   the   reliability   of   authenticating   platforms   and   system

components,   making   it   easier   to   defend   against   current   network   threats   such   as
phishing, viruses, trojan horses, corruptive software and other attacks from hostile

sources. The project's results enable platforms to run critical applications such as
trusted banking or e-commerce software in their own, sealed-off compartments that

are protected against external access. The framework developed in this project can
eliminate most current assaults and dangers in the computing world.
These   techniques   can   also be  employed   to  ward  off  threats  to  the   reliability   and

security of applications and software in devices such as, for example, mobile phones.
Insecure and unreliable behaviour can be eliminated from the start in new IT-based

equipment   and   applications   by   exploiting   the   results   of   the   OpenTC   project.   The
results will be open source and freely available to users and researchers.
The enabling technology used in OpenTC for computer security is the design and

implementation of a layered system architecture in which a special computer chip,
the Trusted Platform Module (TPM) – similar to a smart card – performs the security

functions in a protected hardware environment. The OpenTC project has three major
technical objectives:

Developing   a   secure   operating   system   architecture   consisting   of   universal

virtualization layers, Trusted Software Stack (TSS) for Linux, and TC and TPM
management software

Producing   management   infrastructures   and   software   protocols   for   Trusted

Computing   in   the   areas   of   policy   management,   including   distributed   policy
enforcement,   security   state   monitoring   and   management,   network

management, and configuration management software

Producing prototype applications for Trusted Computing system support in the
areas   of   CA,   PKI,   attestation   and   zero   knowledge   authentication,   Trusted

WYSIWYS (What You See Is What you Sign) and Proof-of-Concept for digital
signing and verification).

To   support   these   prototypes,   OpenTC   also   addresses   the   Integration   of   TC   into

existing Public Key Infrastructures and the adaptation of TC APIs (especially the TSS
stack on the TPM to other programming languages, in particular JAVA.

Results of Final Project Phase

The   proof-of   concept   prototype   for   the   'Corporate   Computing   at   Home'   use   case
produced  in  the  second project phase  was extended  and  ported  to an  up-to-date

distribution of OpenSUSE. The result was released as Open Source distribution under
GPLv2.   It   includes   all   components   necessary   to   run   the   use   case,   including

infrastructure   and   server   elements   to   generate   certificates   and   perform   remote

Open_TC  Activity Report period 3

2/6

background image



 Publishable Executive Summary P

eriod 3

attestation. The architecture supports hosting instances of Linux as well as those of
MS-Windows XP. For copyright reasons, images for the latter could not be embedded

in the distribution. Instead, documentation was made available on how to build and
configure such images.
Public versions of WP02's cooperative work with external partners were released: the

first one concerned a Protection Profile for High Assurance Kernels, the second one
the IPR study carried out during the last reporting period. The General Requirements

and   Specification   was   extended   to   include   experiences   with   OpenTC's   'Corporate
Computing   at   Home'   proof-of-concept   prototype.   Additional   user   studies   were

performed, targeting the design of a suitable graphical user interface in particular.
The   results   influenced     the   final   design   of   the   OpenTC   GUI   and   highlighted   user

expectations for future support of accelerated 3D graphics on virtualized platforms.
This, in turn, opened up a new area of research in WP04.
WP03  finalized the port of the Infineon TSS to Linux, including fixes for problems

found by the code evaluation and testing performed by WP07. New releases of the
JAVA TSS and its set of management tools were produced. A minimalistic execution

environment   comprising   of   a   core   Linux,   the   JAVA   engine,   a   Privacy   Certificate
Authority   capable   of   self-attestation,   and   command   line   tools   was   produced.   Key

management   components   were   redesigned   and   equipped   with   Configuration
templates   to   support   ssh,   IPSec,   and   Racoon.   PKCS#11   software   modules   were

adapted for integration with the OpenTC management console.
WP04 concluded the implementation of the virtual network switch to include IPSec as
transport protocol. The result was transferred to WP05 for inclusion in the Trusted

Virtual   Datacenter   infrastructure.   The   virtual   TPMs   architecture   designed   and
implemented by the work package is integrated with the hypervisor Basic Security

Management Interface (BMSI) and the hierarchical integrity management component
(HIM) developed in cooperation with WP05. The prototyped implementation provides

virtual TPMs to guest operating systems running on XEN or L4. A new, hypervisor-
agnostic   architecture   for   high   performance   graphics   virtualization   was   developed

that   is   based   on   the   new   'Gallium'   graphics   driver   architecture.   A   prototype   was
developed  for client  OpenTC  platforms  running XEN,  proving  that the  new  design

reduces the footprint of the graphics related trusted code base by more than one
magnitude.
WP05  requirements   drove   the   work   on   the   last   proof-of-concept   prototype   that

covers a large subset of the OpenTC framework. The work package  developed the
policy management and part of the security enforcement mechanisms of the OpenTC

platform that are part of the proof-of-concept prototype for virtualized data centers.
This included several basic building blocks for Trusted Virtual Domains: TVD master

and proxy, the virtual network switch, components for storage, machine life cycle
management,   and   extended   public   key   infrastructure.   For   the   proof-of-concept

prototype, the partners developed a lightweight management infrastructure based
on   the   cross-hypervisor   management   interface   of

libVirt.

Taking   a   DMTF   draft

analysis   as   the   starting   point,   a   CIM   provider   was   developed.   It   supports   the
configuration of TPM functionality during the setup phase of data center nodes and

can be linked into the management components of virtual datacenters developed by
the project. PKI management components extended with simplified communication

protocols for multiple languages, and two types of Trusted Channels were developed.
Research on new directions and foundations of Trusted Computing led to a number of

high-profile publications.
WP06 produced the requirements and refined the security model of a minimal API for
the security services and the Trusted Channel implementations developed by WP05.

All sub-workpackages delivered their application prototypes according to the work
plan.
WP07  performed comprehensive black box testing and static code analysis for the

XEN core system. An important supportive argument for using the XEN hypervisor for

Open_TC  Activity Report period 3

3/6

background image



 Publishable Executive Summary P

eriod 3

security architectures is the fact that the security audit discovered no vulnerabilities
that would compromise the its ability to isolate separate execution domains. For L4, a

certification feasibility study for the L4/Fiasco was produced, and its code base was
subjected to static code analysis. Results of this analysis attest a very high quality of

the code. Further targets for static code analysis were the boot loader OSLO, the
new, Gallium based graphics virtualization components of WP04, and the TrouSerS

package,   an   independent   alternative   to   the   Infineon   TSS   stack.   WP07   has
substantially contributed to the overall community benefit of OpenTC by publishing

the ACSL specification language, by releasing and supporting the FRAMA-C analysis
toolkit   for   public   use,   and   by   disseminating   the   extended   Open   Source   Testing

Methodology as integral part of a highly renowned book on Linux security. A trust
analyst certification process has been started and will be available in near future.
WP08 ported basic microkernel-based operating system components (L4 microkernel,

L4   environment,   L4Linux)   and   the   TPM   emulator   to   the   Infineon   S-GOLD3
development   platform   for   mobile   devices.   For   this   context,   a   detailed   security

analysis was performed. A Secure Wallet application was designed and developed.
Based on the analysis of requirements for this application, a comprehensive set of

trusted   mechanisms   necessary   to   implement   trusted   applications   for   mobile
platforms was determined. Theoretical research of this WP addressed property-based

attestation for the protection of mobile hosts against malicious mobile agents, the
examination   and   analysis   of   property-based   attestation   mechanisms,   potential

interactions   between   trusted   computing   components   and   'crimeware',   and   the
utilization of Trusted Computing technology for ubiquitous mobile computing.
In cooperation  with the core developers of the proof-of-concept prototypes,  WP09

adapted  OpenTC and Linux components where necessary and guided the packaging
and integration into a dedicated distribution based on OpenSUSE 11.1. It facilitated

several tedious porting tasks arising from changes in low level OS interfaces and the
synchronization between hypervisor and Linux kernel revision updates. Developers

were supported in adopting to the work flow imposed by the automated build process
for SuSE distributions. The integration of the OpenTC build process with user friendly

graphical   interfaces   provided   by   SuSE   Studio   promises   to   greatly   simplify   the
production of distributions and purpose build execution environments .
During   the   reporting   period,  WP10  has   further   extended   its   activities   on

dissemination  and  exploitation.  It  informed   the  experts   as  well as   the   non-expert
public about the challenges addressed and research results achieved in the trusted

computing   area.   A   detailed   overview   is   given   in   the   following   section.   The
exploitation     plan   was   finalized   and   started   to   put   into   practice.   First   successes

include the adoption of OpenTC results in products and product roadmaps of several
industrial OpenTC partners. OpenTC partners continued their work on standardizing

in the context of the JAVA Community Process and the Open Mobile Terminal Platform
Group.

Dissemination of Knowledge and Results

In line with the strategy pursued during the previous reporting periods, the project's
results of year two were packaged and as Open Source distribution under GPLv2.

Since mid-2008, the release is produced by the OpenSUSE build system KIWI. The
packaging   of   the   end   release   is   in   progress,   and   a   version   including   the   latest

updates and bug fixes will be finalized in mid 2009. The minor shift in the planned
release   date   is   due   to   the   project's   decision   to   deliver   its   results   with   the   latest

available OpenSUSE distribution 11.1, which involved additional porting efforts.
OpenTC   maintained   a   high   level   of   dissemination   and   training   activities,   firmly
establishing its concepts and results in academic research and publishing, training,

and standardization. During the reporting period, OpenTC results were presented in
more than 29 mostly international conferences and workshops. The project partners

published   some  90  scientific   papers   and   articles,     participated   in   more   than  43

Open_TC  Activity Report period 3

4/6

background image



 Publishable Executive Summary P

eriod 3

presentations, talks, and discussion rounds. 23 academic courses were designed and
delivered to national and international audiences. As in the previous period, the new

proof-of-concept prototype from year two was extended and employed as a training
system.     For   the   foreseeable   future,   the   final   OpenTC   core   architecture   will   be

maintained as a base platform for academic and  professional training.

Exploitation of Final Results

A subset of framework components developed by OpenTC during the final reporting

period was integrated for the final review in a proof-of-concept prototype for Trusted
Virtual Datacenters. This  demonstrator will be included in  the final release  of the

framework,   which   will   be   released   under   Open   Source   license   as   dedicated
OpenSUSE 11.1 distribution.
In   addition   to   this   distribution,   OpenTC   results   already   have   been   or   are   in   the

process of being exploited by various partners. The components for a disaggregated
domain   launcher,   the   new   graphics   subsystem   and   improvement   resulting   from

testing   and   code   analysis   will   become   an   integral   part   of   the   XEN   hypervisor.
Infrastructure and management components such as the virtual network switch and

the TVD-aware libvirt management extensions will be included in future versions of
official SuSE distributions. Trust and virtualization management approaches explored

in   OpenTC   are   considered   for   inclusion   in   IBM's   management   software,   and
architectural concepts for Trusted Virtual Clients investigated by this project have

been included in product roadmaps of HP. Applications developed for the OpenTC
framework are exploited by the partners either as products or for internal purposes.

The distribution will be maintained for the foreseeable future, including the training
platform developed on top of the OpenTC architecture.
OpenTC results have further been exploited through standardization activities   the

JAVA TSS API within JSR321 Expert Group with a first release of the specification for
Early Draft Review   in April 2009. OpenTC partners provided input to and reviewed

the   Open   Mobile   Terminal   Platform   Group's   specification   on   Advanced   Trusted
Environment (TR1).

Conclusion

All deliverables specified by the OpenTC work plan for this period were finalized as
planned.   In   some   cases,   minor   delays   occurred   due   version   updates   of   base

components or resourcing problems, however, without affecting the general progress
of the project. The extension of technical work beyond month 36 recommended by

the reviewers proved to be beneficial with regard to the development of the new
graphics subsystem, the investigation on CIM based management interfaces, and the

testing of additional components.
OpenTC   has   reached   its   technical   aims   of   providing   a   framework   for   trusted
virtualization   based   on   Open   Source   Software   that   can   be   maintained   and

disseminated   in   future   by   means   of   a   industry   grade,   highly   automated   process.
OpenTC has a comprehensive exploitation plan and can already point to a number of

first successes in exploiting results. The project partners have continued to foster the
growing   European   and   international   research   ecosystem   on   Trusted   Computing.

OpenTC's research and contributions were instrumental in helping to establish the
new TRUST conference and the TC summer schools, both now running in their third

year.
In   summary,   OpenTC   has   achieved   its   technical   and   its   non   technical   goals   and
objectives for the reporting period  as well as for the overall project.

Open Trusted Computing Partners

The   OpenTC   project   is   formed   by   an   international   multidisciplinary   consortium
consisting   of   23   partners:   Technikon   Forschungs-   und   Planungsgesellschaft   mbH

Open_TC  Activity Report period 3

5/6

background image



 Publishable Executive Summary P

eriod 3

(project coordination, AT); Hewlett-Packard Ltd (technical leader, UK); AMD Saxony
LLC   &   Co.   KG   (DE);   Budapest   University   of   Technology   and   Economics   (HU);

Commissariat   à   l’Energie   Atomique   –   LIST   (FR);   COMNEON   GmbH.   OHG   (DE);
Forschungszentrum Karlsruhe GmbH – ITAS (DE); Horst Görtz Institute for IT Security,

Ruhr-Universität Bochum (DE); IBM Research GmbH (CH); Infineon Technologies AG
(DE); INTEK Closed Joint Stock Company (RU); ISECOM (ES); Katholieke Universiteit

Leuven   (BE);   Politecnico   di   Torino   (IT);   Portakal   Teknoloji   (TR);   Royal   Holloway,
University of London (UK); SUSE Linux Products GmbH (DE); Technische Universitaet

Dresden (DE), Technische Universitaet Graz (AT), Technische Universitaet Muenchen
(DE),   Technical   Universiy   of   Sofia   (BR)   TUBITAK   –   UEKAE   (TR);   and   University   of

Cambridge (UK).

Open Trusted Computing Consortium

The total volume of the project is estimated to be 17.1 Million Euro, part of which will

be contributed by the EC. Visit www.opentc.net to learn more.
For further information please contact:

Technikon Forschungs- und Planungsgesellschaft mbH
Richard-Wagner-Strasse 7, 9500 Villach, Austria

Tel.: +43 4242 233 55-0, Fax: +43 4242 233 55-77
Email:

coordination@opentc.net

OTC Logo

OTC Disclaimer

The information in this document is provided “as is”, and no guarantee or warranty is

given that the information is fit for any particular purpose. The user thereof uses the
information at its sole risk and liability.

Open_TC  Activity Report period 3

6/6

Picture 1: OpenTC Consortium at General Assembly Meeting in Zurich Sept. 2006

Picture 2: OpenTC Logo


Document Outline
