D05.3 Selected Portions of the Source Code

Used to Build D05.2

Project number

IST-027635

Project acronym

Open_TC

Project title

Open Trusted Computing

Deliverable type

Report (see p 84/85 Annex 1 - Nature)

Deliverable reference number

IST-027635/D05.3/Final

Deliverable title

Selected Portions of the Source Code Used to
Build D05.2

WP contributing to the deliverable

WP05

Due date

Oct 2007 - M24

Actual submission date

November 26, 2007

Responsible Organisation

IAIK, RUB, HP

Authors

IBM (Matthias Schunter), KUL (Dries
Schellekens)

Abstract

This CD contains source code of core
component of the OpenTC 2007
demonstrator for “Corporate Computing at
Home”. It is based on the research
documented in Deliverable D05.1 ”Basic
Security Services” and is accompanied by
design documentation in Deliverable D05.3.

Keywords

Security management, isolation policy, policy
enforcement, corporate computing at home,
2007 demonstrator, implementation, code

Dissemination level

Public

Revision

Final

Instrument

IP

Start date of the
project

1

st

 November 2005

Thematic Priority

IST

Duration

42 months



background image

A

BSTRACT

This CD contains source code of core component of the OpenTC 2007 demonstrator
for “Corporate Computing at Home”. It is based on the research documented in Deliv-
erable D05.1 ”Basic Security Services” and is accompanied by design documentation
in Deliverable D05.3.

The goal of these deliverable is to describe and explain the actual design and imple-

mentation of our demonstrator. In particular how we addressed the security challenges
identified in the given scenario.

2

background image

1

Introduction

This deliverable documents the current source code of the Workpackage 5 portions of
the 2007 demonstrator. It includes the security services for Xen and L4, the networking
for Xen, and the common public key infrastructure.

2

Xen Security Services/

: Xen Security Services

(IBM)

This directory contains the source code of the security services for Xen. This includes
integrity, network, and compartment management. This code is OpenTC Confidential.

3

vNET/

: Xen Virtual Networking (HPL)

This directory contains the source code of the virtual networking for Xen. This includes
the virtual switch code and virtual network management tools. This code is OpenTC
Confidential.

4

L4 Security Services

: Security Services for L4

(RUB)

The L4 Security Services directory contains the full source code of the L4 Security
Services including:

Compartment Manager

Integrity Manager

Property Manager

MicroGUI

Storage Manager

TPM Manager

User Manager

Trust Manager

other specific tools

Additionally this directory contains an archive holding the documentation of the

whole Security Services API in html format.

3

background image

5

PKI/

: Public-Key Infrastructure (IAIK)

The “PKI” directory contains a set of PKI components with Trusted Computing support
which were developed within OpenTC.

pca-0.1.tar.bz2 Is a proof-of-concept implementation of a “Privacy CA” server ser-

vice. This PKI service interprets TPM Endorsement Key certificates of hard-
ware TPMs and issues Attested Identity Key (AIK) certificates, plus common
management functions.

jTpmTools 0.3a.tar.bz2 Is a command line client application which showcases inter-

action with the local TPM to extract the EK certificate and does the AIK creation
cycle with a remote entity, the above mentioned Privacy CA.

tccert-0.2.2.tar.bz2 Is a library which provides the implementation of Trusted Com-

puting specific certificate handling.

Note that these packages are not standalone, but require additional support libraries.
For these and up to date versions please visit

http://trustedjava.sourceforge.net/

.
