D04.4: Initial prototype L4-based TC system

D04.4 Initial prototype L4-based TC system

Project number

IST-027635

Project acronym

Open_TC

Project title

Open Trusted Computing

Deliverable type

Report (see p 84/85 Annex 1 - Nature)

Deliverable reference number

IST-027635/DD04.4/FINAL|1.0

Deliverable title

D04.4: Initial prototype L4-based TC system

WP contributing to the deliverable

WP4

Due date

Feb 2007 - M16

Actual submission date

April 2007

Responsible Organisation

TUD

Authors

TUD (Bernhard Kauer, Carsten Weinhold,
Christelle Braun, Alexander Böttcher),
HP (David Plaquin)

Abstract

This report describes an initial prototype of
an L4-based trusted operating-system layer.
The prototype is based on a snapshot of the
L4 software components that we provide in
OpenTC and it includes a first
implementation of the Basic Management
Interface (BMI), facilities to access TPMs, and
a trusted boot loader. This deliverable
includes the full source code of the L4-based
prototype as well as compiled binaries that
have been integrated into a demonstrator in
the form of a bootable CD image.

Keywords

WP4, prototype, microkernel, L4, L4Linux,
BMI, OSLO

Dissemination level

Public

Revision

FINAL|1.0

Instrument

Start date of the
project

November 2005

Thematic Priority

IST

Duration

42 months

D04.4: Initial prototype L4-based TC system

FINAL|1.0

If you need further information, please visit our website

www.opentc.net

or contact

the coordinator:

Technikon Forschungs-und Planungsgesellschaft mbH
Richard-Wagner-Strasse 7, 9500 Villach, AUSTRIA
Tel.+43 4242 23355 –0
Fax. +43 4242 23355 –77
Email

coordination@opentc.net

The information in this document is provided “as is”, and no guarantee

or warranty is given that the information is fit for any particular purpose.

The user thereof uses the information at its sole risk and liability.

Open_TC Deliverable D04.4

2/13

D04.4: Initial prototype L4-based TC system

FINAL|1.0

Table of Contents

1 Introduction .............................................................................................................. 3
2 The Software.............................................................................................................. 3

2.1 L4/Fiasco Microkernel............................................................................................. 3
2.2 Architectures based on L4/Fiasco........................................................................... 4
2.3 L4Env..................................................................................................................... 4
2.4 L4Linux................................................................................................................... 4
2.5 BMI – The Basic Management Interface.................................................................. 4
2.6 STPM...................................................................................................................... 5
2.7 IPCMon................................................................................................................... 5
2.8 OSLO...................................................................................................................... 6
2.9 Summary of Work Done Within OpenTC................................................................. 6

3 Demo......................................................................................................................... 8

3.1 General Remarks.................................................................................................... 8
3.2 Booting IPCMon Test.............................................................................................. 8
3.3 Booting STPM Test.................................................................................................. 8
3.4 Booting BMI Test.................................................................................................... 9
3.5 Booting OSLO Test................................................................................................. 9
3.6 Booting Integrated Demo of the Complete Prototype............................................ 9

3.6.1 L4Con and Run.................................................................................................. 9
3.6.2 STPM, BMI and IPCMon test............................................................................. 10
3.6.3 L4Linux and Networking.................................................................................. 10

4  Development........................................................................................................... 10
5  Outline – further steps............................................................................................. 11
6  List of Abbreviations ............................................................................................... 12
7  References............................................................................................................... 12

Open_TC Deliverable D04.4

3/13

D04.4: Initial prototype L4-based TC system

FINAL|1.0

Introduction

The WP4 work package of the OpenTC project aims to build two alternative trusted
operating system (OS) layers that provide isolation and protection mechanisms based
on virtualization. Both layers will have an interoperable Basic Management Interface
called BMI with common semantics for policies and configuration data in order to
manage protection domains. In these protection domains, applications and OSes such
as virtualized Linux instances are executed and protected from each other.

One of these OS layers is based on an L4 microkernel, the other one is based on the
Xen VMM. This report describes the initial prototype of the L4-based trusted OS layer.
It documents the basic functionality for the trusted OS layer that we developed within
the OpenTC project, such as communication control and facilities to access TPMs as
well as a rudimentary implementation of the BMI.

The Software

This deliverable is based on the February 2007 OpenTC snapshot of our

software,

which is publicly available at the OpenTC project website

[3]

. The provided source tree

contains the

L4/Fiasco

microkernel, the

L4Env

-core packages that provide services

on top of this microkernel, and a paravirtualized Linux kernel called

Linux

Additionally, we present in this deliverable the first prototype of the L4 BMI
implementation, an L4Env service providing access to TPM interfaces called STPM, and
our trusted boot loader Open Secure LOader (OSLO). In the next sections, we briefly
describe the aforementioned software and give an overview of the components that
were newly developed or modified for OpenTC. Where applicable, we refer to further
documentation, before we present a demonstrator of the L4-based trusted OS layer in
the next chapter.

2.1 L4/Fiasco Microkernel
L4

is a second-generation microkernel originally developed by Jochen Liedtke. The L4

philosophy is to implement only a minimal and essential set of functionality in kernel
space in order to facilitate the construction of robust and tiny kernels. The L4
mechanisms provided to user level tasks are isolation of tasks through separation of
address spaces, execution instances known as threads, and primitives for inter
process communication (IPC) that allow threads to cooperate. In contrast to monolithic
kernels such as Linux, all other required functionality including memory and IO
management, device drivers, file systems, and complex protocol stacks (e.g., for
networking) are implemented as services running as isolated L4 user-level tasks.
Nowadays, the name L4 also stands for a whole family of microkernels that implement
various versions of the L4 application binary interface (ABI). One of these
implementations is

Fiasco

, which is being developed and maintained at TU Dresden.

Fiasco is sometimes referred to as

L4/Fiasco

to emphasize the relation to L4. TU

Dresden is maintaining L4/Fiasco to improve stability and performance. Furthermore,
there are ongoing efforts to port it to more computer architectures and it is extended
with security features such as IPC monitoring, which supports the restriction of IPC-

Open_TC Deliverable D04.4

4/13

D04.4: Initial prototype L4-based TC system

FINAL|1.0

based communication among user level applications.

2.2 Architectures based on L4/Fiasco

L4/Fiasco is real-time capable and supports parallel execution of real-time and time-
sharing applications. This includes

Linux

a paravirtualized version of Linux that is

capable of executing on the L4 microkernel. It can run unmodified Linux programs.
Furthermore, the

Nizza

Secure-System

Architecture

[15] is based on a microkernel

-- in our implementation on L4/Fiasco -- and allows execution of security-critical
applications in parallel to untrusted applications such as one or more L

Linux

instances.

2.3 L4Env
L4Env

comprises a set of user-level services and libraries that facilitate the use of

L4/Fiasco and provide a basis for building an operating-system on top of L4. It provides
memory management with dataspaces, management of tasks, threads and IO
resources as well as services to start new applications. The development environment
for L4Env includes DICE [14], an IDL compiler used to automatically generate stub
code for remote function calls based on Interface Description Language (IDL) files.
These IDL files specify the interfaces provided by L4Env services as a set of functions,
which which applications can call remotely across address space boundaries.
Documentation of the L4Env is available at our L4Env webpage [5] and in the
documentation directory (doc/) of the binary version of the OpenTC snapshot. The
L4Env-core interface document [6] describes which functionality of the L4Env is
publicly supported and which functions an application developer should not rely upon.

2.4 L

Linux

Linux [13] is a port of the Linux kernel to the L4 microkernel ABI and L4Env. As a

paravirtualized Linux running on top of the microkernel, L

Linux is executed in ring 3

of the processor without privileges for accessing hardware IO ports or attaching to
IRQs, and without the permission to perform privileged operations such as interrupt
masking. Thus, multiple instances of L

Linux can run side-by-side with other L4

applications such as real-time or security components. Nevertheless, L4Env services
can grant specific L4Linux instances the necessary rights to access certain hardware
devices directly (e.g., a hard disk controller).

Because the paravirtualization only affects the inner functions of the kernel, L

Linux

provides binary compatibility to existing x86 Linux applications and can therefore be
used with any PC-based Linux distribution.

Linux is regularly updated to the latest Linux kernel version. Within this deliverable

the version from the February 2007 OpenTC snapshot is used, which is 2.6.19.

2.5 BMI – The Basic Management Interface

The cbbmi package provides a first view on the BMI implementation for L4Env. It is not
yet feature complete with regard to the current status of the BMI specification, but

Open_TC Deliverable D04.4

5/13

D04.4: Initial prototype L4-based TC system

FINAL|1.0

mainly a snapshot of the current development. In this early stage, the BMI supports
the following operations:

•

start a protection domain (PD) such as L

Linux or other L4 applications via the

L4 Loader or a guest L

Linux

•

send a shutdown signal to an L

Linux PD

•

kill a PD

•

list all started PDs

The user manual of the cbbmi package describes the structure of the BMI
implementation as well as the command line parameters of the bmic command-line
application. It is available in the documentation directory of the cbbmi package [4].

2.6 STPM

STPM is a server that provides a /dev/tpm like interface for other L4 components. It
reuses Linux-compatible device drivers for TPMs, mainly written by TUD, by using the
Device Driver Environment (DDE) for L4. DDE provides a Linux kernel-like environment
so that drivers originally written for Linux can be isolated in L4 tasks without the need
of a complete Linux kernel. For a deeper explanation of the DDE ideas see [1,2].

The following drivers are stored in the contrib/ directory of the sources and compiled
into the STPM server:

tpm/

The original Atmel TPM driver by IBM

inftpm/

A driver for v1.1 Infineon TPMs by TUD

oslo/tis.c

A driver for v1.2 TPMs of Atmel, Infineon, STM and Broadcom by TUD

tis_oslo/

Wrapper for the OSLO TIS driver with a Linux driver interface by TUD

The main difference between these drivers and those available in the 2.6.x Linux
Kernels is that the former do not require ACPI support in order to detect the which
particular TPM is installed. ACPI support is currently still missing in the L4 software
stack. Instead, these drivers probe for supported TPMs.

STPM is reported to work with the following TPMs:

•

Atmel v1.1 and v1.2

•

Infineon v1.1 and v1.2

•

STM v1.2

•

Broadcom v1.2

STPM will be the basis for TPM support in the final BMI implementation.

2.7 IPCMon

IPCMon provides IPC control for L4/Fiasco at the level of L4 tasks. It consists of a kernel
extension that adds support for task capabilities to Fiasco and a user-level server
called

ipcmon

that manages simple access policies and handles capability faults.

IPCMon was developed within the partner project EMSCB and will be used as the basis

Open_TC Deliverable D04.4

6/13

D04.4: Initial prototype L4-based TC system

FINAL|1.0

to implement access control in the BMI.

2.8 OSLO

The Open Secure LOader (OSLO) is the first publicly available boot loader that
leverages AMDs

skinit

instruction to create a dynamic root of trust as detailed in the

TCG Specification. An important advantage over a static root of trust is that the size
and complexity of the trusted computing base (TCB) can be reduced. As this
instruction can be executed after the initial boot-up phase performed by the BIOS, it is
possible to keep the BIOS and the actual boot loader (e.g, GRUB) out of the TCB. OSLO
and all trusted L4 components are loaded using an untrusted boot loader that starts
OSLO, which in turn puts the system into a trusted state using

skinit

and then passes

control to the L4/Fiasco boot strapper.

OSLO was developed by TUD within OpenTC specifically to use the new hardware
features of the AMD Athlon64 X2 processors. Due to its small size (approximately
1,000 lines of code resulting in a 4 kB of binary code), it should be feasible to review
and verify the correctness of OSLO.

The latest version of OSLO is part of the contrib/ directory in the STPM package,
however it can also be found at [7].

2.9 Summary of Work Done Within OpenTC

In the remainder of this chapter, we summarize the work that we did within WP4 of the
OpenTC project. First of all, TUD invested considerable resources into maintenance of
all the software components that we provide as part of our regular OpenTC snapshots.
This work involved various of bug fixes and improvements of documentation.

Furthermore, the prototype of the L4-based trusted OS layer contains newly added
components and modifications to L4/Fiasco, L4Env, and L

Linux that we did based on

requirements and on feedback from other OpenTC partners:

Source directory

Description of new functionality and modifications

l4linux-2.6/arch/l4/

●

implementation of software suspend in L4Linux as
required for future OpenTC demonstrators

●

improved support for multiple L4Linux instances
running concurrently (ability to transfer FPU states,
control assignment of ISA DMA memory)

●

several bug fixes and minor improvements

kernel/fiasco/

●

faster IPC path, more efficient use of kernel memory

●

support to transfer FPU states

●

support for KIP memory descriptors

●

several bug fixes

l4/pkg/ore/
l4linux-2.6/drivers/net/
l4ore.c

●

major functional improvements: support for loopback-
only networking, multiple ORe instances providing
isolated virtual LANs

●

several bug fixes

Open_TC Deliverable D04.4

7/13

D04.4: Initial prototype L4-based TC system

FINAL|1.0

l4/pkg/cbbmi/

●

newly implemented

l4/pkg/libsigma0/
l4/pkg/sigma0/

●

MTRR support (cacheable memory-mapped I/O)

●

use of KIP memory descriptors for improved
robustness

l4/pkg/stpm/

●

major functional improvements: OSLO-based TIS
driver, Linux wrapper for TIS driver

l4/pkg/stpm/contrib/oslo
/

●

newly implemented

l4/pkg/l4io/

●

support for mapping TPM TIS area

l4/pkg/ipreg/

●

newly implemented

l4/doc/dev-overview/

●

new document on how to get started with L4
development

Open_TC Deliverable D04.4

8/13

D04.4: Initial prototype L4-based TC system

FINAL|1.0

Demo

3.1 General Remarks

The provided bootable CD image can be run on real hardware or within a virtualization
software such as QEmu [8] or VMware [9]. Booting is done with GRUB 0.97 [10,11].
The serial port can be used for debugging purposes, see [12] for details.

Note however that the delivered software does not have product quality, but is rather
a proof of concept that shows the current status of the implementation as well as
future directions of development.

In the following sections, we describe the different choices the user is presented in the
GRUB boot loader's menu when booting from the demo CD.

3.2 Booting IPCMon Test

The IPCMon test shows that IPC in L4 can be restricted by using IPCMon. This test
loads, beside the

ipcmon

server, two applications:

ipctest1

and

ipctest2

. The former

periodically outputs log messages. The latter revokes the rights of

ipctest1

communicate with the log server after a few seconds. The log output after revokation
is something like:

ipcmon | ipcmon_pagefault(): ipc D -> 7 DENIED!
*ipctest1| main(): I'm still printing stuff to LOG.

In the first line IPCMon reports that it denied the communication from

ipctest1

to the

log server, which has task ID 7. The star at the beginning of the second line indicates
that the log output is not printed via the now unreachable log server, but the kernel
debugger instead.

3.3 Booting STPM Test

The STPM test demonstrates that a TPM can be accessed by L4 programs. It runs the
STPM server together with a program called

tpmdemo

. The interesting lines of the

output look similar to those below:

stpm | tis_oslo: Atmel rev: 2
tpmdemo | TPM version 1.1.0.0
tpmdemo | 24 PCR registers are available
tpmdemo | PCR-00: 99 37 C4 68 E2 12 7D 16 BF CB D8 14 AC FC F0

The first line shows that the

tis_oslo

driver has found an Atmel TPM. After that, the

number of the PCRs is shown and their values are dumped. Other output, such as the
key handles or information about the endorsement key is also displayed.

Open_TC Deliverable D04.4

9/13

D04.4: Initial prototype L4-based TC system

FINAL|1.0

3.4 Booting BMI Test

The BMI test starts the same applications as before, but uses the

cbbmi

server and

bmic

tool to start them. It tests the ability to start new applications with the BMI

interface.

bmic    | (bmilib) get_data(stpm$)
cbbmi   | bmi_setImage_component(): (bmi)############data:(stpm$)
cbbmi   | startPD_intern(): (bmi) INIT DATANEW(stpm)

The first line shows the command line to start with the bmic tool “

stpm

”, the second

line shows that the

cbbmi

server received the BMI

setImage()

call and the last line is

from the

startPD()

function of the BMI.

3.5 Booting OSLO Test

This test just boots OSLO alone. It can be used to check whether OSLO supports a
particular machine. The interesting lines on a machine not being an SVM platform are:

OSLO: No SVM platform
PAMPLONA: no ext cpuid
PAMPLONA: no module to start

The last line is always present in this test, as there is nothing started afterwards.

3.6 Booting Integrated Demo of the Complete Prototype

The full demo resembles all the aforementioned single tests into an integrated
scenario.

3.6.1 L4Con and Run

The demo is booted into L4con, a graphical console that can be used to multiplex the
framebuffer output of multiple applications. Please note that L4con is not supported in
OpenTC and used here only to ease the visualization of various running L4Linux
instances.

Two applications are running:

logcon

and

run

. The former is showing the log output,

also visible on the serial line. The latter can be used to start new applications.
Switching between the L4con consoles is done by using the shift and the
function_keys e.g. Shift+F1 to switch to

logcon

The help of

run

can be invoked by typing the single key

New applications can be

loaded by typing

An L4Linux can be started by loading

lx.conf

Open_TC Deliverable D04.4

10/13

D04.4: Initial prototype L4-based TC system

FINAL|1.0

3.6.2 STPM, BMI and IPCMon test

The STPM test can be performed here by executing:

bmic --start stpm
bmic --start tpmdemo

The output is shown on the serial port or on logcon. The

bmic

tool can be used either

via

RUN

or within an L

Linux shell.

The IPCMon test runs similarly by executing:

bmic --start ipcmon
bmic --start ipcmon_test.cfg

3.6.3 L

Linux and Networking

Multiple L

Linux instances could be started via

bmic --start-linux vmlinux 15

The last parameter gives the amount of memory they can use in megabytes. The one
before the name of the kernel.

The started L

Linux instances are connected via our virtual network switch (ORe). A

broadcast ping such as

ping 192.168.0.255

can be used to show which L4Linuxes are started.

It is also possible to log into these virtual machines via a simple remote shell on port
22. Use for instance

echo cat /proc/cmdline | nc 192.168.0.11 22

to get the commandline of a remote kernel.

There is currently no easy policy enforcement possible to restrict that a L4Linux
instance can connect to ORe. A device abstraction layer in the BMI could be
implemented to simplify the management of the virtual devices. This part of the BMI
could use IPCMon as underlying service.

Development

For developing software in the L4 environment the development overview [12] can be
used as a starting point. The document briefly describes and gives pointers to the
needed tools, the test environment and the way to write new components or to build
existing ones.

Open_TC Deliverable D04.4

11/13
